Cast x12 PE3 50lb Braid

CAST premium casting braid in both X12 and X8 is more supple and has a smoother surface allowing for longer trouble free casting and maximum performance.

Extreme smoothness has been achieved through an extra process call “High Stitch” which shrinks and tightens the line during manufacturing.

We have also added a micro coating to both the X12 and X8 Casting Braids which enables casting with far less friction and also repels water from the surface of the line ensuring long lasting higher performance.

https://castmag.co/products/x12-casting-braid?variant=40837338824883

Key Statistics

Measured Diameter: .371mm (+161.5% on stated .230mm)
Out of Roundness: .18mm (48.5% variation in diameter)
Measured Breaking Strain: 51.2lbs (102.4% of rated 50bs)
Abrasion Breaking Strain: 16.8lbs (32.9% of max break)
FG Knot Breaking Strain: 36.6lbs (71.5% of max break)

Final performance across all tests was average. Line inspection shows that the line is very flat, with an average diameter of +161% of what is written on the box. Quoted breaking strain is 50lbs, and our tests achieved a break of 51.19lbs, so it is very accurately rated.

Testing Process

Key Line Statistics

Attribute	Value
Brand	Cast x BUKU
Name	x12 Premium Casting Braid PE3
Web Site	Visit Website
Rated Strength (lbs)	50
Date Tested	14 October 2023
Credit to	Line Laboratory
Strands	12
Cost $AUD	90
Spool Quanity (m)	300
Quoted Diameter (mm)	0.23
Measured Average Diameter (mm)	0.371
Diameter Quoted vs Measured (%)	161.3
Minimum Diameter (mm)	0.272
Maximum Diameter (mm)	0.452
Break Max Average (lbs)	51.19
Claimed vs Actual Maximum Break (%)	102.39
Average Stretch @ Maximum Break	N/A
Tensile Strength (PSI)	297717
Tensile Rank	105
Abrasion Break Max Average (lbs)	16.82
Abrasion Break vs Max Break (%)	32.86
Abrasion % of Maximum Rank	98
Abrasion Tensile Strength PSI	97824
Abrasion Tensile Rank	96
FG Break Max Average (lbs)	36.62
FG Break vs Max Break (%)	71.54
FG % of Maximum Rank	91
FG Tensile Strength PSI	212979
FG Tensile Rank	84

Time	Test1	Test2	Test3	Average	Rated
0.0	2.30	1.98	1.83	51.19	50
0.1	3.23	2.85	2.36	51.19	50
0.2	3.69	3.29	2.62	51.19	50
0.3	3.97	3.59	2.98	51.19	50
0.4	4.24	3.88	3.34	51.19	50
0.5	4.90	4.58	4.04	51.19	50
0.6	5.28	4.98	4.39	51.19	50
0.7	6.00	5.75	4.95	51.19	50
0.8	6.33	6.12	5.18	51.19	50
0.9	6.67	6.49	5.40	51.19	50
1.0	6.91	6.73	5.70	51.19	50
1.1	7.15	6.97	5.99	51.19	50
1.2	7.77	7.52	6.56	51.19	50
1.3	8.14	7.84	6.83	51.19	50
1.4	8.83	8.45	7.28	51.19	50
1.5	9.14	8.76	7.47	51.19	50
1.6	9.45	9.06	7.65	51.19	50
1.7	9.66	9.27	7.92	51.19	50
1.8	9.86	9.48	8.20	51.19	50
1.9	10.38	9.98	8.75	51.19	50
2.0	10.70	10.26	9.03	51.19	50
2.1	11.28	10.84	9.51	51.19	50
2.2	11.55	11.13	9.70	51.19	50
2.3	12.02	11.68	10.18	51.19	50
2.4	12.23	11.93	10.47	51.19	50
2.5	12.43	12.19	10.75	51.19	50
2.6	12.74	12.37	11.03	51.19	50
2.7	13.06	12.54	11.31	51.19	50
2.8	13.65	12.95	11.76	51.19	50
2.9	13.93	13.19	11.92	51.19	50
3.0	14.38	13.65	12.33	51.19	50
3.1	14.54	13.89	12.58	51.19	50
3.2	14.71	14.12	12.82	51.19	50
3.3	14.95	14.28	13.09	51.19	50
3.4	15.20	14.44	13.35	51.19	50
3.5	15.64	14.87	13.79	51.19	50
3.6	15.83	15.13	13.96	51.19	50
3.7	16.30	15.63	14.37	51.19	50
3.8	16.56	15.85	14.60	51.19	50
3.9	16.98	16.23	15.07	51.19	50
4.0	17.14	16.38	15.29	51.19	50
4.1	17.29	16.53	15.52	51.19	50
4.2	17.51	16.75	15.64	51.19	50
4.3	17.72	16.98	15.75	51.19	50
4.4	18.17	17.39	16.07	51.19	50
4.5	18.40	17.59	16.27	51.19	50
4.6	18.73	17.97	16.71	51.19	50
4.7	18.82	18.17	16.95	51.19	50
4.8	18.92	18.36	17.34	51.19	50
4.9	19.10	18.61	17.50	51.19	50
5.0	19.29	18.87	17.65	51.19	50
5.1	19.72	19.33	17.85	51.19	50
5.2	19.98	19.53	18.06	51.19	50
5.3	20.37	19.90	18.48	51.19	50
5.4	20.52	20.05	18.69	51.19	50
5.5	20.66	20.42	19.00	51.19	50
5.6	20.86	20.62	19.08	51.19	50
5.7	21.05	20.83	19.17	51.19	50
5.8	21.45	21.00	19.36	51.19	50
5.9	21.66	21.18	19.54	51.19	50
6.0	21.95	21.53	19.97	51.19	50
6.1	22.05	21.70	20.22	51.19	50
6.2	22.31	22.10	20.60	51.19	50
6.3	22.47	22.33	20.73	51.19	50
6.4	22.64	22.55	21.08	51.19	50
6.5	22.87	22.73	21.28	51.19	50
6.6	23.11	22.91	21.49	51.19	50
6.7	23.45	23.26	21.70	51.19	50
6.8	23.57	23.42	21.92	51.19	50
6.9	23.89	23.79	22.19	51.19	50
7.0	24.11	23.98	22.26	51.19	50
7.1	24.51	24.33	22.49	51.19	50
7.2	24.69	24.49	22.65	51.19	50
7.3	24.88	24.64	22.82	51.19	50
7.4	24.95	24.80	23.08	51.19	50
7.5	25.03	24.95	23.33	51.19	50
7.6	25.27	25.18	23.73	51.19	50
7.7	25.45	25.26	23.87	51.19	50
7.8	25.84	25.55	24.19	51.19	50
7.9	26.06	25.77	24.38	51.19	50
8.0	26.28	25.99	24.73	51.19	50
8.1	26.41	26.14	24.91	51.19	50
8.2	26.53	26.30	25.08	51.19	50
8.3	26.86	26.62	25.17	51.19	50
8.4	27.05	26.79	25.25	51.19	50
8.5	27.44	27.13	25.45	51.19	50
8.6	27.64	27.31	25.57	51.19	50
8.7	27.92	27.48	25.93	51.19	50
8.8	28.01	27.64	26.18	51.19	50
8.9	28.10	27.80	26.43	51.19	50
9.0	28.29	28.15	26.61	51.19	50
9.1	28.47	28.35	26.78	51.19	50
9.2	28.88	28.68	27.11	51.19	50
9.3	29.09	28.82	27.25	51.19	50
9.4	29.45	29.09	27.56	51.19	50
9.5	29.59	29.23	27.73	51.19	50
9.6	29.73	29.36	27.89	51.19	50
9.7	29.93	29.51	27.97	51.19	50
9.8	30.14	29.66	28.06	51.19	50
9.9	30.56	29.95	28.28	51.19	50
10.0	30.78	30.10	28.42	51.19	50
10.1	31.09	30.38	28.81	51.19	50
10.2	31.17	30.53	29.05	51.19	50
10.3	31.26	30.87	29.50	51.19	50
10.4	31.45	31.07	29.70	51.19	50
10.5	31.65	31.27	29.90	51.19	50
10.6	32.07	31.39	30.03	51.19	50
10.7	32.30	31.50	30.17	51.19	50
10.8	32.66	31.76	30.45	51.19	50
10.9	32.79	31.91	30.61	51.19	50
11.0	33.15	32.19	30.84	51.19	50
11.1	33.37	32.34	30.92	51.19	50
11.2	33.60	32.48	31.14	51.19	50
11.3	33.80	32.63	31.27	51.19	50
11.4	33.99	32.77	31.41	51.19	50
11.5	34.29	33.07	31.66	51.19	50
11.6	34.38	33.21	31.91	51.19	50
11.7	34.67	33.56	32.37	51.19	50
11.8	34.86	33.75	32.58	51.19	50
11.9	35.05	33.95	32.93	51.19	50
12.0	35.26	34.05	33.08	51.19	50
12.1	35.48	34.15	33.22	51.19	50
12.2	35.81	34.39	33.35	51.19	50
12.3	35.92	34.54	33.49	51.19	50
12.4	36.23	34.82	33.71	51.19	50
12.5	36.42	34.96	33.81	51.19	50
12.6	36.77	35.26	34.05	51.19	50
12.7	36.93	35.42	34.20	51.19	50
12.8	37.09	35.58	34.35	51.19	50
12.9	37.17	35.75	34.59	51.19	50
13.0	37.26	35.91	34.84	51.19	50
13.1	37.53	36.27	35.29	51.19	50
13.2	37.71	36.45	35.49	51.19	50
13.3	38.11	36.79	35.84	51.19	50
13.4	38.31	36.94	35.99	51.19	50
13.5	38.52	37.29	36.28	51.19	50
13.6	38.73	37.48	36.42	51.19	50
13.7	38.94	37.68	36.57	51.19	50
13.8	39.31	37.77	36.65	51.19	50
13.9	39.46	37.87	36.72	51.19	50
14.0	39.80	38.14	36.94	51.19	50
14.1	39.99	38.31	37.07	51.19	50
14.2	40.17	38.71	37.45	51.19	50
14.3	40.29	38.94	37.69	51.19	50
14.4	40.42	39.16	37.93	51.19	50
14.5	40.71	39.26	38.13	51.19	50
14.6	40.87	39.37	38.34	51.19	50
14.7	41.28	39.50	38.66	51.19	50
14.8	41.52	39.52	38.77	51.19	50
14.9	41.99	39.79	39.00	51.19	50
15.0	42.21	40.04	39.10	51.19	50
15.1	42.44	40.43	39.21	51.19	50
15.2	42.61	40.58	39.26	51.19	50
15.3	42.79	40.73	39.30	51.19	50
15.4	43.16	40.91	39.48	51.19	50
15.5	43.37	41.10	39.61	51.19	50
15.6	43.72	41.53	39.94	51.19	50
15.7	43.86	41.78	40.14	51.19	50
15.8	44.20	42.16	40.54	51.19	50
15.9	44.40	42.30	40.75	51.19	50
16.0	44.59	42.61	40.95	51.19	50
16.1	44.85	42.79	41.07	51.19	50
16.2	45.11	42.97	41.18	51.19	50
16.3	45.60	43.22	41.42	51.19	50
16.4	45.84	43.46	41.53	51.19	50
16.5	46.26	43.84	41.70	51.19	50
16.6	46.45	43.97	41.76	51.19	50
16.7	46.64	44.28	41.95	51.19	50
16.8	46.81	44.45	42.08	51.19	50
16.9	46.97	44.63	42.22	51.19	50
17.0	47.27	44.88	42.47	51.19	50
17.1	47.40	45.12	42.71	51.19	50
17.2	47.68	45.47	43.20	51.19	50
17.3	47.84	45.58	43.44	51.19	50
17.4	48.27	45.88	43.84	51.19	50
17.5	48.54	46.09	44.00	51.19	50
17.6	48.82	46.53	44.16	51.19	50
17.7	49.03	46.78	44.34	51.19	50
17.8	49.24	47.02	44.51	51.19	50
17.9	49.66	47.14	44.77	51.19	50
18.0	49.86	47.27	44.84	51.19	50
18.1	50.27	47.51	45.20	51.19	50
18.2	50.48	47.64	45.47	51.19	50
18.3	50.68	48.03	45.75	51.19	50
18.4	50.82	48.30	45.91	51.19	50
18.5	50.96	48.57	46.08	51.19	50
18.6	51.10	48.72	46.49	51.19	50
18.7		48.88	46.74	51.19	50
18.8		49.19	47.21	51.19	50
18.9		49.36	47.42	51.19	50
19.0		49.73	47.72	51.19	50
19.1		49.94	47.81	51.19	50
19.2		50.15	47.95	51.19	50
19.3		50.29	48.00	51.19	50
19.4		50.42	48.15	51.19	50
19.5		50.68	48.24	51.19	50
19.6		50.80	48.48	51.19	50
19.7		51.19	48.64	51.19	50
19.8		51.47	48.92	51.19	50
19.9		51.88	49.06	51.19	50
20.0		52.01	49.19	51.19	50
20.1		52.15	49.20	51.19	50
20.2		52.15	49.22	51.19	50
20.3			49.35	51.19	50
20.4			49.47	51.19	50
20.5			49.72	51.19	50
20.6			49.85	51.19	50
20.7			49.98	51.19	50
20.8			50.10	51.19	50
20.9			50.21	51.19	50
21.0			50.33	51.19	50
