Momoi Ryujin PE1 25lb Braid
An extra-strong and extra-soft PE line that pursues the desire to “cast further” and “have more flexibility.”
By having an exquisite balance in the braiding, this extra-flexible line caters to a variety of the anglers’ needs. Adopting “extra silent mode” that minimizes noise with the guide, it is a PE line for versatile use such as surfcasting, wharf fishing, lure fishing, and light jigging.
Key Statistics
-
- Measured Diameter: .267mm (166.56% of stated .160mm)
- Out of Roundness: .073mm (27.4% variation in diameter)
- Measured Breaking Strain: 26.26 lbs (105% of rated 25lbs)
- Abrasion Breaking Strain: 10.48 lbs (39.91% of max break)
- FG Knot Breaking Strain: 20.46 lbs (77.91% of max break)
Overall a very high performing braid. The outright Tensile Strength was slightly below average but both the Abrasion and FG Knot strength were excellent. The line does have a distinct oval profile with an out-of-roundness value of over 27%
Testing Process
Key Line Statistics
| Attribute | Value |
|---|---|
| Brand | Momoi |
| Name | RYUJIN PE1 |
| Web Site | Visit Website |
| Rated Strength (lbs) | 25 |
| Date Tested | 1 June 2024 |
| Credit to | Jonas from Switzerland |
| Strands | 8 |
| Cost $AUD | 48 |
| Spool Quanity (m) | 150 |
| Quoted Diameter (mm) | 0.16 |
| Measured Average Diameter (mm) | 0.267 |
| Diameter Quoted vs Measured (%) | 166.88 |
| Minimum Diameter (mm) | 0.227 |
| Maximum Diameter (mm) | 0.3 |
| Break Max Average (lbs) | 26.26 |
| Claimed vs Actual Breaking Strain (%) | 105.04 |
| Tensile Strength (PSI) | 301672 |
| Tensile Rank | 68 |
| Abrasion Break Max Average (lbs) | 10.48 |
| Abrasion Break vs Max Break Strain (%) | 39.91 |
| Abrasion % of Maximum Rank | 15 |
| Abrasion Tensile Strength PSI | 120393 |
| Abrasion Tensile Rank | 34 |
| FG Break Max Average (lbs) | 20.46 |
| FG Break vs Max Break Strain (%) | 77.93 |
| FG % of Maximum Rank | 24 |
| FG Tensile Strength PSI | 235042 |
| FG Tensile Rank | 44 |
| Time | Test1 | Test2 | Test3 | Average | Rated |
|---|---|---|---|---|---|
| 0,0 | 0,00 | 0,00 | 0,00 | 26,26 | 25 |
| 0,1 | 1,07 | 1,37 | 1,41 | 26,26 | 25 |
| 0,2 | 1,91 | 2,34 | 2,12 | 26,26 | 25 |
| 0,3 | 2,22 | 2,62 | 2,38 | 26,26 | 25 |
| 0,4 | 2,93 | 2,91 | 2,65 | 26,26 | 25 |
| 0,5 | 3,35 | 3,31 | 3,30 | 26,26 | 25 |
| 0,6 | 3,76 | 3,72 | 3,70 | 26,26 | 25 |
| 0,7 | 4,14 | 4,48 | 4,41 | 26,26 | 25 |
| 0,8 | 4,53 | 4,85 | 4,73 | 26,26 | 25 |
| 0,9 | 5,16 | 5,44 | 5,05 | 26,26 | 25 |
| 1,0 | 5,40 | 5,68 | 5,29 | 26,26 | 25 |
| 1,1 | 6,00 | 5,91 | 5,86 | 26,26 | 25 |
| 1,2 | 6,35 | 6,24 | 6,43 | 26,26 | 25 |
| 1,3 | 7,01 | 6,58 | 6,76 | 26,26 | 25 |
| 1,4 | 7,32 | 7,21 | 7,08 | 26,26 | 25 |
| 1,5 | 7,63 | 7,51 | 7,39 | 26,26 | 25 |
| 1,6 | 7,82 | 8,00 | 7,89 | 26,26 | 25 |
| 1,7 | 8,01 | 8,18 | 8,07 | 26,26 | 25 |
| 1,8 | 8,45 | 8,65 | 8,25 | 26,26 | 25 |
| 1,9 | 8,71 | 8,93 | 8,51 | 26,26 | 25 |
| 2,0 | 9,20 | 9,21 | 9,03 | 26,26 | 25 |
| 2,1 | 9,45 | 9,47 | 9,55 | 26,26 | 25 |
| 2,2 | 9,86 | 9,74 | 9,81 | 26,26 | 25 |
| 2,3 | 10,02 | 10,17 | 9,97 | 26,26 | 25 |
| 2,4 | 10,19 | 10,35 | 10,12 | 26,26 | 25 |
| 2,5 | 10,42 | 10,77 | 10,51 | 26,26 | 25 |
| 2,6 | 10,66 | 11,02 | 10,75 | 26,26 | 25 |
| 2,7 | 11,11 | 11,27 | 10,98 | 26,26 | 25 |
| 2,8 | 11,34 | 11,52 | 11,20 | 26,26 | 25 |
| 2,9 | 11,79 | 11,76 | 11,42 | 26,26 | 25 |
| 3,0 | 12,02 | 12,16 | 11,78 | 26,26 | 25 |
| 3,1 | 12,39 | 12,30 | 11,93 | 26,26 | 25 |
| 3,2 | 12,54 | 12,67 | 12,27 | 26,26 | 25 |
| 3,3 | 12,68 | 12,90 | 12,46 | 26,26 | 25 |
| 3,4 | 12,89 | 13,34 | 12,66 | 26,26 | 25 |
| 3,5 | 13,11 | 13,56 | 12,85 | 26,26 | 25 |
| 3,6 | 13,53 | 13,78 | 13,04 | 26,26 | 25 |
| 3,7 | 13,74 | 13,92 | 13,43 | 26,26 | 25 |
| 3,8 | 14,09 | 14,07 | 13,62 | 26,26 | 25 |
| 3,9 | 14,24 | 14,40 | 13,93 | 26,26 | 25 |
| 4,0 | 14,38 | 14,60 | 14,03 | 26,26 | 25 |
| 4,1 | 14,58 | 14,99 | 14,31 | 26,26 | 25 |
| 4,2 | 14,77 | 15,19 | 14,48 | 26,26 | 25 |
| 4,3 | 15,18 | 15,39 | 14,65 | 26,26 | 25 |
| 4,4 | 15,39 | 15,57 | 14,77 | 26,26 | 25 |
| 4,5 | 15,71 | 15,74 | 14,90 | 26,26 | 25 |
| 4,6 | 15,83 | 16,06 | 15,03 | 26,26 | 25 |
| 4,7 | 15,94 | 16,21 | 15,05 | 26,26 | 25 |
| 4,8 | 16,13 | 16,53 | 15,24 | 26,26 | 25 |
| 4,9 | 16,31 | 16,71 | 15,43 | 26,26 | 25 |
| 5,0 | 16,68 | 17,07 | 15,61 | 26,26 | 25 |
| 5,1 | 16,85 | 17,24 | 15,81 | 26,26 | 25 |
| 5,2 | 17,16 | 17,42 | 16,02 | 26,26 | 25 |
| 5,3 | 17,29 | 17,54 | 16,32 | 26,26 | 25 |
| 5,4 | 17,58 | 17,65 | 16,41 | 26,26 | 25 |
| 5,5 | 17,75 | 17,92 | 16,68 | 26,26 | 25 |
| 5,6 | 17,91 | 18,07 | 16,86 | 26,26 | 25 |
| 5,7 | 18,09 | 18,37 | 17,20 | 26,26 | 25 |
| 5,8 | 18,27 | 18,52 | 17,36 | 26,26 | 25 |
| 5,9 | 18,53 | 18,67 | 17,53 | 26,26 | 25 |
| 6,0 | 18,61 | 18,78 | 17,67 | 26,26 | 25 |
| 6,1 | 18,87 | 18,88 | 17,81 | 26,26 | 25 |
| 6,2 | 19,04 | 19,16 | 18,12 | 26,26 | 25 |
| 6,3 | 19,22 | 19,33 | 18,30 | 26,26 | 25 |
| 6,4 | 19,40 | 19,67 | 18,66 | 26,26 | 25 |
| 6,5 | 19,59 | 19,85 | 18,85 | 26,26 | 25 |
| 6,6 | 19,89 | 20,02 | 19,12 | 26,26 | 25 |
| 6,7 | 20,02 | 20,15 | 19,20 | 26,26 | 25 |
| 6,8 | 20,34 | 20,27 | 19,28 | 26,26 | 25 |
| 6,9 | 20,54 | 20,54 | 19,41 | 26,26 | 25 |
| 7,0 | 20,93 | 20,67 | 19,54 | 26,26 | 25 |
| 7,1 | 21,12 | 20,95 | 19,82 | 26,26 | 25 |
| 7,2 | 21,31 | 21,10 | 19,96 | 26,26 | 25 |
| 7,3 | 21,40 | 21,36 | 20,11 | 26,26 | 25 |
| 7,4 | 21,48 | 21,47 | 20,26 | 26,26 | 25 |
| 7,5 | 21,78 | 21,59 | 20,42 | 26,26 | 25 |
| 7,6 | 21,98 | 21,78 | 20,77 | 26,26 | 25 |
| 7,7 | 22,38 | 21,96 | 20,97 | 26,26 | 25 |
| 7,8 | 22,57 | 22,33 | 21,36 | 26,26 | 25 |
| 7,9 | 22,76 | 22,52 | 21,56 | 26,26 | 25 |
| 8,0 | 22,88 | 22,84 | 21,84 | 26,26 | 25 |
| 8,1 | 23,00 | 22,98 | 21,92 | 26,26 | 25 |
| 8,2 | 23,33 | 23,12 | 22,01 | 26,26 | 25 |
| 8,3 | 23,53 | 23,28 | 22,18 | 26,26 | 25 |
| 8,4 | 23,92 | 23,43 | 22,36 | 26,26 | 25 |
| 8,5 | 24,11 | 23,77 | 22,67 | 26,26 | 25 |
| 8,6 | 24,38 | 23,95 | 22,80 | 26,26 | 25 |
| 8,7 | 24,48 | 24,24 | 23,08 | 26,26 | 25 |
| 8,8 | 24,57 | 24,34 | 23,21 | 26,26 | 25 |
| 8,9 | 24,77 | 24,62 | 23,35 | 26,26 | 25 |
| 9,0 | 24,98 | 24,79 | 23,55 | 26,26 | 25 |
| 9,1 | 25,39 | 24,96 | 23,74 | 26,26 | 25 |
| 9,2 | 25,59 | 25,12 | 24,09 | 26,26 | 25 |
| 9,3 | 26,01 | 25,29 | 24,24 | 26,26 | 25 |
| 9,4 | 26,21 | 25,54 | 24,46 | 26,26 | 25 |
| 9,5 | 26,42 | 25,64 | 24,54 | 26,26 | 25 |
| 9,6 | 26,55 | 25,73 | 24,79 | 26,26 | 25 |
| 9,7 | 26,67 | 24,97 | 26,26 | 25 | |
| 9,8 | 26,99 | 25,15 | 26,26 | 25 | |
| 9,9 | 27,18 | 25,33 | 26,26 | 25 | |
| 10,0 | 27,37 | 25,50 | 26,26 | 25 | |
| 10,1 | 25,68 | 26,26 | 25 |
Diameter Variation
