Product characteristics:
Thinnest Line-super Thin 0.2# PE line
Refuse Bending-Supple&Tough
Smooth Line Body-Thin PE Coating On
Incredible abrasion resistance and knot strength
Round and Smooth design increase casting distance and overall fishability
Extremely low memory-easy to cast and handle
Zero stretch creates a line with extreme sensitivity that delivers rock solid hooksets
Small diameter to test LB ratio
Summary
- Measured Diameter: .146mm (208% of stated .07mm)
- Out of Roundness: .061mm (41.8% variation in diameter)
- Measured Breaking Strain: 7.45lbs (82.8% of rated 9lbs)
- Abrasion Breaking Strain: 2.82lbs (37.8% of max break)
- FG Knot Breaking Strain: 7.4lbs (100% of max break)
Average result for the Tensile test, however this was in contrast to the great result in the abrasion test and an exceptional performance for the FG Knot test. The ovality of the line is quite high even for an x4 braid. With a very competetive price, it might be worth a look if your in the market for a finesse x4 braid.
Testing Process
Your consent is required to display this content from youtube - Privacy Settings
Key Line Statistics
| Attribute | Value |
|---|---|
| Brand | Kingdom |
| Name | MicroFly PE0.2 |
| Web Site | Visit Website |
| Rated Strength (lbs) | 9 |
| Date Tested | 18 December 2023 |
| Credit to | Matthew W |
| Strands | 4 |
| Cost $AUD | 7.94 |
| Spool Quanity (m) | 150 |
| Quoted Diameter (mm) | 0.07 |
| Measured Average Diameter (mm) | 0.146 |
| Diameter Quoted vs Measured (%) | 208.57 |
| Minimum Diameter (mm) | 0.114 |
| Maximum Diameter (mm) | 0.175 |
| Break Max Average (lbs) | 7.45 |
| Claimed vs Actual Maximum Break (%) | 82.81 |
| Average Stretch @ Maximum Break | N/A |
| Tensile Strength (PSI) | 271091 |
| Tensile Rank | 132 |
| Abrasion Break Max Average (lbs) | 2.82 |
| Abrasion Break vs Max Break (%) | 37.85 |
| Abrasion % of Maximum Rank | 43 |
| Abrasion Tensile Strength PSI | 102614 |
| Abrasion Tensile Rank | 89 |
| FG Break Max Average (lbs) | 7.47 |
| FG Break vs Max Break (%) | 100.27 |
| FG % of Maximum Rank | 1 |
| FG Tensile Strength PSI | 271819 |
| FG Tensile Rank | 42 |
| Time | Test1 | Test2 | Test3 | Average | Rated |
|---|---|---|---|---|---|
| 0.0 | 0.00 | 0.00 | 0.00 | 7.45 | 9 |
| 0.1 | 0.81 | 0.71 | 0.84 | 7.45 | 9 |
| 0.2 | 1.38 | 1.17 | 1.42 | 7.45 | 9 |
| 0.3 | 1.53 | 1.28 | 1.59 | 7.45 | 9 |
| 0.4 | 1.69 | 1.56 | 1.90 | 7.45 | 9 |
| 0.5 | 1.79 | 1.73 | 2.06 | 7.45 | 9 |
| 0.6 | 1.88 | 1.90 | 2.21 | 7.45 | 9 |
| 0.7 | 2.13 | 2.05 | 2.31 | 7.45 | 9 |
| 0.8 | 2.27 | 2.21 | 2.41 | 7.45 | 9 |
| 0.9 | 2.55 | 2.46 | 2.66 | 7.45 | 9 |
| 1.0 | 2.69 | 2.56 | 2.80 | 7.45 | 9 |
| 1.1 | 2.82 | 2.80 | 3.08 | 7.45 | 9 |
| 1.2 | 2.91 | 2.95 | 3.22 | 7.45 | 9 |
| 1.3 | 2.99 | 3.09 | 3.44 | 7.45 | 9 |
| 1.4 | 3.20 | 3.22 | 3.53 | 7.45 | 9 |
| 1.5 | 3.33 | 3.34 | 3.62 | 7.45 | 9 |
| 1.6 | 3.56 | 3.55 | 3.74 | 7.45 | 9 |
| 1.7 | 3.67 | 3.64 | 3.86 | 7.45 | 9 |
| 1.8 | 3.85 | 3.84 | 4.09 | 7.45 | 9 |
| 1.9 | 3.93 | 3.96 | 4.21 | 7.45 | 9 |
| 2.0 | 4.00 | 4.08 | 4.40 | 7.45 | 9 |
| 2.1 | 4.11 | 4.19 | 4.49 | 7.45 | 9 |
| 2.2 | 4.21 | 4.31 | 4.57 | 7.45 | 9 |
| 2.3 | 4.42 | 4.49 | 4.68 | 7.45 | 9 |
| 2.4 | 4.51 | 4.57 | 4.79 | 7.45 | 9 |
| 2.5 | 4.68 | 4.74 | 5.00 | 7.45 | 9 |
| 2.6 | 4.74 | 4.85 | 5.11 | 7.45 | 9 |
| 2.7 | 4.81 | 5.05 | 5.28 | 7.45 | 9 |
| 2.8 | 4.91 | 5.15 | 5.34 | 7.45 | 9 |
| 2.9 | 5.01 | 5.25 | 5.41 | 7.45 | 9 |
| 3.0 | 5.20 | 5.32 | 5.51 | 7.45 | 9 |
| 3.1 | 5.30 | 5.38 | 5.60 | 7.45 | 9 |
| 3.2 | 5.45 | 5.55 | 5.80 | 7.45 | 9 |
| 3.3 | 5.50 | 5.64 | 5.90 | 7.45 | 9 |
| 3.4 | 5.65 | 5.84 | 6.06 | 7.45 | 9 |
| 3.5 | 5.74 | 5.95 | 6.13 | 7.45 | 9 |
| 3.6 | 5.83 | 6.10 | 6.29 | 7.45 | 9 |
| 3.7 | 5.92 | 6.16 | 6.38 | 7.45 | 9 |
| 3.8 | 6.02 | 6.21 | 6.48 | 7.45 | 9 |
| 3.9 | 6.17 | 6.31 | 6.57 | 7.45 | 9 |
| 4.0 | 6.24 | 6.41 | 6.67 | 7.45 | 9 |
| 4.1 | 6.38 | 6.59 | 6.82 | 7.45 | 9 |
| 4.2 | 6.47 | 6.68 | 6.88 | 7.45 | 9 |
| 4.3 | 6.55 | 6.82 | 7.03 | 7.45 | 9 |
| 4.4 | 6.64 | 6.89 | 7.12 | 7.45 | 9 |
| 4.5 | 6.74 | 7.00 | 7.21 | 7.45 | 9 |
| 4.6 | 6.88 | 7.06 | 7.29 | 7.45 | 9 |
| 4.7 | 6.93 | 7.11 | 7.37 | 7.45 | 9 |
| 4.8 | 7.06 | 7.50 | 7.45 | 9 | |
| 4.9 | 7.14 | 7.60 | 7.45 | 9 | |
| 5.0 | 7.31 | 7.45 | 9 | ||
| 5.1 | 7.39 | 7.45 | 9 | ||
| 5.2 | 7.48 | 7.45 | 9 | ||
| 5.3 | 7.54 | 7.45 | 9 | ||
| 5.4 | 7.59 | 7.45 | 9 | ||
| 5.5 | 7.65 | 7.45 | 9 |
Diameter Variation
