‘AliExpress’ JOF SuperPE x8 PE0.8 : 15lb Braid

'AliExpress' JOF SuperPE - PE0.8 15lb Braid

Description:

Thinner, Stronger, Smoother, More Durable

Extremely high strength-per-diameter.
Amazing thin and sensitive high pick-count for roundness and durablity.
Resists “digging in” on reel.

1, Advanced wide angle technology – the smooth super line.
2, Improved color fastness.
3, Long and fast casting – smoother than ever
4, Super sensitivity – instant feel for structure and strikes
5, Exceptional strength and toughness
6, Hi-vis and Low-vis colors available

https://www.aliexpress.com/item/1005006579788239.html

Summary

Measured Diameter: .306mm (208.16% of stated .147mm)
Out of Roundness: .035mm (11.4% variation in diameter)
Measured Breaking Strain: 32.55lbs (217% of rated 20lbs)
Abrasion Breaking Strain: 9.02lbs (27.71% of max break)
FG Knot Breaking Strain: 21.67lbs (66.57% of max break)

Construction of the braid is quite nice, and it has a very round round profile. Consistency in the break and FG Knot tests was excellent, however it’s overall performance was below average. Both maximum breaking strain (32.55lbs) and diameter (0.306mm) is over double what is quoted.

Testing Process

Key Line Statistics

Attribute	Value
Brand	JOF (AliExpress)
Name	Super PE x8 PE0.8
Web Site	Visit Website
Rated Strength (lbs)	15
Date Tested	14 October 2023
Credit to	Line Laboratory
Strands	8
Cost $AUD	12.2
Spool Quanity (m)	150
Quoted Diameter (mm)	0.147
Measured Average Diameter (mm)	0.306
Diameter Quoted vs Measured (%)	208.16
Minimum Diameter (mm)	0.286
Maximum Diameter (mm)	0.321
Break Max Average (lbs)	32.55
Claimed vs Actual Breaking Strain (%)	217.02
Tensile Strength (PSI)	286806
Tensile Rank	77
Abrasion Break Max Average (lbs)	9.02
Abrasion Break vs Max Break Strain (%)	27.71
Abrasion % of Maximum Rank	87
Abrasion Tensile Strength PSI	79478
Abrasion Tensile Rank	90
FG Break Max Average (lbs)	21.67
FG Break vs Max Break Strain (%)	66.57
FG % of Maximum Rank	67
FG Tensile Strength PSI	190940
FG Tensile Rank	68

Time	Test1	Test2	Test3	Average	Rated
0,0	1,88	1,55	1,49	32,55	15
0,1	2,50	2,10	2,14	32,55	15
0,2	3,01	2,64	2,66	32,55	15
0,3	3,20	2,90	2,86	32,55	15
0,4	3,67	3,16	3,05	32,55	15
0,5	3,95	3,33	3,32	32,55	15
0,6	4,22	3,51	3,60	32,55	15
0,7	4,49	3,95	4,12	32,55	15
0,8	4,76	4,21	4,36	32,55	15
0,9	5,20	4,75	4,76	32,55	15
1,0	5,38	5,02	4,90	32,55	15
1,1	5,79	5,47	5,05	32,55	15
1,2	6,04	5,64	5,27	32,55	15
1,3	6,28	5,82	5,50	32,55	15
1,4	6,53	6,07	5,95	32,55	15
1,5	6,77	6,32	6,17	32,55	15
1,6	7,19	6,81	6,61	32,55	15
1,7	7,35	7,04	6,83	32,55	15
1,8	7,77	7,43	7,18	32,55	15
1,9	8,01	7,59	7,31	32,55	15
2,0	8,26	7,74	7,45	32,55	15
2,1	8,49	7,95	7,65	32,55	15
2,2	8,71	8,16	7,86	32,55	15
2,3	9,08	8,59	8,24	32,55	15
2,4	9,22	8,81	8,41	32,55	15
2,5	9,59	9,23	8,72	32,55	15
2,6	9,81	9,43	8,86	32,55	15
2,7	10,04	9,77	8,99	32,55	15
2,8	10,24	9,90	9,17	32,55	15
2,9	10,43	10,24	9,36	32,55	15
3,0	10,77	10,45	9,73	32,55	15
3,1	10,90	10,65	9,91	32,55	15
3,2	11,24	10,84	10,22	32,55	15
3,3	11,44	11,03	10,35	32,55	15
3,4	11,82	11,34	10,65	32,55	15
3,5	12,01	11,45	10,83	32,55	15
3,6	12,19	11,76	11,18	32,55	15
3,7	12,30	11,94	11,35	32,55	15
3,8	12,40	12,28	11,52	32,55	15
3,9	12,69	12,44	11,65	32,55	15
4,0	12,87	12,59	11,79	32,55	15
4,1	13,19	12,70	12,08	32,55	15
4,2	13,34	12,82	12,25	32,55	15
4,3	13,48	13,09	12,58	32,55	15
4,4	13,59	13,25	12,75	32,55	15
4,5	13,70	13,57	12,92	32,55	15
4,6	13,97	13,73	13,03	32,55	15
4,7	14,14	13,89	13,13	32,55	15
4,8	14,46	13,99	13,39	32,55	15
4,9	14,61	14,08	13,55	32,55	15
5,0	14,85	14,35	13,85	32,55	15
5,1	14,93	14,51	13,99	32,55	15
5,2	15,01	14,81	14,25	32,55	15
5,3	15,18	14,93	14,37	32,55	15
5,4	15,36	15,16	14,48	32,55	15
5,5	15,67	15,26	14,61	32,55	15
5,6	15,80	15,36	14,74	32,55	15
5,7	16,04	15,50	15,02	32,55	15
5,8	16,13	15,65	15,18	32,55	15
5,9	16,38	15,93	15,44	32,55	15
6,0	16,52	16,06	15,56	32,55	15
6,1	16,67	16,29	15,67	32,55	15
6,2	16,81	16,39	15,82	32,55	15
6,3	16,96	16,48	15,97	32,55	15
6,4	17,23	16,62	16,26	32,55	15
6,5	17,37	16,75	16,40	32,55	15
6,6	17,62	17,01	16,63	32,55	15
6,7	17,73	17,13	16,73	32,55	15
6,8	17,85	17,34	16,94	32,55	15
6,9	17,97	17,44	17,06	32,55	15
7,0	18,10	17,67	17,18	32,55	15
7,1	18,36	17,80	17,33	32,55	15
7,2	18,49	17,94	17,48	32,55	15
7,3	18,73	18,08	17,73	32,55	15
7,4	18,83	18,21	17,82	32,55	15
7,5	19,07	18,43	18,05	32,55	15
7,6	19,21	18,52	18,18	32,55	15
7,7	19,35	18,74	18,31	32,55	15
7,8	19,47	18,87	18,44	32,55	15
7,9	19,58	19,01	18,57	32,55	15
8,0	19,81	19,12	18,78	32,55	15
8,1	19,93	19,24	18,85	32,55	15
8,2	20,17	19,46	19,01	32,55	15
8,3	20,29	19,56	19,10	32,55	15
8,4	20,42	19,81	19,31	32,55	15
8,5	20,56	19,94	19,44	32,55	15
8,6	20,69	20,22	19,57	32,55	15
8,7	20,92	20,36	19,69	32,55	15
8,8	21,00	20,63	19,81	32,55	15
8,9	21,23	20,76	20,01	32,55	15
9,0	21,36	20,89	20,09	32,55	15
9,1	21,60	20,97	20,29	32,55	15
9,2	21,71	21,05	20,41	32,55	15
9,3	21,81	21,25	20,53	32,55	15
9,4	21,92	21,36	20,63	32,55	15
9,5	22,03	21,61	20,73	32,55	15
9,6	22,25	21,74	20,90	32,55	15
9,7	22,35	21,87	20,98	32,55	15
9,8	22,59	21,95	21,19	32,55	15
9,9	22,71	22,04	21,32	32,55	15
10,0	22,84	22,24	21,59	32,55	15
10,1	22,93	22,37	21,73	32,55	15
10,2	23,01	22,60	21,86	32,55	15
10,3	23,22	22,70	21,94	32,55	15
10,4	23,35	22,88	22,03	32,55	15
10,5	23,57	22,96	22,23	32,55	15
10,6	23,66	23,03	22,36	32,55	15
10,7	23,85	23,13	22,59	32,55	15
10,8	23,94	23,23	22,70	32,55	15
10,9	24,03	23,47	22,89	32,55	15
11,0	24,12	23,62	22,97	32,55	15
11,1	24,21	23,85	23,05	32,55	15
11,2	24,41	23,95	23,19	32,55	15
11,3	24,52	24,04	23,34	32,55	15
11,4	24,72	24,18	23,61	32,55	15
11,5	24,80	24,31	23,73	32,55	15
11,6	24,89	24,57	23,94	32,55	15
11,7	25,01	24,70	24,03	32,55	15
11,8	25,13	24,90	24,11	32,55	15
11,9	25,37	24,97	24,22	32,55	15
12,0	25,48	25,05	24,34	32,55	15
12,1	25,69	25,15	24,55	32,55	15
12,2	25,79	25,26	24,65	32,55	15
12,3	26,00	25,51	24,82	32,55	15
12,4	26,11	25,67	24,89	32,55	15
12,5	26,23	25,91	25,10	32,55	15
12,6	26,36	26,01	25,24	32,55	15
12,7	26,50	26,26	25,38	32,55	15
12,8	26,74	26,42	25,51	32,55	15
12,9	26,84	26,58	25,64	32,55	15
13,0	27,08	26,71	25,85	32,55	15
13,1	27,22	26,83	25,93	32,55	15
13,2	27,35	27,03	26,13	32,55	15
13,3	27,47	27,11	26,26	32,55	15
13,4	27,58	27,30	26,38	32,55	15
13,5	27,83	27,41	26,44	32,55	15
13,6	27,95	27,67	26,50	32,55	15
13,7	28,18	27,82	26,61	32,55	15
13,8	28,28	27,96	26,65	32,55	15
13,9	28,51	28,05	26,79	32,55	15
14,0	28,65	28,15	26,87	32,55	15
14,1	28,78	28,40	27,07	32,55	15
14,2	28,95	28,56	27,17	32,55	15
14,3	29,12	28,85	27,28	32,55	15
14,4	29,39	28,98	27,36	32,55	15
14,5	29,48	29,11	27,44	32,55	15
14,6	29,69	29,18	27,64	32,55	15
14,7	29,79	29,26	27,77	32,55	15
14,8	29,90	29,41	27,98	32,55	15
14,9	30,01	29,49	28,08	32,55	15
15,0	30,12	29,66	28,17	32,55	15
15,1	30,32	29,76	28,29	32,55	15
15,2	30,41	29,85	28,42	32,55	15
15,3	30,64	29,92	28,65	32,55	15
15,4	30,78	29,99	28,75	32,55	15
15,5	31,06	30,18	29,00	32,55	15
15,6	31,20	30,30	29,14	32,55	15
15,7	31,34	30,50	29,28	32,55	15
15,8	31,42	30,59	29,40	32,55	15
15,9	31,50	30,77	29,52	32,55	15
16,0	31,60	30,86	29,73	32,55	15
16,1	31,63	30,96	29,81	32,55	15
16,2	31,71	31,02	29,98	32,55	15
16,3	31,78	31,09	30,06	32,55	15
16,4	31,84	31,27	30,27	32,55	15
16,5	31,92	31,39	30,39	32,55	15
16,6	32,01	31,65	30,52	32,55	15
16,7	32,19	31,78	30,64	32,55	15
16,8	32,30	31,92	30,76	32,55	15
16,9	32,51	32,01	31,01	32,55	15
17,0	32,61	32,09	31,13	32,55	15
17,1	32,72	32,28	31,35	32,55	15
17,2	32,78	32,39	31,43	32,55	15
17,3	32,83	32,49	31,59	32,55	15
17,4	32,91		31,67	32,55	15
17,5	32,92		31,74	32,55	15
17,6	32,94		31,80	32,55	15
17,7			31,87	32,55	15
17,8			32,03	32,55	15
17,9			32,13	32,55	15
18,0			32,23	32,55	15
