Daiwa JBraid Grand 30lb Braid
Daiwa’s premium braid goes to another level with the J-Braid Grand. A premium 8-strand PE, J-Braid Grand is made from an advanced raw material (IZANAS) and uses a technologically advanced construction method. J-Braid Grand is J-Braid’s strongest, most abrasion resistant line ever. Four times more abrasion resistant than other braided lines, J-Braid Grand has a best-in-class short pitch fibre construction that significantly reduces line damage and failure to dramatically increase abrasion resistance and straight-line pulling strength. A short pitch construction also aids in creating an even rounder profile for optimum line performance. Rounder profile braids tangle less and perform better, making J-Braid Grand our best performing J-Braid ever.
Made in Japan and available in sizes ranging from 6lb (0.6PE) to 120lb (PE12) in high-visibility island blue & depth-marked multicolour. J-Braid Grand is the smoothest and best performing J-Braid we’ve ever made.
Key Statistics
- Measured Diameter: .374mm (+133.5% on claimed .28mm)
- Measured Breaking Strain: 49.53lbs (+165% on claimed 30lbs)
- Abrasion Breaking Strain: 14.96lbs (30.2% of measured)
- Both Diameter and Breaking strain indicate that this is closer to a 50lb line, not 30lb. Abrasion resistance is slightly below average compared to others.
Testing Process
Key Line Statistics
Attribute | Value |
---|---|
Brand | Daiwa |
Name | JBraid Grand |
Web Site | Visit Website |
Rated Strength (lbs) | 30 |
Date Tested | 23 July 2022 |
Credit to | Line Laboratory |
Strands | 8 |
Cost $AUD | 34.99 |
Spool Quanity (m) | 135 |
Quoted Diameter (mm) | 0.28 |
Measured Average Diameter (mm) | 0.374 |
Diameter Quoted vs Measured (%) | 133.57 |
Minimum Diameter (mm) | 0.364 |
Maximum Diameter (mm) | 0.388 |
Break Max Average (lbs) | 49.53 |
Claimed vs Actual Breaking Strain (%) | 165.11 |
Tensile Strength (PSI) | 290873 |
Tensile Rank | 56 |
Abrasion Break Max Average (lbs) | 14.96 |
Abrasion Break vs Max Break Strain (%) | 30.2 |
Abrasion Tensile Strength PSI | 87855 |
Abrasion Tensile Rank | 57 |
FG Break Max Average (lbs) | 0 |
FG Break vs Max Break Strain (%) | 0 |
FG Tensile Strength PSI | 0 |
FG Tensile Rank | 63 |
Time | Test1 | Test2 | Test3 | Rated |
---|---|---|---|---|
0,00 | 0,47 | 0,22 | 0,18 | 30 |
0,10 | 0,47 | 0,41 | 0,36 | 30 |
0,20 | 0,85 | 0,59 | 0,55 | 30 |
0,30 | 1,22 | 1,17 | 1,10 | 30 |
0,40 | 1,90 | 1,56 | 1,46 | 30 |
0,50 | 2,19 | 2,36 | 1,83 | 30 |
0,60 | 2,93 | 2,77 | 2,23 | 30 |
0,70 | 3,37 | 3,18 | 2,64 | 30 |
0,80 | 4,24 | 3,47 | 3,33 | 30 |
0,90 | 4,66 | 3,76 | 3,62 | 30 |
1,00 | 5,09 | 4,49 | 4,32 | 30 |
1,10 | 5,36 | 4,94 | 4,73 | 30 |
1,20 | 5,63 | 5,77 | 5,14 | 30 |
1,30 | 6,29 | 6,15 | 5,54 | 30 |
1,40 | 6,68 | 6,54 | 5,93 | 30 |
1,50 | 7,40 | 6,80 | 6,59 | 30 |
1,60 | 7,74 | 7,05 | 6,85 | 30 |
1,70 | 8,07 | 7,68 | 7,50 | 30 |
1,80 | 8,27 | 8,06 | 7,90 | 30 |
1,90 | 8,46 | 8,81 | 8,66 | 30 |
2,00 | 8,94 | 9,20 | 9,02 | 30 |
2,10 | 9,23 | 9,82 | 9,39 | 30 |
2,20 | 9,79 | 10,07 | 9,61 | 30 |
2,30 | 10,07 | 10,31 | 9,83 | 30 |
2,40 | 10,54 | 10,64 | 10,42 | 30 |
2,50 | 10,74 | 10,97 | 10,79 | 30 |
2,60 | 10,93 | 11,56 | 11,53 | 30 |
2,70 | 11,21 | 11,81 | 11,89 | 30 |
2,80 | 11,48 | 12,37 | 12,26 | 30 |
2,90 | 12,03 | 12,67 | 12,45 | 30 |
3,00 | 12,30 | 12,97 | 12,65 | 30 |
3,10 | 12,75 | 13,14 | 13,12 | 30 |
3,20 | 12,92 | 13,31 | 13,40 | 30 |
3,30 | 13,10 | 13,73 | 13,93 | 30 |
3,40 | 13,37 | 13,99 | 14,17 | 30 |
3,50 | 13,63 | 14,53 | 14,58 | 30 |
3,60 | 14,16 | 14,81 | 14,75 | 30 |
3,70 | 14,41 | 15,10 | 14,91 | 30 |
3,80 | 14,84 | 15,26 | 15,21 | 30 |
3,90 | 15,00 | 15,41 | 15,51 | 30 |
4,00 | 15,17 | 15,77 | 16,10 | 30 |
4,10 | 15,41 | 15,96 | 16,38 | 30 |
4,20 | 15,66 | 16,41 | 16,82 | 30 |
4,30 | 16,13 | 16,66 | 16,97 | 30 |
4,40 | 16,37 | 17,05 | 17,12 | 30 |
4,50 | 16,75 | 17,20 | 17,36 | 30 |
4,60 | 16,90 | 17,34 | 17,61 | 30 |
4,70 | 17,29 | 17,57 | 18,05 | 30 |
4,80 | 17,53 | 17,80 | 18,24 | 30 |
4,90 | 17,77 | 18,28 | 18,56 | 30 |
5,00 | 17,99 | 18,52 | 18,69 | 30 |
5,10 | 18,20 | 18,93 | 19,06 | 30 |
5,20 | 18,58 | 19,08 | 19,32 | 30 |
5,30 | 18,75 | 19,24 | 19,57 | 30 |
5,40 | 19,13 | 19,45 | 19,78 | 30 |
5,50 | 19,36 | 19,67 | 20,00 | 30 |
5,60 | 19,58 | 20,12 | 20,36 | 30 |
5,70 | 19,77 | 20,36 | 20,50 | 30 |
5,80 | 19,97 | 20,72 | 20,88 | 30 |
5,90 | 20,36 | 20,84 | 21,12 | 30 |
6,00 | 20,56 | 21,17 | 21,50 | 30 |
6,10 | 20,94 | 21,39 | 21,66 | 30 |
6,20 | 21,13 | 21,60 | 21,81 | 30 |
6,30 | 21,53 | 21,83 | 21,93 | 30 |
6,40 | 21,76 | 22,05 | 22,06 | 30 |
6,50 | 22,20 | 22,42 | 22,42 | 30 |
6,60 | 22,42 | 22,56 | 22,66 | 30 |
6,70 | 22,64 | 22,88 | 23,09 | 30 |
6,80 | 22,79 | 23,07 | 23,29 | 30 |
6,90 | 22,93 | 23,25 | 23,48 | 30 |
7,00 | 23,27 | 23,51 | 23,68 | 30 |
7,10 | 23,45 | 23,76 | 23,88 | 30 |
7,20 | 23,85 | 24,13 | 24,25 | 30 |
7,30 | 24,06 | 24,23 | 24,41 | 30 |
7,40 | 24,27 | 24,54 | 24,72 | 30 |
7,50 | 24,44 | 24,75 | 24,86 | 30 |
7,60 | 24,62 | 25,17 | 25,00 | 30 |
7,70 | 25,02 | 25,39 | 25,23 | 30 |
7,80 | 25,25 | 25,61 | 25,45 | 30 |
7,90 | 25,70 | 25,74 | 25,81 | 30 |
8,00 | 25,91 | 25,87 | 25,94 | 30 |
8,10 | 26,29 | 26,19 | 26,26 | 30 |
8,20 | 26,44 | 26,39 | 26,46 | 30 |
8,30 | 26,60 | 26,76 | 26,85 | 30 |
8,40 | 26,79 | 26,93 | 27,05 | 30 |
8,50 | 26,97 | 27,24 | 27,25 | 30 |
8,60 | 27,36 | 27,36 | 27,41 | 30 |
8,70 | 27,57 | 27,49 | 27,57 | 30 |
8,80 | 27,93 | 27,69 | 27,86 | 30 |
8,90 | 28,09 | 27,90 | 28,00 | 30 |
9,00 | 28,25 | 28,33 | 28,35 | 30 |
9,10 | 28,41 | 28,56 | 28,58 | 30 |
9,20 | 28,58 | 28,93 | 28,95 | 30 |
9,30 | 28,96 | 29,06 | 29,10 | 30 |
9,40 | 29,19 | 29,39 | 29,25 | 30 |
9,50 | 29,58 | 29,58 | 29,44 | 30 |
9,60 | 29,74 | 29,77 | 29,64 | 30 |
9,70 | 29,91 | 30,00 | 30,01 | 30 |
9,80 | 30,07 | 30,22 | 30,20 | 30 |
9,90 | 30,22 | 30,56 | 30,54 | 30 |
10,00 | 30,61 | 30,68 | 30,70 | 30 |
10,10 | 30,83 | 30,99 | 30,86 | 30 |
10,20 | 31,16 | 31,18 | 30,99 | 30 |
10,30 | 31,27 | 31,62 | 31,11 | 30 |
10,40 | 31,59 | 31,85 | 31,37 | 30 |
10,50 | 31,80 | 32,09 | 31,50 | 30 |
10,60 | 32,02 | 32,23 | 31,86 | 30 |
10,70 | 32,19 | 32,37 | 32,09 | 30 |
10,80 | 32,36 | 32,68 | 32,32 | 30 |
10,90 | 32,68 | 32,86 | 32,51 | 30 |
11,00 | 32,82 | 33,23 | 32,70 | 30 |
11,10 | 33,12 | 33,42 | 33,12 | 30 |
11,20 | 33,26 | 33,62 | 33,34 | 30 |
11,30 | 33,41 | 33,77 | 33,74 | 30 |
11,40 | 33,65 | 33,93 | 33,90 | 30 |
11,50 | 33,88 | 34,28 | 34,22 | 30 |
11,60 | 34,23 | 34,47 | 34,37 | 30 |
11,70 | 34,35 | 34,83 | 34,52 | 30 |
11,80 | 34,70 | 35,00 | 34,69 | 30 |
11,90 | 34,94 | 35,36 | 34,85 | 30 |
12,00 | 35,32 | 35,56 | 35,16 | 30 |
12,10 | 35,46 | 35,76 | 35,29 | 30 |
12,20 | 35,60 | 35,85 | 35,61 | 30 |
12,30 | 35,75 | 35,95 | 35,78 | 30 |
12,40 | 35,89 | 36,26 | 36,15 | 30 |
12,50 | 36,18 | 36,48 | 36,35 | 30 |
12,60 | 36,33 | 36,89 | 36,54 | 30 |
12,70 | 36,72 | 37,09 | 36,71 | 30 |
12,80 | 36,96 | 37,28 | 36,89 | 30 |
12,90 | 37,21 | 37,43 | 37,23 | 30 |
13,00 | 37,27 | 37,58 | 37,40 | 30 |
13,10 | 37,34 | 37,91 | 37,71 | 30 |
13,20 | 37,68 | 38,08 | 37,84 | 30 |
13,30 | 37,95 | 38,50 | 37,98 | 30 |
13,40 | 38,37 | 38,75 | 38,12 | 30 |
13,50 | 38,50 | 38,99 | 38,25 | 30 |
13,60 | 38,64 | 39,08 | 38,58 | 30 |
13,70 | 38,76 | 39,18 | 38,77 | 30 |
13,80 | 38,89 | 39,49 | 39,17 | 30 |
13,90 | 39,15 | 39,71 | 39,38 | 30 |
14,00 | 39,28 | 40,13 | 39,70 | 30 |
14,10 | 39,66 | 40,32 | 39,80 | 30 |
14,20 | 39,91 | 40,69 | 39,91 | 30 |
14,30 | 40,23 | 40,86 | 40,17 | 30 |
14,40 | 40,31 | 41,03 | 40,42 | 30 |
14,50 | 40,39 | 41,18 | 40,74 | 30 |
14,60 | 40,62 | 41,34 | 40,81 | 30 |
14,70 | 40,86 | 41,74 | 41,04 | 30 |
14,80 | 41,11 | 41,98 | 41,21 | 30 |
14,90 | 41,12 | 42,38 | 41,38 | 30 |
15,00 | 41,22 | 42,53 | 41,58 | 30 |
15,10 | 41,31 | 42,87 | 41,79 | 30 |
15,20 | 41,39 | 43,06 | 42,21 | 30 |
15,30 | 41,42 | 43,25 | 42,42 | 30 |
15,40 | 41,46 | 43,40 | 42,81 | 30 |
15,50 | 41,74 | 43,55 | 42,99 | 30 |
15,60 | 41,98 | 43,86 | 43,43 | 30 |
15,70 | 42,41 | 44,01 | 43,70 | 30 |
15,80 | 42,59 | 44,39 | 43,97 | 30 |
15,90 | 42,94 | 44,60 | 44,07 | 30 |
16,00 | 43,10 | 44,98 | 44,18 | 30 |
16,10 | 43,27 | 45,13 | 44,42 | 30 |
16,20 | 43,37 | 45,29 | 44,56 | 30 |
16,30 | 43,46 | 45,41 | 44,88 | 30 |
16,40 | 43,72 | 45,53 | 45,05 | 30 |
16,50 | 43,87 | 45,80 | 45,45 | 30 |
16,60 | 44,08 | 45,96 | 45,68 | 30 |
16,70 | 44,13 | 46,25 | 45,90 | 30 |
16,80 | 44,40 | 46,39 | 46,07 | 30 |
16,90 | 44,62 | 46,53 | 46,24 | 30 |
17,00 | 44,84 | 46,67 | 46,69 | 30 |
17,10 | 45,09 | 46,82 | 46,97 | 30 |
17,20 | 45,34 | 47,19 | 47,31 | 30 |
17,30 | 45,78 | 47,41 | 47,38 | 30 |
17,40 | 45,98 | 47,83 | 47,44 | 30 |
17,50 | 46,17 | 48,01 | 47,60 | 30 |
17,60 | 48,34 | 47,75 | 30 | |
17,70 | 48,47 | 48,12 | 30 | |
17,80 | 48,61 | 48,32 | 30 | |
17,90 | 48,83 | 48,75 | 30 | |
18,00 | 49,05 | 48,96 | 30 | |
18,10 | 49,45 | 49,36 | 30 | |
18,20 | 49,63 | 49,53 | 30 | |
18,30 | 49,97 | 49,71 | 30 | |
18,40 | 50,14 | 49,98 | 30 | |
18,50 | 50,30 | 50,26 | 30 | |
18,60 | 50,50 | 50,62 | 30 | |
18,70 | 50,69 | 50,71 | 30 | |
18,80 | 51,00 | 50,89 | 30 | |
18,90 | 51,12 | 50,98 | 30 | |
19,00 | 51,25 | 51,07 | 30 | |
19,10 | 51,27 | 51,07 | 30 | |
19,20 | 51,29 | 30 | ||
19,30 | 51,31 | 30 | ||
19,40 | 51,34 | 30 | ||
19,50 | 51,36 | 30 |
