Daiwa Tournament EVO : PE8 - Line Laboratory

Daiwa Tournament EVO : PE8 Braid

Description

TOURNAMENT 8 BRAID EVO line to significantly improves abrasion resistance and offers high strength.

8 strand braided line.
Round profile.
Extra high abrasion resistance.
Super smooth surface coating.
Super soft & flexible.
No stretch.

Summary

- Measured Ave Diameter: 0.506mm (112.44% of claimed diameter)
- Out of Roundness: 0.048mm (9.48% variation in diameter)
- Measured Maximum Break: 106.81 lbs (133.51% of claimed 80 lbs)
- Measured Stretch @ Break: 2.93%
- Abrasion Maximum Break: 38.66 lbs (36.2% of max break)
- FG Knot Maximum Break: 78.89 lbs (73.86% of max break)

Testing Process

Key Line Statistics

Attribute	Value
Brand	Daiwa
Name	Evo Tournament PE8
Web Site	Visit Website
Rated Strength (lbs)	80
Date Tested	12 December 2025
Credit to	Line Laboratory
Strands	8
Cost $AUD	59.99
Spool Quanity (m)	300
Quoted Diameter (mm)	0.45
Measured Average Diameter (mm)	0.506
Diameter Quoted vs Measured (%)	112.44
Minimum Diameter (mm)	0.475
Maximum Diameter (mm)	0.523
Break Max Average (lbs)	106.81
Claimed vs Actual Maximum Break (%)	133.51
Average Stretch @ Maximum Break	2.93%
Tensile Strength (PSI)	342238
Tensile Rank	72
Abrasion Break Max Average (lbs)	38.66
Abrasion Break vs Max Break (%)	36.2
Abrasion % of Maximum Rank	54
Abrasion Tensile Strength PSI	123873
Abrasion Tensile Rank	51
FG Break Max Average (lbs)	78.89
FG Break vs Max Break (%)	73.86
FG % of Maximum Rank	69
FG Tensile Strength PSI	252777
FG Tensile Rank	51

StrainSummary	Test 1	Test 2	Test 3	Average	Rated
0.01	0.84	0.82	0.76	106.81	80
0.03	1.20	1.29	1.27	106.81	80
0.05	1.38	1.69	1.72	106.81	80
0.06	1.73	1.89	2.15	106.81	80
0.08	2.06	2.30	2.58	106.81	80
0.09	2.58	3.12	3.01	106.81	80
0.11	2.58	3.98	3.69	106.81	80
0.14	3.55	4.69	4.17	106.81	80
0.16	4.19	5.70	4.65	106.81	80
0.17	4.64	6.23	5.15	106.81	80
0.19	5.13	6.77	5.94	106.81	80
0.20	5.62	7.04	6.47	106.81	80
0.22	6.12	7.32	7.02	106.81	80
0.24	6.36	8.12	8.15	106.81	80
0.26	6.85	8.95	9.24	106.81	80
0.27	7.34	9.22	10.08	106.81	80
0.29	7.58	9.74	10.63	106.81	80
0.30	8.32	10.28	11.19	106.81	80
0.32	8.56	10.85	11.74	106.81	80
0.33	9.05	11.44	12.03	106.81	80
0.35	9.30	11.74	12.62	106.81	80
0.37	9.81	12.03	13.23	106.81	80
0.39	10.61	12.92	13.83	106.81	80
0.40	11.19	13.51	14.46	106.81	80
0.42	12.03	14.12	15.11	106.81	80
0.44	12.61	14.75	15.45	106.81	80
0.46	13.16	15.68	16.09	106.81	80
0.50	14.02	16.61	16.76	106.81	80
0.52	15.20	17.91	17.41	106.81	80
0.53	15.82	18.62	18.06	106.81	80
0.55	16.47	19.30	18.71	106.81	80
0.56	17.12	19.95	19.05	106.81	80
0.58	17.75	20.60	19.70	106.81	80
0.59	18.37	20.92	20.36	106.81	80
0.61	18.97	21.24	21.00	106.81	80
0.63	19.28	22.16	21.62	106.81	80
0.65	19.88	22.82	22.22	106.81	80
0.66	20.47	23.40	22.82	106.81	80
0.68	21.09	23.98	23.13	106.81	80
0.69	21.67	24.61	23.72	106.81	80
0.72	22.57	24.92	24.29	106.81	80
0.75	23.80	25.21	24.89	106.81	80
0.76	24.12	26.17	25.47	106.81	80
0.78	24.45	26.82	26.37	106.81	80
0.79	25.09	27.44	27.96	106.81	80
0.81	26.06	28.10	28.27	106.81	80
0.82	26.68	28.74	28.89	106.81	80
0.84	27.28	29.05	29.51	106.81	80
0.85	27.90	30.31	30.12	106.81	80
0.87	28.21	30.96	30.42	106.81	80
0.89	28.79	31.62	31.03	106.81	80
0.90	29.70	32.99	31.61	106.81	80
0.92	30.00	34.02	32.23	106.81	80
0.94	30.63	34.66	32.88	106.81	80
0.95	31.29	35.28	33.18	106.81	80
0.97	31.94	35.90	33.81	106.81	80
0.98	32.58	36.21	34.47	106.81	80
1.00	32.90	36.84	35.10	106.81	80
1.02	33.53	37.44	35.73	106.81	80
1.03	34.14	38.03	36.33	106.81	80
1.05	34.75	38.34	36.65	106.81	80
1.07	35.64	39.31	37.29	106.81	80
1.08	36.28	39.63	37.91	106.81	80
1.11	36.91	40.28	38.54	106.81	80
1.13	38.18	40.92	39.20	106.81	80
1.14	38.49	41.56	39.85	106.81	80
1.16	39.11	42.22	40.86	106.81	80
1.18	39.43	42.53	42.16	106.81	80
1.20	40.38	43.19	43.41	106.81	80
1.21	40.98	43.82	44.04	106.81	80
1.23	41.62	45.15	44.36	106.81	80
1.24	41.93	46.52	44.99	106.81	80
1.26	42.22	47.23	45.60	106.81	80
1.27	43.15	47.60	46.25	106.81	80
1.29	43.79	47.97	46.94	106.81	80
1.30	44.44	49.06	47.29	106.81	80
1.32	45.12	49.74	47.65	106.81	80
1.33	45.46	50.38	48.71	106.81	80
1.36	46.17	51.03	49.40	106.81	80
1.37	47.13	51.35	50.06	106.81	80
1.39	47.45	51.99	50.71	106.81	80
1.40	47.75	52.65	51.04	106.81	80
1.42	48.73	53.30	51.36	106.81	80
1.43	49.40	53.94	52.64	106.81	80
1.45	50.41	54.27	52.97	106.81	80
1.47	51.07	54.95	53.60	106.81	80
1.50	51.74	55.60	53.93	106.81	80
1.52	52.74	56.92	54.88	106.81	80
1.53	53.35	57.93	55.21	106.81	80
1.55	53.99	58.92	56.12	106.81	80
1.56	54.60	59.23	56.77	106.81	80
1.58	55.23	59.89	57.09	106.81	80
1.59	55.86	60.56	57.75	106.81	80
1.61	56.17	61.24	58.41	106.81	80
1.63	56.48	61.96	59.06	106.81	80
1.64	57.45	62.66	60.72	106.81	80
1.66	57.89	63.01	61.32	106.81	80
1.68	58.50	63.68	61.99	106.81	80
1.69	59.26	64.34	62.67	106.81	80
1.71	59.98	64.67	63.01	106.81	80
1.72	60.33	65.35	63.35	106.81	80
1.74	61.05	66.00	64.37	106.81	80
1.76	61.73	66.65	65.07	106.81	80
1.78	62.45	67.24	65.73	106.81	80
1.79	63.15	67.81	66.05	106.81	80
1.81	63.81	68.49	67.03	106.81	80
1.82	64.49	69.20	67.36	106.81	80
1.85	65.47	69.92	68.00	106.81	80
1.87	65.48	70.28	68.65	106.81	80
1.88	65.96	70.97	69.18	106.81	80
1.91	66.53	71.69	69.33	106.81	80
1.92	66.82	72.39	69.63	106.81	80
1.94	67.34	73.08	70.00	106.81	80
1.95	67.67	73.41	71.12	106.81	80
1.97	67.96	74.84	71.80	106.81	80
1.98	68.39	76.08	73.24	106.81	80
2.00	68.72	76.08	74.27	106.81	80
2.01	68.84	76.22	74.95	106.81	80
2.03	69.01	78.00	75.60	106.81	80
2.05	70.20	78.70	76.27	106.81	80
2.07	71.11	79.36	76.91	106.81	80
2.08	71.91	79.65	77.52	106.81	80
2.10	72.28	80.26	77.99	106.81	80
2.11	73.03	80.50	77.67	106.81	80
2.13	73.41	80.66	77.28	106.81	80
2.15	74.50	81.29	77.89	106.81	80
2.16	75.24	81.92	78.54	106.81	80
2.18	76.00	82.47	79.02	106.81	80
2.21	77.15	82.72	79.48	106.81	80
2.23	78.55	83.51	79.75	106.81	80
2.24	79.27	83.82	80.29	106.81	80
2.26	79.96	84.43	80.84	106.81	80
2.27	80.63	84.73	81.30	106.81	80
2.29	80.97	85.55	81.81	106.81	80
2.30	81.64	86.56	82.97	106.81	80
2.32	82.31	87.22	84.49	106.81	80
2.34	82.99	87.59	85.90	106.81	80
2.35	83.68	89.06	86.93	106.81	80
2.37	84.36	90.49	87.63	106.81	80
2.38	85.02	90.84	88.34	106.81	80
2.40	85.66	91.18	89.03	106.81	80
2.42	85.99	92.23	89.70	106.81	80
2.43	86.66	92.93	90.05	106.81	80
2.45	87.28	93.68	90.39	106.81	80
2.46	87.88	94.02	91.32	106.81	80
2.48	88.49	94.72	91.99	106.81	80
2.49	88.77	95.76	92.65	106.81	80
2.51	89.37	96.11	93.26	106.81	80
2.53	89.99	96.83	93.58	106.81	80
2.56	90.90	97.53	94.21	106.81	80
2.59	92.10	98.17	94.85	106.81	80
2.63	93.43	98.50	95.50	106.81	80
2.65	94.71	99.76	96.15	106.81	80
2.66	95.38	101.01	97.10	106.81	80
2.68	95.69	101.34	97.72	106.81	80
2.69	96.31	101.97	98.34	106.81	80
2.71	97.00	102.58	98.96	106.81	80
2.72	97.67	103.16	99.58	106.81	80
2.74	97.99	103.77	100.17	106.81	80
2.75	98.31	104.40	100.76	106.81	80
2.77	99.60	104.72	101.36	106.81	80
2.79	100.23	105.30	101.67	106.81	80
2.80	100.54	105.89	102.00	106.81	80
2.82	101.15	106.48	102.96	106.81	80
2.84	101.72	107.10	103.57	106.81	80
2.85	102.29	107.74	104.21	106.81	80
2.87	102.58	108.04	104.82	106.81	80
2.88	102.87		105.14	106.81	80
2.90	103.74		105.77	106.81	80
2.91	104.31		106.35	106.81	80
2.93	104.88		106.92	106.81	80
2.94	105.47			106.81	80
