Beyond Braid x8 : 15lb Braid

Beyond Braid 8x : 15lb Braid

CAST FURTHER & LASTS LONGER– Smooth fluoropolymer coating that allows for more efficient casts and longer distances every time. A thinner diameter slices through your guides and allows you to pack more line onto your reel.
NO STRETCH FOR EXTREME SENSITIVITY– Braided line PE fibers have no stretch properties which allow you to feel every bite and have instant hooksets increasing your hookup ratio.
8X STRANDS– Our 8X braid has 8 tightly woven PE fibers for a thinner, smoother, and ultra-performing line. Having 8 strands gives this line a much rounder and more natural feel, which results in farther casts and a smoother experience every time.
LOW MEMORY– Helps keep your line straight during casting which leads to less wind knots, tangles, and will extend the life of your braid.
ABRASION RESISTANT– Ultra-strong construction allows you to yank fish out of the toughest of situations. Whether fishing around structure of bridges or heavy cover/vegetation, Beyond Braid will hold up and get you out of any tough spot.

https://beyondbraid.com/collections/all/products/8-strand-white

Key Statistics

Measured Diameter: .323mm (+202% on claimed .16mm)
Measured Breaking Strain: 21,9lbs (+146% on claimed 15lbs)
Abrasion Breaking Strain: 7,24lbs (28.9% of measured max) Both

Diameter and Breaking strain indicate that this line is closer to 22lb than 15lb.

Tensile Strength is very poor (last place).

Abrasion resistance is very poor (last place).

Testing Process

Key Line Statistics

Attribute	Value
Brand	Beyond Braid
Name	x8
Web Site	Visit Website
Rated Strength (lbs)	15
Date Tested	23 October 2022
Credit to	Line Laboratory
Strands	8
Cost $AUD	37.34
Spool Quanity (m)	274
Quoted Diameter (mm)	0.16
Measured Average Diameter (mm)	0.323
Diameter Quoted vs Measured (%)	201.87
Minimum Diameter (mm)	0.312
Maximum Diameter (mm)	0.334
Break Max Average (lbs)	21.9
Claimed vs Actual Maximum Break (%)	146
Average Stretch @ Maximum Break	N/A
Tensile Strength (PSI)	172076
Tensile Rank	150
Abrasion Break Max Average (lbs)	7.24
Abrasion Break vs Max Break (%)	33.06
Abrasion % of Maximum Rank	95
Abrasion Tensile Strength PSI	56887
Abrasion Tensile Rank	152
FG Break Max Average (lbs)	0
FG Break vs Max Break (%)	0
FG % of Maximum Rank	132
FG Tensile Strength PSI	0
FG Tensile Rank	132

Time	Test1	Test2	Test3	Average	Rated
0.0	0.00	0.00	0.16	21.90	15
0.1	0.09	0.33	0.29	21.90	15
0.2	0.13	0.67	0.41	21.90	15
0.3	0.27	0.84	0.54	21.90	15
0.4	0.40	1.14	0.71	21.90	15
0.5	0.72	1.25	0.87	21.90	15
0.6	0.90	1.37	1.21	21.90	15
0.7	1.24	1.52	1.39	21.90	15
0.8	1.41	1.68	1.67	21.90	15
0.9	1.69	2.00	1.77	21.90	15
1.0	1.80	2.16	2.05	21.90	15
1.1	1.92	2.49	2.21	21.90	15
1.2	2.07	2.65	2.38	21.90	15
1.3	2.23	2.81	2.54	21.90	15
1.4	2.54	2.91	2.71	21.90	15
1.5	2.71	3.02	2.98	21.90	15
1.6	2.97	3.27	3.08	21.90	15
1.7	3.07	3.42	3.34	21.90	15
1.8	3.17	3.74	3.50	21.90	15
1.9	3.33	3.90	3.65	21.90	15
2.0	3.48	4.18	3.79	21.90	15
2.1	3.81	4.30	3.93	21.90	15
2.2	3.98	4.41	4.16	21.90	15
2.3	4.26	4.57	4.26	21.90	15
2.4	4.38	4.72	4.50	21.90	15
2.5	4.66	5.04	4.66	21.90	15
2.6	4.83	5.21	4.96	21.90	15
2.7	5.00	5.47	5.12	21.90	15
2.8	5.16	5.56	5.27	21.90	15
2.9	5.32	5.66	5.38	21.90	15
3.0	5.58	5.80	5.48	21.90	15
3.1	5.69	5.94	5.74	21.90	15
3.2	5.94	6.24	5.90	21.90	15
3.3	6.10	6.40	6.22	21.90	15
3.4	6.25	6.66	6.39	21.90	15
3.5	6.41	6.77	6.56	21.90	15
3.6	6.58	7.01	6.66	21.90	15
3.7	6.85	7.16	6.77	21.90	15
3.8	6.95	7.30	7.01	21.90	15
3.9	7.20	7.46	7.15	21.90	15
4.0	7.34	7.61	7.42	21.90	15
4.1	7.62	7.87	7.55	21.90	15
4.2	7.77	7.97	7.78	21.90	15
4.3	7.98	8.19	7.87	21.90	15
4.4	8.05	8.30	7.97	21.90	15
4.5	8.12	8.56	8.10	21.90	15
4.6	8.26	8.70	8.24	21.90	15
4.7	8.41	8.84	8.50	21.90	15
4.8	8.69	8.93	8.63	21.90	15
4.9	8.84	9.01	8.86	21.90	15
5.0	9.09	9.23	8.95	21.90	15
5.1	9.20	9.36	9.05	21.90	15
5.2	9.42	9.62	9.16	21.90	15
5.3	9.53	9.76	9.27	21.90	15
5.4	9.64	9.89	9.49	21.90	15
5.5	9.75	9.96	9.61	21.90	15
5.6	9.85	10.04	9.79	21.90	15
5.7	10.03	10.21	9.86	21.90	15
5.8	10.09	10.31	9.93	21.90	15
5.9	10.28	10.51	10.05	21.90	15
6.0	10.39	10.62	10.16	21.90	15
6.1	10.51	10.79	10.42	21.90	15
6.2	10.64	10.86	10.57	21.90	15
6.3	10.76	10.93	10.78	21.90	15
6.4	10.96	11.04	10.85	21.90	15
6.5	11.02	11.15	10.99	21.90	15
6.6	11.20	11.37	11.07	21.90	15
6.7	11.30	11.47	11.14	21.90	15
6.8	11.46	11.63	11.22	21.90	15
6.9	11.51	11.69	11.30	21.90	15
7.0	11.56	11.74	11.45	21.90	15
7.1	11.64	11.84	11.51	21.90	15
7.2	11.71	11.93	11.67	21.90	15
7.3	11.89	12.12	11.76	21.90	15
7.4	12.00	12.21	11.85	21.90	15
7.5	12.21	12.37	11.97	21.90	15
7.6	12.33	12.43	12.08	21.90	15
7.7	12.44	12.62	12.26	21.90	15
7.8	12.49	12.74	12.31	21.90	15
7.9	12.54	12.86	12.42	21.90	15
8.0	12.66	12.94	12.46	21.90	15
8.1	12.74	13.03	12.61	21.90	15
8.2	12.86	13.14	12.71	21.90	15
8.3	12.90	13.17	12.81	21.90	15
8.4	13.03	13.31	12.90	21.90	15
8.5	13.12	13.43	12.98	21.90	15
8.6	13.20	13.54	13.15	21.90	15
8.7	13.32	13.62	13.22	21.90	15
8.8	13.44	13.70	13.43	21.90	15
8.9	13.67	13.86	13.55	21.90	15
9.0	13.78	13.94	13.75	21.90	15
9.1	13.99	14.14	13.82	21.90	15
9.2	14.09	14.25	13.89	21.90	15
9.3	14.19	14.45	13.94	21.90	15
9.4	14.25	14.54	13.99	21.90	15
9.5	14.30	14.62	14.15	21.90	15
9.6	14.40	14.64	14.25	21.90	15
9.7	14.45	14.67	14.44	21.90	15
9.8	14.62	14.81	14.52	21.90	15
9.9	14.74	14.94	14.70	21.90	15
10.0	14.95	15.14	14.81	21.90	15
10.1	15.02	15.22	14.91	21.90	15
10.2	15.10	15.30	14.99	21.90	15
10.3	15.20	15.38	15.08	21.90	15
10.4	15.30	15.47	15.22	21.90	15
10.5	15.49	15.66	15.29	21.90	15
10.6	15.58	15.78	15.41	21.90	15
10.7	15.72	15.96	15.47	21.90	15
10.8	15.76	16.03	15.53	21.90	15
10.9	15.87	16.14	15.62	21.90	15
11.0	15.93	16.19	15.70	21.90	15
11.1	15.99	16.23	15.89	21.90	15
11.2	16.11	16.34	16.00	21.90	15
11.3	16.24	16.45	16.22	21.90	15
11.4	16.44	16.65	16.34	21.90	15
11.5	16.52	16.75	16.54	21.90	15
11.6	16.68	16.93	16.61	21.90	15
11.7	16.76	17.02	16.69	21.90	15
11.8	16.84	17.20	16.76	21.90	15
11.9	16.92	17.30	16.84	21.90	15
12.0	17.01	17.39	17.00	21.90	15
12.1	17.10	17.44	17.09	21.90	15
12.2	17.12	17.50	17.27	21.90	15
12.3	17.20	17.61	17.35	21.90	15
12.4	17.26	17.67	17.56	21.90	15
12.5	17.33	17.84	17.69	21.90	15
12.6	17.44	17.95	17.81	21.90	15
12.7	17.56	18.06	17.91	21.90	15
12.8	17.73	18.17	18.01	21.90	15
12.9	17.79	18.29	18.17	21.90	15
13.0	17.94	18.49	18.24	21.90	15
13.1	18.02	18.57	18.35	21.90	15
13.2	18.19	18.73	18.41	21.90	15
13.3	18.27	18.81	18.53	21.90	15
13.4	18.35	18.90	18.60	21.90	15
13.5	18.36	18.92	18.67	21.90	15
13.6	18.37	18.94	18.76	21.90	15
13.7	18.48	19.00	18.85	21.90	15
13.8	18.58	19.07	19.08	21.90	15
13.9	18.81	19.17	19.21	21.90	15
14.0	18.95	19.21	19.42	21.90	15
14.1	19.12	19.37	19.49	21.90	15
14.2	19.15	19.49	19.56	21.90	15
14.3	19.19	19.71	19.63	21.90	15
14.4	19.28	19.80	19.70	21.90	15
14.5	19.36	19.90	19.87	21.90	15
14.6	19.54	19.94	19.96	21.90	15
14.7	19.62	19.99	20.11	21.90	15
14.8	19.72	20.06	20.17	21.90	15
14.9	19.74	20.08	20.23	21.90	15
15.0	19.75	20.23	20.23	21.90	15
15.1	19.90	20.35	20.24	21.90	15
15.2	20.04	20.47	20.41	21.90	15
15.3	20.33	20.52	20.57	21.90	15
15.4	20.47	20.58	20.79	21.90	15
15.5	20.67	20.78	20.85	21.90	15
15.6	20.74	20.94	20.97	21.90	15
15.7	20.92	21.17	21.03	21.90	15
15.8	21.05	21.26	21.10	21.90	15
15.9	21.22	21.34	21.10	21.90	15
16.0	21.27	21.38		21.90	15
16.1	21.32	21.41		21.90	15
16.2	21.34	21.48		21.90	15
16.3	21.36	21.52		21.90	15
16.4	21.51	21.64		21.90	15
16.5	21.64	21.74		21.90	15
16.6	21.78	21.89		21.90	15
16.7	21.80	21.96		21.90	15
16.8	21.81	22.02		21.90	15
16.9	21.81	22.14		21.90	15
17.0		22.26		21.90	15
17.1		22.48		21.90	15
17.2		22.59		21.90	15
17.3		22.72		21.90	15
17.4		22.76		21.90	15
17.5		22.79		21.90	15
