Seaguar Blue Label Fluorocarbon : 40lb

Seaguar Blue Label 40lb Fluorocarbon

Blue Label Fluorocarbon Leader – Incredible Impact and Abrasion Resistance. Fast Sinking, Double Structure for Strength and Softness. The Original Fluoro Leader

Seaguar Blue Label Leader Material is known the world over for its incredible impact strength and abrasion resistance. No wonder it’s one of our best sellers.

Our exclusive double-structure process fuses two 100% fluorocarbon resins to create a leader with exceptional knot and tensile strength.

Virtually invisible; made in Japan with cutting-edge innovation. It’s a versatile choice that’s proven on the water for dependability and consistency.

https://seaguar.com/products/blue-label?variant=42960897966299

Summary

- Measured Ave Diameter: .637mm (102.7% of stated .62mm)
- Measured Breaking Strain: 60.75 lbs (151.88% of rated 40lbs)
- Abrasion Breaking Strain: 32.39 lbs (53.32% of max break)
- FG Knot Breaking Strain: 58.64 lbs (96.53% of max break)

Definately seems like a decent quality Fluorocarbon line. There did appear to be some pitting in the surface under close inspection. Some solid results across all the tests, with the stated diameter being only 0.017mm under what we measured. The fact that this line was rated at 40lbs, yet broke at over 60lbs is a little surprising.

Testing Process

Key Line Statistics

Attribute	Value
Brand	Seaguar
Name	Blue Label
Web Site	Visit Website
Rated Strength (lbs)	40
Date Tested	7 July 2024
Credit to	Matthew P
Strands	1
Cost $AUD	0
Spool Quanity (m)	0
Quoted Diameter (mm)	0.62
Measured Average Diameter (mm)	0.637
Diameter Quoted vs Measured (%)	102.74
Minimum Diameter (mm)	0.637
Maximum Diameter (mm)	0.637
Break Max Average (lbs)	60.75
Claimed vs Actual Breaking Strain (%)	151.88
Average Stretch @ Maximum Break	N/A
Tensile Strength (PSI)	122983
Tensile Rank	6
Abrasion Break Max Average (lbs)	32.39
Abrasion Break vs Max Break Strain (%)	53.32
Abrasion % of Maximum Rank	7
Abrasion Tensile Strength PSI	65571
Abrasion Tensile Rank	4
FG Break Max Average (lbs)	58.64
FG Break vs Max Break Strain (%)	96.53
FG % of Maximum Rank	3
FG Tensile Strength PSI	118711
FG Tensile Rank	3

Time	Test1	Test2	Test3	Average	Rated
0.0	0.00	0.00	0.00	60.75	40
0.1	0.95	1.06	0.91	60.75	40
0.2	1.43	1.93	1.59	60.75	40
0.3	1.75	2.26	1.81	60.75	40
0.4	2.07	2.80	2.34	60.75	40
0.5	2.57	3.01	2.65	60.75	40
0.6	2.76	3.49	2.95	60.75	40
0.7	3.23	3.76	3.23	60.75	40
0.8	3.51	4.29	3.52	60.75	40
0.9	3.80	4.54	3.96	60.75	40
1.0	4.06	4.79	4.12	60.75	40
1.1	4.31	4.95	4.51	60.75	40
1.2	4.73	5.10	4.73	60.75	40
1.3	4.90	5.48	5.18	60.75	40
1.4	5.29	5.70	5.39	60.75	40
1.5	5.51	6.15	5.61	60.75	40
1.6	5.74	6.38	5.75	60.75	40
1.7	5.96	6.61	5.89	60.75	40
1.8	6.17	6.77	6.24	60.75	40
1.9	6.53	6.92	6.44	60.75	40
2.0	6.66	7.31	6.86	60.75	40
2.1	7.02	7.53	7.06	60.75	40
2.2	7.23	7.98	7.27	60.75	40
2.3	7.66	8.20	7.46	60.75	40
2.4	7.88	8.62	7.65	60.75	40
2.5	8.09	8.81	7.97	60.75	40
2.6	8.22	9.01	8.11	60.75	40
2.7	8.36	9.16	8.44	60.75	40
2.8	8.70	9.32	8.65	60.75	40
2.9	8.90	9.70	9.06	60.75	40
3.0	9.32	9.92	9.28	60.75	40
3.1	9.52	10.39	9.49	60.75	40
3.2	9.73	10.64	9.62	60.75	40
3.3	9.86	10.88	9.74	60.75	40
3.4	10.00	11.02	10.07	60.75	40
3.5	10.36	11.17	10.28	60.75	40
3.6	10.60	11.53	10.69	60.75	40
3.7	11.04	11.74	10.89	60.75	40
3.8	11.26	12.17	11.10	60.75	40
3.9	11.62	12.38	11.24	60.75	40
4.0	11.76	12.75	11.38	60.75	40
4.1	11.91	12.90	11.73	60.75	40
4.2	12.12	13.06	11.95	60.75	40
4.3	12.32	13.30	12.37	60.75	40
4.4	12.77	13.54	12.58	60.75	40
4.5	13.02	14.02	12.93	60.75	40
4.6	13.49	14.26	13.06	60.75	40
4.7	13.72	14.65	13.20	60.75	40
4.8	13.95	14.80	13.40	60.75	40
4.9	14.11	14.95	13.59	60.75	40
5.0	14.28	15.18	14.01	60.75	40
5.1	14.67	15.40	14.22	60.75	40
5.2	14.90	15.84	14.58	60.75	40
5.3	15.36	16.05	14.72	60.75	40
5.4	15.58	16.41	14.86	60.75	40
5.5	15.95	16.56	15.08	60.75	40
5.6	16.08	16.98	15.29	60.75	40
5.7	16.22	17.24	15.73	60.75	40
5.8	16.46	17.51	15.94	60.75	40
5.9	16.69	17.76	16.29	60.75	40
6.0	17.19	18.01	16.43	60.75	40
6.1	17.44	18.42	16.75	60.75	40
6.2	17.87	18.57	16.93	60.75	40
6.3	18.04	18.96	17.12	60.75	40
6.4	18.21	19.18	17.32	60.75	40
6.5	18.47	19.41	17.52	60.75	40
6.6	18.73	19.60	17.88	60.75	40
6.7	19.20	19.79	18.03	60.75	40
6.8	19.42	20.14	18.41	60.75	40
6.9	19.79	20.31	18.62	60.75	40
7.0	19.95	20.72	18.84	60.75	40
7.1	20.34	20.98	19.05	60.75	40
7.2	20.58	21.23	19.26	60.75	40
7.3	21.08	21.48	19.70	60.75	40
7.4	21.34	21.72	19.94	60.75	40
7.5	21.61	22.12	20.27	60.75	40
7.6	21.77	22.28	20.37	60.75	40
7.7	21.94	22.65	20.47	60.75	40
7.8	22.36	22.87	20.69	60.75	40
7.9	22.61	23.28	20.92	60.75	40
8.0	23.10	23.46	21.37	60.75	40
8.1	23.33	23.65	21.60	60.75	40
8.2	23.56	23.63	21.92	60.75	40
8.3	23.69	23.62	22.00	60.75	40
8.4	23.83	23.95	22.39	60.75	40
8.5	24.18	24.30	22.68	60.75	40
8.6	24.40	24.82	22.98	60.75	40
8.7	24.89	24.99	23.08	60.75	40
8.8	25.17	25.36	23.19	60.75	40
8.9	25.54	25.55	23.39	60.75	40
9.0	25.63	25.75	23.50	60.75	40
9.1	25.73	25.88	23.79	60.75	40
9.2	26.03	26.02	23.99	60.75	40
9.3	26.34	26.33	24.44	60.75	40
9.4	26.79	26.51	24.70	60.75	40
9.5	26.93	26.90	24.96	60.75	40
9.6	27.28	27.11	25.02	60.75	40
9.7	27.48	27.32	25.09	60.75	40
9.8	27.68	27.45	25.44	60.75	40
9.9	27.83	27.59	25.72	60.75	40
10.0	27.98	27.94	26.15	60.75	40
10.1	28.47	28.16	26.28	60.75	40
10.2	28.80	28.60	26.42	60.75	40
10.3	29.31	28.81	26.62	60.75	40
10.4	29.47	29.16	26.83	60.75	40
10.5	29.64	29.30	27.21	60.75	40
10.6	29.80	29.43	27.40	60.75	40
10.7	29.95	29.59	27.76	60.75	40
10.8	30.37	29.74	27.95	60.75	40
10.9	30.64	30.11	28.13	60.75	40
11.0	31.00	30.33	28.23	60.75	40
11.1	31.09	30.67	28.34	60.75	40
11.2	31.44	30.81	28.66	60.75	40
11.3	31.68	30.94	28.87	60.75	40
11.4	31.93	31.14	29.30	60.75	40
11.5	32.21	31.35	29.52	60.75	40
11.6	32.50	31.80	29.85	60.75	40
11.7	32.85	32.06	29.98	60.75	40
11.8	32.91	32.45	30.10	60.75	40
11.9	33.25	32.58	30.29	60.75	40
12.0	33.53	32.87	30.47	60.75	40
12.1	33.80	33.02	30.90	60.75	40
12.2	34.05	33.17	31.13	60.75	40
12.3	34.30	33.39	31.48	60.75	40
12.4	34.58	33.62	31.58	60.75	40
12.5	34.62	33.92	31.69	60.75	40
12.6	34.96	34.01	31.91	60.75	40
12.7	35.26	34.35	32.14	60.75	40
12.8	35.73	34.62	32.58	60.75	40
12.9	35.88	34.88	32.80	60.75	40
13.0	36.04	35.15	33.16	60.75	40
13.1	36.29	35.41	33.31	60.75	40
13.2	36.53	35.81	33.68	60.75	40
13.3	36.94	35.95	33.90	60.75	40
13.4	37.10	36.23	34.13	60.75	40
13.5	37.50	36.38	34.26	60.75	40
13.6	37.73	36.71	34.40	60.75	40
13.7	37.97	36.90	34.76	60.75	40
13.8	38.04	37.08	34.99	60.75	40
13.9	38.12	37.14	35.41	60.75	40
14.0	38.45	37.21	35.61	60.75	40
14.1	38.70	37.60	35.80	60.75	40
14.2	39.06	37.92	35.99	60.75	40
14.3	39.15	38.47	36.18	60.75	40
14.4	39.54	38.69	36.62	60.75	40
14.5	39.83	39.01	36.86	60.75	40
14.6	40.12	39.11	37.17	60.75	40
14.7	40.26	39.21	37.23	60.75	40
14.8	40.39	39.36	37.47	60.75	40
14.9	40.46	39.51	37.64	60.75	40
15.0	40.38	39.81	37.82	60.75	40
15.1	40.74	39.97	38.08	60.75	40
15.2	41.17	40.07	38.35	60.75	40
15.3	41.60	40.01	38.70	60.75	40
15.4	41.79	39.96	38.79	60.75	40
15.5	41.97	40.16	39.01	60.75	40
15.6	42.09	40.36	39.15	60.75	40
15.7	42.02	40.89	39.28	60.75	40
15.8	42.39	41.23	39.59	60.75	40
15.9	42.84	41.48	39.91	60.75	40
16.0	43.44	41.39	40.18	60.75	40
16.1	43.60	41.40	40.15	60.75	40
16.2	43.76	41.48	40.32	60.75	40
16.3	43.99	41.57	40.53	60.75	40
16.4	44.23	41.94	40.94	60.75	40
16.5	44.28	42.32	41.13	60.75	40
16.6	44.11	42.82	41.33	60.75	40
16.7	44.31	42.95	41.53	60.75	40
16.8	44.70	43.09	41.74	60.75	40
16.9	45.08	43.10	41.97	60.75	40
17.0	45.33	43.49	42.01	60.75	40
17.1	45.58	43.88	42.29	60.75	40
17.2	46.11	44.26	42.54	60.75	40
17.3	46.39	44.45	43.07	60.75	40
17.4	46.77	44.65	43.34	60.75	40
17.5	46.87	44.97	43.62	60.75	40
17.6	46.65	45.10	43.58	60.75	40
17.7	46.32	45.43	43.53	60.75	40
17.8	46.00	45.63	43.64	60.75	40
17.9	46.61	45.83	43.78	60.75	40
18.0	47.23	45.81	44.19	60.75	40
18.1	48.11	45.80	44.44	60.75	40
18.2	48.37	45.86	44.70	60.75	40
18.3	48.64	45.95	44.98	60.75	40
18.4	48.65	46.45	45.27	60.75	40
18.5	48.65	46.88	45.62	60.75	40
18.6	48.84	47.30	45.68	60.75	40
18.7	49.02	47.44	45.86	60.75	40
18.8	49.51	47.58	45.98	60.75	40
18.9	49.81	47.73	46.09	60.75	40
19.0	50.27	47.74	46.31	60.75	40
19.1	50.42	48.03	46.52	60.75	40
19.2	50.58	48.30	46.91	60.75	40
19.3	50.75	48.60	47.09	60.75	40
19.4	50.93	48.62	47.39	60.75	40
19.5	50.94	48.64	47.51	60.75	40
19.6	50.77	48.67	47.76	60.75	40
19.7	51.05	48.71	47.88	60.75	40
19.8	51.50	49.12	48.00	60.75	40
19.9	52.20	49.51	48.21	60.75	40
20.0	52.47	49.98	48.41	60.75	40
20.1	52.73	50.08	48.99	60.75	40
20.2	52.90	50.17	49.35	60.75	40
20.3	53.08	50.39	49.76	60.75	40
20.4	52.98	50.62	49.80	60.75	40
20.5	52.70	51.01	49.84	60.75	40
20.6	52.97	51.18	49.97	60.75	40
20.7	53.51	51.32	50.11	60.75	40
20.8	54.05	51.30	50.37	60.75	40
20.9	54.32	51.40	50.49	60.75	40
21.0	54.58	51.54	50.76	60.75	40
21.1	54.65	51.67	50.90	60.75	40
21.2	54.44	52.02	51.18	60.75	40
21.3	54.65	52.37	51.33	60.75	40
21.4	55.07	52.65	51.47	60.75	40
21.5	55.69	52.57	51.82	60.75	40
21.6	55.91	52.93	52.17	60.75	40
21.7	56.12	53.35	52.50	60.75	40
21.8	56.34	53.78	52.48	60.75	40
21.9	56.55	53.69	52.67	60.75	40
22.0	56.91	53.61	52.88	60.75	40
22.1	57.04	53.69	53.09	60.75	40
22.2	56.90	53.87	53.27	60.75	40
22.3	56.63	54.26	53.44	60.75	40
22.4	56.35	54.48	53.67	60.75	40
22.5	56.93	54.59	53.71	60.75	40
22.6	57.52	54.48	53.91	60.75	40
22.7	58.23	54.37	54.05	60.75	40
22.8	58.36	54.45	54.56	60.75	40
22.9	58.67	54.54	54.92	60.75	40
23.0	58.86	54.90	55.28	60.75	40
23.1	59.20	55.17	55.36	60.75	40
23.2	59.36	55.54	55.45	60.75	40
23.3	59.59	55.63	55.45	60.75	40
23.4	59.67	55.94	55.38	60.75	40
23.5	59.74	56.17	55.38	60.75	40
23.6	59.53	56.39	55.46	60.75	40
23.7	59.33	56.52	55.54	60.75	40
23.8	59.60	56.65	55.58	60.75	40
23.9	60.07	56.76	55.62	60.75	40
24.0	60.67	56.74	56.11	60.75	40
24.1	60.78	57.04	56.57	60.75	40
24.2	60.90	57.37	57.03	60.75	40
24.3		57.69	57.03	60.75	40
24.4		57.64	57.05	60.75	40
24.5		57.59	57.07	60.75	40
24.6		57.67	57.08	60.75	40
24.7		57.79	57.13	60.75	40
24.8		58.36	57.19	60.75	40
24.9		58.81	57.46	60.75	40
25.0		59.20	57.68	60.75	40
25.1		59.15	58.15	60.75	40
25.2		59.10	58.41	60.75	40
25.3		59.21	58.73	60.75	40
25.4		59.33	58.81	60.75	40
25.5		59.75	58.88	60.75	40
25.6		60.05	58.98	60.75	40
25.7		60.38	59.09	60.75	40
25.8		60.41	59.19	60.75	40
25.9		60.43	59.20	60.75	40
26.0		60.40	59.35	60.75	40
26.1		60.38	59.49	60.75	40
26.2		60.43	59.64	60.75	40
26.3		60.50	59.93	60.75	40
26.4		60.58	60.22	60.75	40
26.5			60.60	60.75	40
26.6			60.68	60.75	40
26.7			60.77	60.75	40
