AliExpress JOF x16 200lb : PE20

AliExpress JOF x16 : PE20 Braid

OVERVIEW

The JOF NEW 16 Strands Braided Fishing Line is the perfect choice for avid anglers. This high-strength, anti-bite, and wear-resistant fishing line is designed using the latest weaving technology to ensure maximum durability and toughness. With a higher density and stronger pulling force, this line provides better performance than traditional 4, 8, 9, and 12 strands lines.

Attractive features of this line include its ability to cut through water easily, making it ideal for catching big fish in the sea. The improved density and strength of this line also give it a longer lifespan than other fishing lines on the market. Additionally, it is an excellent choice for fishing for ferocious carnivorous fish that are more likely to bite and damage lesser-quality fishing lines.

The JOF NEW 16 Strands Braided Fishing Line is available in 25LB-200LB and comes in a convenient 100M/300M length. This fishing line is perfect for all your fishing needs, from deep-sea fishing to freshwater fishing. Upgrade your fishing experience today with this unique and high-quality fishing line, which is sure to exceed your expectations.

https://www.aliexpress.com/item/1005006850445667.html

Summary

- Measured Ave Diameter: 0.878mm (109.75% of claimed diameter)
- Out of Roundness: 0.118mm (13.44% variation in diameter)
- Measured Maximum Break: 141.36 lbs (70.68% of claimed 200 lbs)
- Measured Stretch @ Break: 6.66% Abrasion
- Maximum Break: 89.2 lbs (63.1% of max break)
- FG Knot Maximum Break: 129.41 lbs (91.55% of max break)

Testing Process

Key Line Statistics

Attribute	Value
Brand	JOF
Name	x16 PE20
Web Site	Visit Website
Rated Strength (lbs)	200
Date Tested	12 September 2025
Credit to	LL
Strands	16
Cost $AUD	18.24
Spool Quanity (m)	100
Quoted Diameter (mm)	0.8
Measured Average Diameter (mm)	0.878
Diameter Quoted vs Measured (%)	109.75
Minimum Diameter (mm)	0.82
Maximum Diameter (mm)	0.938
Break Max Average (lbs)	141.36
Claimed vs Actual Maximum Break (%)	70.68
Average Stretch @ Maximum Break	6.66%
Tensile Strength (PSI)	150440
Tensile Rank	150
Abrasion Break Max Average (lbs)	89.2
Abrasion Break vs Max Break (%)	63.1
Abrasion % of Maximum Rank	1
Abrasion Tensile Strength PSI	94930
Abrasion Tensile Rank	101
FG Break Max Average (lbs)	129.41
FG Break vs Max Break (%)	91.55
FG % of Maximum Rank	8
FG Tensile Strength PSI	137723
FG Tensile Rank	123

StrainSummary	Test 1	Test 2	Test 3	Average	Rated
0.03	0.68	0.48	1.30	141.36	200
0.05	1.02	0.69	1.60	141.36	200
0.10	1.58	1.16	2.16	141.36	200
0.12	1.80	1.45	2.54	141.36	200
0.13	1.91	1.72	3.00	141.36	200
0.15	2.25	2.09	3.43	141.36	200
0.16	2.47	2.55	3.73	141.36	200
0.18	2.68	2.95	4.13	141.36	200
0.19	2.89	3.25	4.50	141.36	200
0.21	2.99	3.62	4.60	141.36	200
0.23	3.31	3.91	4.79	141.36	200
0.26	3.61	4.10	4.96	141.36	200
0.29	3.99	4.28	5.04	141.36	200
0.32	4.18	4.47	5.22	141.36	200
0.36	4.62	4.64	5.39	141.36	200
0.38	4.96	4.72	5.56	141.36	200
0.39	5.12	4.88	5.73	141.36	200
0.41	5.20	5.05	5.89	141.36	200
0.42	5.37	5.29	6.06	141.36	200
0.44	5.52	5.38	6.22	141.36	200
0.45	5.60	5.45	6.39	141.36	200
0.47	5.77	5.68	6.47	141.36	200
0.49	5.94	5.84	6.62	141.36	200
0.50	6.20	6.00	6.70	141.36	200
0.52	6.28	6.31	6.94	141.36	200
0.54	6.36	6.57	7.20	141.36	200
0.55	6.54	6.82	7.37	141.36	200
0.57	6.81	7.09	7.73	141.36	200
0.58	6.89	7.32	7.90	141.36	200
0.60	7.08	7.41	7.98	141.36	200
0.61	7.23	7.58	8.16	141.36	200
0.63	7.41	7.67	8.24	141.36	200
0.65	7.75	7.92	8.52	141.36	200
0.67	7.84	8.09	8.69	141.36	200
0.68	7.99	8.26	8.86	141.36	200
0.70	8.06	8.33	8.93	141.36	200
0.71	8.29	8.57	9.09	141.36	200
0.73	8.37	8.64	9.32	141.36	200
0.74	8.51	8.79	9.40	141.36	200
0.76	8.67	8.86	9.57	141.36	200
0.78	8.91	9.08	9.72	141.36	200
0.80	8.98	9.16	10.05	141.36	200
0.81	9.14	9.31	10.29	141.36	200
0.83	9.22	9.46	10.63	141.36	200
0.84	9.46	9.61	10.71	141.36	200
0.86	9.46	9.86	11.16	141.36	200
0.87	9.71	10.20	11.43	141.36	200
0.89	9.78	10.58	11.54	141.36	200
0.91	10.06	10.83	11.79	141.36	200
0.94	10.32	11.18	11.87	141.36	200
0.97	10.65	11.53	12.14	141.36	200
1.00	11.01	11.80	12.23	141.36	200
1.03	11.26	11.94	12.40	141.36	200
1.07	11.60	12.10	12.49	141.36	200
1.09	11.93	12.26	12.68	141.36	200
1.10	12.09	12.44	12.77	141.36	200
1.12	12.17	12.52	13.02	141.36	200
1.13	12.32	12.67	13.18	141.36	200
1.15	12.48	12.85	13.33	141.36	200
1.16	12.57	13.01	13.42	141.36	200
1.18	12.72	13.10	13.65	141.36	200
1.19	12.80	13.26	13.75	141.36	200
1.21	13.15	13.43	13.92	141.36	200
1.23	13.24	13.70	14.29	141.36	200
1.25	13.42	13.79	14.55	141.36	200
1.26	13.50	13.99	14.97	141.36	200
1.28	13.76	14.17	15.34	141.36	200
1.29	13.94	14.37	15.65	141.36	200
1.31	14.03	14.64	16.05	141.36	200
1.34	14.43	14.84	16.23	141.36	200
1.36	14.80	15.02	16.31	141.36	200
1.38	14.90	15.20	16.51	141.36	200
1.39	15.18	15.38	16.67	141.36	200
1.41	15.28	15.46	16.84	141.36	200
1.42	15.45	15.75	17.03	141.36	200
1.44	15.55	15.84	17.22	141.36	200
1.45	15.82	16.01	17.32	141.36	200
1.47	15.92	16.18	17.58	141.36	200
1.48	16.10	16.35	17.67	141.36	200
1.50	16.17	16.35	17.84	141.36	200
1.52	16.43	16.72	17.95	141.36	200
1.54	16.52	16.80	18.24	141.36	200
1.55	16.79	17.06	18.43	141.36	200
1.57	16.88	17.06	18.56	141.36	200
1.58	17.07	17.36	19.00	141.36	200
1.60	17.15	17.45	19.42	141.36	200
1.61	17.45	17.74	19.84	141.36	200
1.63	17.66	18.05	19.95	141.36	200
1.64	17.87	18.37	20.27	141.36	200
1.68	18.19	18.80	20.61	141.36	200
1.71	18.59	19.22	20.72	141.36	200
1.74	19.01	19.43	21.03	141.36	200
1.78	19.33	19.54	21.14	141.36	200
1.81	19.73	19.84	21.35	141.36	200
1.83	20.14	19.94	21.54	141.36	200
1.84	20.23	20.14	21.75	141.36	200
1.86	20.43	20.24	21.93	141.36	200
1.87	20.63	20.54	22.03	141.36	200
1.89	20.82	20.71	22.25	141.36	200
1.90	20.90	20.81	22.48	141.36	200
1.92	21.12	21.03	22.71	141.36	200
1.94	21.33	21.22	22.95	141.36	200
1.95	21.64	21.43	23.19	141.36	200
1.97	21.76	21.54	23.39	141.36	200
1.99	21.96	21.84	23.50	141.36	200
2.00	22.08	21.93	23.75	141.36	200
2.02	22.42	22.16	23.87	141.36	200
2.03	22.54	22.39	24.24	141.36	200
2.05	22.78	22.60	24.37	141.36	200
2.06	22.89	23.09	25.00	141.36	200
2.08	23.26	23.45	25.37	141.36	200
2.10	23.76	23.94	25.84	141.36	200
2.12	23.87	24.06	26.28	141.36	200
2.13	24.07	24.38	26.65	141.36	200
2.15	24.16	24.49	27.10	141.36	200
2.16	24.49	24.84	27.22	141.36	200
2.18	24.59	24.98	27.58	141.36	200
2.19	24.94	25.33	27.70	141.36	200
2.21	25.05	25.33	27.96	141.36	200
2.23	25.27	25.53	28.22	141.36	200
2.25	25.49	25.62	28.35	141.36	200
2.26	25.74	26.07	28.49	141.36	200
2.28	25.85	26.20	28.86	141.36	200
2.29	26.11	26.44	29.16	141.36	200
2.31	26.35	26.57	29.30	141.36	200
2.32	26.61	26.91	29.43	141.36	200
2.34	26.75	27.04	29.96	141.36	200
2.35	27.16	27.30	30.53	141.36	200
2.39	27.54	27.54	30.53	141.36	200
2.42	28.03	27.94	30.96	141.36	200
2.45	28.54	28.32	31.36	141.36	200
2.47	28.92	28.84	31.77	141.36	200
2.49	29.17	29.24	31.90	141.36	200
2.50	29.40	29.63	32.14	141.36	200
2.52	29.67	30.15	32.38	141.36	200
2.54	29.92	30.69	32.50	141.36	200
2.55	30.15	31.17	32.63	141.36	200
2.57	30.41	31.29	33.01	141.36	200
2.58	30.54	31.54	33.26	141.36	200
2.60	30.79	31.82	33.53	141.36	200
2.61	30.90	32.09	33.80	141.36	200
2.63	31.16	32.36	34.11	141.36	200
2.65	31.42	32.48	34.28	141.36	200
2.67	31.69	32.61	34.61	141.36	200
2.68	31.94	33.06	34.91	141.36	200
2.70	32.21	33.35	35.22	141.36	200
2.71	32.49	33.64	35.50	141.36	200
2.73	32.78	33.95	35.63	141.36	200
2.74	32.94	34.11	35.91	141.36	200
2.76	33.37	34.37	36.47	141.36	200
2.78	33.52	34.76	36.74	141.36	200
2.80	33.94	34.89	36.88	141.36	200
2.81	34.37	35.17	37.35	141.36	200
2.84	34.65	35.31	37.50	141.36	200
2.86	35.10	35.74	37.81	141.36	200
2.87	35.24	36.16	38.15	141.36	200
2.89	35.52	36.44	38.46	141.36	200
2.90	35.95	36.75	38.73	141.36	200
2.92	36.09	36.90	38.86	141.36	200
2.94	36.50	37.33	39.16	141.36	200
2.96	36.66	37.49	39.45	141.36	200
2.97	36.94	37.80	39.74	141.36	200
2.99	37.07	37.95	40.02	141.36	200
3.00	37.49	38.42	40.32	141.36	200
3.02	37.63	38.57	40.65	141.36	200
3.03	37.93	38.88	40.84	141.36	200
3.05	38.22	39.19	41.19	141.36	200
3.07	38.51	39.48	41.89	141.36	200
3.10	39.15	39.79	42.36	141.36	200
3.13	39.64	40.11	42.69	141.36	200
3.16	40.24	40.45	42.98	141.36	200
3.19	40.93	40.63	43.48	141.36	200
3.23	41.59	40.80	43.84	141.36	200
3.25	41.95	41.31	44.19	141.36	200
3.26	42.26	41.95	44.55	141.36	200
3.28	42.70	42.49	44.93	141.36	200
3.29	42.86	43.16	45.26	141.36	200
3.31	43.17	43.81	45.62	141.36	200
3.32	43.48	44.45	45.80	141.36	200
3.34	43.81	44.93	46.26	141.36	200
3.36	44.15	45.09	46.42	141.36	200
3.38	44.31	45.61	46.75	141.36	200
3.39	44.62	45.78	47.12	141.36	200
3.41	44.95	46.31	47.48	141.36	200
3.42	45.30	46.50	47.66	141.36	200
3.44	45.62	46.86	48.17	141.36	200
3.46	46.15	47.24	48.36	141.36	200
3.47	46.31	47.59	48.69	141.36	200
3.49	46.83	47.78	49.05	141.36	200
3.51	47.15	48.29	49.44	141.36	200
3.52	47.33	48.46	49.61	141.36	200
3.54	47.69	48.84	50.39	141.36	200
3.55	48.19	49.21	50.76	141.36	200
3.57	48.38	49.61	50.95	141.36	200
3.58	48.56	49.82	51.77	141.36	200
3.60	49.16	50.39	52.13	141.36	200
3.62	49.52	50.97	52.47	141.36	200
3.64	49.71	51.56	52.84	141.36	200
3.65	50.08	51.88	53.20	141.36	200
3.67	50.42	52.23	53.58	141.36	200
3.68	50.78	52.59	53.79	141.36	200
3.72	51.52	52.92	54.17	141.36	200
3.75	52.01	53.27	54.53	141.36	200
3.78	52.73	53.65	54.88	141.36	200
3.80	53.27	54.04	55.28	141.36	200
3.81	53.44	54.23	55.68	141.36	200
3.84	53.99	54.42	56.37	141.36	200
3.86	54.73	55.00	56.79	141.36	200
3.88	54.99	55.39	57.71	141.36	200
3.89	55.34	55.60	58.15	141.36	200
3.91	55.58	56.20	58.37	141.36	200
3.93	56.06	56.39	59.20	141.36	200
3.94	56.49	56.83	59.63	141.36	200
3.96	56.95	57.25	59.85	141.36	200
3.97	57.38	57.65	60.29	141.36	200
3.99	57.76	58.11	60.74	141.36	200
4.01	57.96	58.79	61.15	141.36	200
4.02	58.37	59.43	61.57	141.36	200
4.04	58.74	60.41	62.01	141.36	200
4.06	59.33	60.90	62.22	141.36	200
4.07	59.33	61.23	62.62	141.36	200
4.09	59.95	61.42	63.03	141.36	200
4.10	60.15	62.08	63.46	141.36	200
4.12	60.58	62.31	64.07	141.36	200
4.13	60.98	62.75	64.07	141.36	200
4.15	61.80	62.96	63.61	141.36	200
4.17	62.00	63.63	63.50	141.36	200
4.18	62.42	64.09	63.58	141.36	200
4.20	63.01	64.56	63.83	141.36	200
4.22	63.21	64.78	63.97	141.36	200
4.23	63.51	65.26	64.07	141.36	200
4.25	63.47	65.66	63.92	141.36	200
4.26	63.29	65.76	63.78	141.36	200
4.28	63.27	64.82	64.67	141.36	200
4.29	63.45	64.62	65.53	141.36	200
4.31	63.87	64.66	66.34	141.36	200
4.33	64.31	64.75	66.72	141.36	200
4.35	64.49	64.63	67.39	141.36	200
4.36	64.96	65.29	68.01	141.36	200
4.38	65.09	65.71	68.33	141.36	200
4.39	65.43	66.94	68.95	141.36	200
4.41	65.51	68.39	69.52	141.36	200
4.42	65.79	69.32	70.35	141.36	200
4.46	66.91	69.90	70.35	141.36	200
4.49	67.81	70.52	71.11	141.36	200
4.52	68.92	70.81	71.59	141.36	200
4.54	69.72	71.35	72.07	141.36	200
4.55	70.28	71.60	72.32	141.36	200
4.57	71.15	72.12	72.82	141.36	200
4.59	71.43	72.39	73.31	141.36	200
4.60	71.98	73.25	73.77	141.36	200
4.62	72.54	73.79	74.80	141.36	200
4.64	72.80	74.32	75.44	141.36	200
4.65	73.33	74.57	76.22	141.36	200
4.67	73.87	75.27	77.36	141.36	200
4.68	74.43	75.53	78.19	141.36	200
4.70	74.96	76.31	78.47	141.36	200
4.71	75.49	76.31	79.30	141.36	200
4.73	76.02	77.12	79.84	141.36	200
4.75	76.30	77.65	80.38	141.36	200
4.76	76.85	78.21	80.91	141.36	200
4.78	77.40	79.34	81.47	141.36	200
4.80	77.99	80.13	81.71	141.36	200
4.81	78.24	81.15	82.20	141.36	200
4.84	79.47	81.67	82.74	141.36	200
4.87	80.24	82.97	83.31	141.36	200
4.91	81.01	83.74	83.84	141.36	200
4.94	82.04	84.76	84.38	141.36	200
4.97	83.12	85.35	84.62	141.36	200
4.99	84.13	85.87	85.11	141.36	200
5.00	84.37	86.12	85.64	141.36	200
5.02	85.10	86.89	86.20	141.36	200
5.03	85.36	87.14	87.06	141.36	200
5.05	85.86	87.40	87.59	141.36	200
5.07	86.12	88.00	88.13	141.36	200
5.08	86.66	89.09	88.39	141.36	200
5.10	87.19	89.09	89.20	141.36	200
5.12	87.75	89.94	89.77	141.36	200
5.13	88.34	90.22	90.07	141.36	200
5.15	88.62	91.09	90.62	141.36	200
5.16	89.17	91.36	91.19	141.36	200
5.18	89.72	91.91	91.74	141.36	200
5.19	90.24	92.42	92.31	141.36	200
5.21	91.03	92.69	92.60	141.36	200
5.23	91.03	94.07	93.17	141.36	200
5.24	91.81	94.88	93.71	141.36	200
5.26	92.38	95.14	94.25	141.36	200
5.28	92.95	96.02	95.39	141.36	200
5.29	93.19	96.33	96.30	141.36	200
5.31	94.02	97.21	97.44	141.36	200
5.32	94.89	97.21	98.60	141.36	200
5.34	95.49	98.04	99.75	141.36	200
5.35	96.05	98.34	100.65	141.36	200
5.37	96.33	99.28	101.26	141.36	200
5.39	96.93	99.57	101.55	141.36	200
5.41	97.46	100.17	101.86	141.36	200
5.42	98.03	100.79	103.04	141.36	200
5.44	98.32	101.38	103.34	141.36	200
5.45	98.58	101.67	103.87	141.36	200
5.47	99.65	102.54	104.47	141.36	200
5.48	99.90	102.85	104.77	141.36	200
5.50	100.46	103.44	105.32	141.36	200
5.52	100.76	103.73	106.21	141.36	200
5.54	101.60	104.62	106.51	141.36	200
5.55	101.88	105.50	107.14	141.36	200
5.57	102.16	106.67	107.46	141.36	200
5.58	103.00	107.87	108.41	141.36	200
5.60	103.58	108.76	109.69	141.36	200
5.61	103.89	109.98	110.01	141.36	200
5.63	104.76	111.27	110.62	141.36	200
5.65	105.34	112.20	111.53	141.36	200
5.68	106.21	112.79	112.17	141.36	200
5.71	107.48	113.39	113.39	141.36	200
5.74	108.44	114.00	114.33	141.36	200
5.76	109.64	114.60	114.33	141.36	200
5.77	110.20	115.20	114.97	141.36	200
5.79	110.78	115.51	115.29	141.36	200
5.81	111.09	116.14	116.27	141.36	200
5.83	111.71	116.73	116.92	141.36	200
5.84	112.31	117.06	117.22	141.36	200
5.86	112.92	118.04	118.22	141.36	200
5.87	113.53	118.35	118.84	141.36	200
5.89	113.83	119.29	119.14	141.36	200
5.90	114.72	119.62	120.09	141.36	200
5.94	115.62	120.25	120.43	141.36	200
5.97	116.80	121.49	121.05	141.36	200
5.99	117.70	122.40	121.95	141.36	200
6.00	118.34	123.04	123.21	141.36	200
6.02	118.94	123.98	124.11	141.36	200
6.03	119.57	124.28	124.73	141.36	200
6.05	120.22	124.88	125.73	141.36	200
6.07	120.54	125.53	127.10	141.36	200
6.08	120.85	125.85	128.07	141.36	200
6.10	121.77	126.20	128.73	141.36	200
6.12	122.37	127.19	129.04	141.36	200
6.13	123.01	127.91	129.66	141.36	200
6.15	123.58	128.23	129.68	141.36	200
6.16	124.20	128.86	129.62	141.36	200
6.18	124.49	129.71	130.69	141.36	200
6.19	125.43	129.92	131.42	141.36	200
6.21	125.72	130.61	132.18	141.36	200
6.23	126.40	131.32	132.52	141.36	200
6.25	127.04	131.97	132.88	141.36	200
6.26	127.69	133.24	132.43	141.36	200
6.28	128.03	134.21	133.24	141.36	200
6.29	128.71	135.43	133.61	141.36	200
6.31	129.37	136.67		141.36	200
6.32	129.99	130.21		141.36	200
6.35	131.27	136.18		141.36	200
6.39	132.21	137.98		141.36	200
6.42	133.46	137.98		141.36	200
6.45	134.36	139.20		141.36	200
6.48	135.66	138.98		141.36	200
6.50	135.00	140.12		141.36	200
6.51	135.16	140.54		141.36	200
6.53	135.86	141.32		141.36	200
6.55	136.81	142.08		141.36	200
6.57	135.65	142.78		141.36	200
6.58	135.41	143.51		141.36	200
6.60	137.29	143.85		141.36	200
6.61	138.22	142.11		141.36	200
6.63	138.64	142.79		141.36	200
6.64	138.73	142.79		141.36	200
6.66	138.73	144.37		141.36	200
6.67	139.83			141.36	200
6.69	138.83			141.36	200
6.71	138.97			141.36	200
6.74	140.72			141.36	200
6.77	142.42			141.36	200
6.80	143.93			141.36	200
6.84	144.53			141.36	200
6.86	145.35			141.36	200
6.87	146.10			141.36	200

Number	Measured	Average	Quoted
Number	Measured	Average	Quoted
1	0.935	0.878	0.800
2	0.895	0.878	0.800
3	0.823	0.878	0.800
4	0.856	0.878	0.800
5	0.938	0.878	0.800
6	0.897	0.878	0.800
7	0.820	0.878	0.800
8	0.856	0.878	0.800

AliExpress JOF x16 : PE20 Braid

OVERVIEW

Summary

Testing Process

Key Line Statistics

JOF x16 200lb PE20 Diameter
