Daiwa JThread X-Link : 20lb Fluorocarbon

DAIWA J-THREAD FC X-LINK FLUOROCARBON LEADER

J-Thread FC X-Link (Cross Link) FC is a totally revolutionary fluorocarbon line developed exclusively by Daiwa.

The X-Link process is a game-changer for the fishing line industry. The X-Link method alters the molecular structure of the line itself, bonding individual particles on a chemical level. This change in the chemical composition results in a line which is much stronger for its given diameter. The X-Link method also produces a line which is incredibly limp and supple, resulting in a more manageable line and a much higher knot retention.

J-Thread FC X-Link is made in Japan and sets a new benchmark for leader material in Australia.

https://daiwafishing.com.au/products/j-thread-x-link-fluorocarbon-leader

Measured Diameter: .375mm (-1.83% on claimed .382mm)
Measured Breaking Strain: 24.78lbs (+123.9% on claimed 20lbs)
Abrasion Breaking Strain: 10.98lbs (44.3% of measured max break)

Breaking strain indicates that this line is slightly underrated.

Tensile Strength (144749psi) is EXCEPTIONAL, ranks No: 1

Abrasion resistance as a percentage of maximum break is BELOW average @ 44.3% (average 56%).

Testing Process

Key Line Statistics

Attribute	Value
Brand	Daiwa
Name	JThread FC X-Link
Web Site	Visit Website
Rated Strength (lbs)	20
Date Tested	30 December 2022
Credit to	Line Laboratory
Strands	1
Cost $AUD	24.95
Spool Quanity (m)	50
Quoted Diameter (mm)	0.382
Measured Average Diameter (mm)	0.375
Diameter Quoted vs Measured (%)	98.17
Minimum Diameter (mm)	0.371
Maximum Diameter (mm)	0.38
Break Max Average (lbs)	24.78
Claimed vs Actual Breaking Strain (%)	123.88
Average Stretch @ Maximum Break	N/A
Tensile Strength (PSI)	144492
Tensile Rank	2
Abrasion Break Max Average (lbs)	10.98
Abrasion Break vs Max Break Strain (%)	44.31
Abrasion % of Maximum Rank	12
Abrasion Tensile Strength PSI	64024
Abrasion Tensile Rank	5
FG Break Max Average (lbs)	0
FG Break vs Max Break Strain (%)	0
FG % of Maximum Rank	7
FG Tensile Strength PSI	0
FG Tensile Rank	7

Time	Test1	Test2	Test3	Average	Rated
0.0	0.00	0.00	0.00	24.78	20
0.1	0.28	0.20	0.23	24.78	20
0.2	0.53	0.30	0.34	24.78	20
0.3	0.63	0.39	0.45	24.78	20
0.4	0.74	0.49	0.56	24.78	20
0.5	0.88	0.72	0.82	24.78	20
0.6	1.02	0.85	0.97	24.78	20
0.7	1.28	1.12	1.26	24.78	20
0.8	1.40	1.24	1.39	24.78	20
0.9	1.59	1.37	1.61	24.78	20
1.0	1.66	1.45	1.70	24.78	20
1.1	1.73	1.52	1.78	24.78	20
1.2	1.83	1.71	1.89	24.78	20
1.3	1.93	1.82	2.01	24.78	20
1.4	2.13	2.04	2.22	24.78	20
1.5	2.23	2.14	2.33	24.78	20
1.6	2.40	2.32	2.50	24.78	20
1.7	2.46	2.38	2.56	24.78	20
1.8	2.63	2.45	2.63	24.78	20
1.9	2.73	2.55	2.73	24.78	20
2.0	2.83	2.66	2.84	24.78	20
2.1	2.93	2.86	3.05	24.78	20
2.2	3.02	2.97	3.15	24.78	20
2.3	3.19	3.14	3.33	24.78	20
2.4	3.26	3.21	3.39	24.78	20
2.5	3.44	3.28	3.46	24.78	20
2.6	3.54	3.39	3.57	24.78	20
2.7	3.65	3.51	3.67	24.78	20
2.8	3.75	3.73	3.89	24.78	20
2.9	3.85	3.84	3.99	24.78	20
3.0	4.02	4.03	4.17	24.78	20
3.1	4.10	4.10	4.25	24.78	20
3.2	4.28	4.30	4.44	24.78	20
3.3	4.38	4.42	4.55	24.78	20
3.4	4.59	4.54	4.67	24.78	20
3.5	4.70	4.66	4.79	24.78	20
3.6	4.80	4.78	4.91	24.78	20
3.7	4.87	4.97	5.10	24.78	20
3.8	4.94	5.05	5.18	24.78	20
3.9	5.12	5.25	5.37	24.78	20
4.0	5.24	5.37	5.49	24.78	20
4.1	5.46	5.50	5.71	24.78	20
4.2	5.57	5.62	5.82	24.78	20
4.3	5.68	5.74	5.92	24.78	20
4.4	5.76	5.94	6.00	24.78	20
4.5	5.83	6.03	6.07	24.78	20
4.6	6.02	6.23	6.25	24.78	20
4.7	6.13	6.36	6.36	24.78	20
4.8	6.34	6.60	6.57	24.78	20
4.9	6.45	6.72	6.68	24.78	20
5.0	6.63	6.84	6.79	24.78	20
5.1	6.71	6.91	6.86	24.78	20
5.2	6.79	6.99	6.94	24.78	20
5.3	6.90	7.18	7.12	24.78	20
5.4	7.00	7.31	7.24	24.78	20
5.5	7.22	7.54	7.45	24.78	20
5.6	7.33	7.66	7.56	24.78	20
5.7	7.51	7.77	7.73	24.78	20
5.8	7.58	7.84	7.81	24.78	20
5.9	7.76	7.91	7.88	24.78	20
6.0	7.86	8.10	7.99	24.78	20
6.1	7.97	8.22	8.11	24.78	20
6.2	8.07	8.45	8.33	24.78	20
6.3	8.18	8.55	8.43	24.78	20
6.4	8.36	8.75	8.62	24.78	20
6.5	8.43	8.84	8.70	24.78	20
6.6	8.62	8.93	8.78	24.78	20
6.7	8.74	9.01	8.89	24.78	20
6.8	8.85	9.09	8.99	24.78	20
6.9	8.97	9.27	9.20	24.78	20
7.0	9.09	9.38	9.29	24.78	20
7.1	9.28	9.58	9.45	24.78	20
7.2	9.36	9.69	9.52	24.78	20
7.3	9.54	9.79	9.68	24.78	20
7.4	9.66	9.86	9.79	24.78	20
7.5	9.77	9.94	9.89	24.78	20
7.6	9.86	10.11	9.99	24.78	20
7.7	9.95	10.21	10.08	24.78	20
7.8	10.12	10.40	10.24	24.78	20
7.9	10.20	10.49	10.31	24.78	20
8.0	10.39	10.58	10.46	24.78	20
8.1	10.51	10.65	10.54	24.78	20
8.2	10.73	10.73	10.63	24.78	20
8.3	10.84	10.90	10.72	24.78	20
8.4	10.95	11.01	10.80	24.78	20
8.5	11.03	11.22	10.95	24.78	20
8.6	11.10	11.33	11.01	24.78	20
8.7	11.28	11.51	11.17	24.78	20
8.8	11.39	11.58	11.27	24.78	20
8.9	11.58	11.65	11.47	24.78	20
9.0	11.67	11.75	11.56	24.78	20
9.1	11.76	11.85	11.66	24.78	20
9.2	11.83	12.04	11.73	24.78	20
9.3	11.91	12.14	11.79	24.78	20
9.4	12.09	12.30	11.96	24.78	20
9.5	12.19	12.37	12.07	24.78	20
9.6	12.41	12.53	12.26	24.78	20
9.7	12.51	12.63	12.35	24.78	20
9.8	12.69	12.72	12.44	24.78	20
9.9	12.76	12.82	12.50	24.78	20
10.0	12.83	12.93	12.56	24.78	20
10.1	12.93	13.09	12.71	24.78	20
10.2	13.04	13.16	12.80	24.78	20
10.3	13.22	13.32	12.98	24.78	20
10.4	13.30	13.41	13.08	24.78	20
10.5	13.46	13.51	13.24	24.78	20
10.6	13.53	13.59	13.30	24.78	20
10.7	13.72	13.68	13.37	24.78	20
10.8	13.83	13.83	13.46	24.78	20
10.9	13.94	13.89	13.55	24.78	20
11.0	14.05	14.05	13.72	24.78	20
11.1	14.15	14.14	13.81	24.78	20
11.2	14.34	14.32	13.95	24.78	20
11.3	14.41	14.41	14.01	24.78	20
11.4	14.59	14.50	14.07	24.78	20
11.5	14.69	14.56	14.16	24.78	20
11.6	14.79	14.63	14.24	24.78	20
11.7	14.86	14.78	14.42	24.78	20
11.8	14.93	14.87	14.51	24.78	20
11.9	15.07	15.06	14.66	24.78	20
12.0	15.14	15.16	14.72	24.78	20
12.1	15.32	15.26	14.87	24.78	20
12.2	15.42	15.32	14.96	24.78	20
12.3	15.53	15.37	15.05	24.78	20
12.4	15.64	15.49	15.13	24.78	20
12.5	15.74	15.56	15.22	24.78	20
12.6	15.91	15.73	15.35	24.78	20
12.7	15.98	15.84	15.39	24.78	20
12.8	16.14	16.01	15.53	24.78	20
12.9	16.24	16.06	15.62	24.78	20
13.0	16.41	16.12	15.71	24.78	20
13.1	16.49	16.20	15.80	24.78	20
13.2	16.56	16.28	15.88	24.78	20
13.3	16.66	16.47	16.05	24.78	20
13.4	16.75	16.59	16.13	24.78	20
13.5	16.91	16.74	16.29	24.78	20
13.6	16.98	16.77	16.36	24.78	20
13.7	17.14	16.81	16.53	24.78	20
13.8	17.25	16.84	16.61	24.78	20
13.9	17.44	16.86	16.70	24.78	20
14.0	17.54	17.04	16.73	24.78	20
14.1	17.63	17.20	16.77	24.78	20
14.2	17.71	17.38	16.90	24.78	20
14.3	17.78	17.40	17.00	24.78	20
14.4	17.92	17.56	17.18	24.78	20
14.5	17.98	17.68	17.26	24.78	20
14.6	18.13	17.81	17.34	24.78	20
14.7	18.21	17.86	17.39	24.78	20
14.8	18.30	17.92	17.43	24.78	20
14.9	18.35	18.02	17.57	24.78	20
15.0	18.41	18.06	17.65	24.78	20
15.1	18.55	18.22	17.81	24.78	20
15.2	18.65	18.34	17.89	24.78	20
15.3	18.83	18.53	18.02	24.78	20
15.4	18.92	18.60	18.07	24.78	20
15.5	19.09	18.68	18.13	24.78	20
15.6	19.17	18.77	18.23	24.78	20
15.7	19.25	18.85	18.32	24.78	20
15.8	19.32	19.01	18.49	24.78	20
15.9	19.38	19.08	18.57	24.78	20
16.0	19.53	19.24	18.71	24.78	20
16.1	19.61	19.34	18.77	24.78	20
16.2	19.74	19.43	18.84	24.78	20
16.3	19.80	19.43	18.91	24.78	20
16.4	19.85	19.44	18.97	24.78	20
16.5	19.94	19.56	19.12	24.78	20
16.6	20.02	19.69	19.21	24.78	20
16.7	20.19	19.88	19.34	24.78	20
16.8	20.27	19.95	19.38	24.78	20
16.9	20.41	20.02	19.51	24.78	20
17.0	20.48	20.11	19.60	24.78	20
17.1	20.54	20.20	19.68	24.78	20
17.2	20.62	20.36	19.76	24.78	20
17.3	20.69	20.44	19.83	24.78	20
17.4	20.83	20.59	19.98	24.78	20
17.5	20.88	20.68	20.05	24.78	20
17.6	21.01	20.79	20.19	24.78	20
17.7	21.07	20.81	20.26	24.78	20
17.8	21.22	20.84	20.33	24.78	20
17.9	21.31	20.92	20.40	24.78	20
18.0	21.39	20.99	20.48	24.78	20
18.1	21.47	21.16	20.59	24.78	20
18.2	21.55	21.26	20.63	24.78	20
18.3	21.68	21.42	20.75	24.78	20
18.4	21.73	21.50	20.84	24.78	20
18.5	21.86	21.57	20.92	24.78	20
18.6	21.94	21.64	20.99	24.78	20
18.7	22.02	21.71	21.07	24.78	20
18.8	22.06	21.88	21.21	24.78	20
18.9	22.11	21.98	21.27	24.78	20
19.0	22.22	22.09	21.41	24.78	20
19.1	22.29	22.11	21.49	24.78	20
19.2	22.44	22.22	21.63	24.78	20
19.3	22.51	22.31	21.70	24.78	20
19.4	22.68	22.41	21.77	24.78	20
19.5	22.77	22.46	21.80	24.78	20
19.6	22.86	22.51	21.84	24.78	20
19.7	22.90	22.63	21.95	24.78	20
19.8	22.94	22.70	22.03	24.78	20
19.9	23.06	22.83	22.18	24.78	20
20.0	23.14	22.90	22.24	24.78	20
20.1	23.26	22.96	22.31	24.78	20
20.2	23.30	23.07	22.40	24.78	20
20.3	23.39	23.18	22.50	24.78	20
20.4	23.43	23.31	22.63	24.78	20
20.5	23.48	23.33	22.67	24.78	20
20.6	23.57	23.41	22.78	24.78	20
20.7	23.65	23.48	22.85	24.78	20
20.8	23.82	23.60	22.97	24.78	20
20.9	23.89	23.67	23.03	24.78	20
21.0	24.00	23.73	23.08	24.78	20
21.1	24.04	23.78	23.13	24.78	20
21.2	24.07	23.82	23.17	24.78	20
21.3	24.15	23.95	23.28	24.78	20
21.4	24.23	24.02	23.35	24.78	20
21.5	24.34	24.17	23.49	24.78	20
21.6	24.36	24.25	23.58	24.78	20
21.7	24.42	24.32	23.70	24.78	20
21.8	24.45	24.35	23.75	24.78	20
21.9	24.55	24.39	23.79	24.78	20
22.0	24.63	24.48	23.79	24.78	20
22.1	24.70	24.54		24.78	20
22.2	24.78	24.65		24.78	20
22.3	24.86	24.69		24.78	20
22.4	24.94	24.77		24.78	20
22.5		24.81		24.78	20
22.6		24.84		24.78	20
22.7		24.92		24.78	20
22.8		25.01		24.78	20
22.9		25.13		24.78	20
23.0		25.16		24.78	20
23.1		25.23		24.78	20
23.2		25.25		24.78	20
23.3		25.28		24.78	20
23.4		25.32		24.78	20
23.5		25.35		24.78	20
23.6		25.44		24.78	20
23.7		25.49		24.78	20
23.8		25.56		24.78	20
23.9		25.58		24.78	20
24.0		25.60		24.78	20
