Seaguar Grandmax x8 - PE0.8 Braid
PE line for those who are picky.
[High Sensitivity] Adopts Grand Max PE, which has the least elongation in our PE series.
[High strength] Adopts a set of 8 pieces to thoroughly pursue strength.
[High visibility] Adopts new pitch markings to thoroughly pursue visibility.
[Value Price] Thorough pursuit of cost performance.
We have a wide range of sizes available, from size 0.4, which is suitable for precise fishing methods, to size 6, which can be used for targeting big fish such as blue fish.
Summary
- Measured Diameter: .189mm (127.45% of stated .148mm)
- Out of Roundness: .075mm (39.76% variation in diameter)
- Measured Breaking Strain: 14.22lbs (88.8% of rated ave 16lbs)
- Abrasion Breaking Strain: 4.25lbs (29.9% of max break)
- FG Knot Breaking Strain: 10.62lbs (74.68% of max break)
Average performance across all of the tests. The line has a very distinct oval shape which is uncommon for an x8 braid. Average Diameter is 127% of what is claimed. Average Break is 89% of the quoted figure.
Testing Process
Your consent is required to display this content from youtube - Privacy Settings
Key Line Statistics
| Attribute | Value |
|---|---|
| Brand | Seaguar |
| Name | Grandmax PE x8 PE0.8 |
| Web Site | Visit Website |
| Rated Strength (lbs) | 16 |
| Date Tested | 12 February 2024 |
| Credit to | Steven |
| Strands | 8 |
| Cost $AUD | 79.99 |
| Spool Quanity (m) | 150 |
| Quoted Diameter (mm) | 0.148 |
| Measured Average Diameter (mm) | 0.189 |
| Diameter Quoted vs Measured (%) | 127.7 |
| Minimum Diameter (mm) | 0.139 |
| Maximum Diameter (mm) | 0.214 |
| Break Max Average (lbs) | 14.22 |
| Claimed vs Actual Maximum Break (%) | 88.9 |
| Average Stretch @ Maximum Break | N/A |
| Tensile Strength (PSI) | 326483 |
| Tensile Rank | 83 |
| Abrasion Break Max Average (lbs) | 4.25 |
| Abrasion Break vs Max Break (%) | 29.91 |
| Abrasion % of Maximum Rank | 119 |
| Abrasion Tensile Strength PSI | 97578 |
| Abrasion Tensile Rank | 98 |
| FG Break Max Average (lbs) | 10.62 |
| FG Break vs Max Break (%) | 74.68 |
| FG % of Maximum Rank | 67 |
| FG Tensile Strength PSI | 243829 |
| FG Tensile Rank | 61 |
| Time | Test1 | Test2 | Test3 | Average | Rated |
|---|---|---|---|---|---|
| 0.0 | 0.00 | 0.00 | 0.00 | 14.22 | 16 |
| 0.1 | 1.12 | 0.79 | 1.25 | 14.22 | 16 |
| 0.2 | 2.00 | 1.51 | 2.09 | 14.22 | 16 |
| 0.3 | 2.32 | 1.83 | 2.32 | 14.22 | 16 |
| 0.4 | 2.87 | 2.36 | 2.85 | 14.22 | 16 |
| 0.5 | 3.09 | 2.57 | 3.16 | 14.22 | 16 |
| 0.6 | 3.61 | 3.11 | 3.78 | 14.22 | 16 |
| 0.7 | 3.90 | 3.44 | 4.09 | 14.22 | 16 |
| 0.8 | 4.19 | 3.77 | 4.40 | 14.22 | 16 |
| 0.9 | 4.47 | 4.08 | 4.60 | 14.22 | 16 |
| 1.0 | 4.76 | 4.38 | 4.80 | 14.22 | 16 |
| 1.1 | 5.21 | 4.87 | 5.27 | 14.22 | 16 |
| 1.2 | 5.39 | 5.05 | 5.53 | 14.22 | 16 |
| 1.3 | 5.81 | 5.23 | 6.04 | 14.22 | 16 |
| 1.4 | 6.06 | 5.49 | 6.28 | 14.22 | 16 |
| 1.5 | 6.31 | 5.75 | 6.52 | 14.22 | 16 |
| 1.6 | 6.53 | 6.26 | 6.66 | 14.22 | 16 |
| 1.7 | 6.75 | 6.51 | 6.80 | 14.22 | 16 |
| 1.8 | 7.10 | 6.91 | 7.15 | 14.22 | 16 |
| 1.9 | 7.22 | 7.05 | 7.37 | 14.22 | 16 |
| 2.0 | 7.54 | 7.40 | 7.79 | 14.22 | 16 |
| 2.1 | 7.74 | 7.59 | 8.01 | 14.22 | 16 |
| 2.2 | 8.13 | 7.98 | 8.36 | 14.22 | 16 |
| 2.3 | 8.33 | 8.17 | 8.49 | 14.22 | 16 |
| 2.4 | 8.53 | 8.36 | 8.63 | 14.22 | 16 |
| 2.5 | 8.66 | 8.50 | 8.83 | 14.22 | 16 |
| 2.6 | 8.80 | 8.63 | 9.03 | 14.22 | 16 |
| 2.7 | 9.11 | 8.96 | 9.40 | 14.22 | 16 |
| 2.8 | 9.30 | 9.15 | 9.57 | 14.22 | 16 |
| 2.9 | 9.65 | 9.54 | 9.84 | 14.22 | 16 |
| 3.0 | 9.83 | 9.73 | 9.94 | 14.22 | 16 |
| 3.1 | 10.00 | 9.93 | 10.19 | 14.22 | 16 |
| 3.2 | 10.07 | 10.04 | 10.35 | 14.22 | 16 |
| 3.3 | 10.15 | 10.15 | 10.50 | 14.22 | 16 |
| 3.4 | 10.33 | 10.41 | 10.67 | 14.22 | 16 |
| 3.5 | 10.45 | 10.57 | 10.85 | 14.22 | 16 |
| 3.6 | 10.73 | 10.87 | 11.19 | 14.22 | 16 |
| 3.7 | 10.89 | 11.02 | 11.35 | 14.22 | 16 |
| 3.8 | 11.16 | 11.17 | 11.62 | 14.22 | 16 |
| 3.9 | 11.25 | 11.29 | 11.73 | 14.22 | 16 |
| 4.0 | 11.35 | 11.40 | 11.83 | 14.22 | 16 |
| 4.1 | 11.49 | 11.67 | 11.97 | 14.22 | 16 |
| 4.2 | 11.63 | 11.83 | 12.10 | 14.22 | 16 |
| 4.3 | 11.86 | 12.12 | 12.35 | 14.22 | 16 |
| 4.4 | 11.95 | 12.26 | 12.46 | 14.22 | 16 |
| 4.5 | 12.10 | 12.49 | 12.66 | 14.22 | 16 |
| 4.6 | 12.16 | 12.57 | 12.75 | 14.22 | 16 |
| 4.7 | 12.22 | 12.66 | 12.84 | 14.22 | 16 |
| 4.8 | 12.34 | 12.77 | 12.98 | 14.22 | 16 |
| 4.9 | 12.47 | 12.89 | 13.12 | 14.22 | 16 |
| 5.0 | 12.59 | 13.14 | 13.40 | 14.22 | 16 |
| 5.1 | 13.27 | 13.53 | 14.22 | 16 | |
| 5.2 | 13.51 | 13.74 | 14.22 | 16 | |
| 5.3 | 13.60 | 13.82 | 14.22 | 16 | |
| 5.4 | 13.70 | 13.99 | 14.22 | 16 | |
| 5.5 | 13.84 | 14.10 | 14.22 | 16 | |
| 5.6 | 13.99 | 14.20 | 14.22 | 16 | |
| 5.7 | 14.25 | 14.27 | 14.22 | 16 | |
| 5.8 | 14.36 | 14.33 | 14.22 | 16 | |
| 5.9 | 14.48 | 14.45 | 14.22 | 16 | |
| 6.0 | 14.50 | 14.22 | 16 | ||
| 6.1 | 14.63 | 14.22 | 16 | ||
| 6.2 | 14.71 | 14.22 | 16 | ||
| 6.3 | 14.89 | 14.22 | 16 | ||
| 6.4 | 14.98 | 14.22 | 16 | ||
| 6.5 | 15.14 | 14.22 | 16 | ||
| 6.6 | 15.19 | 14.22 | 16 | ||
| 6.7 | 15.25 | 14.22 | 16 | ||
| 6.8 | 15.37 | 14.22 | 16 | ||
| 6.9 | 15.48 | 14.22 | 16 | ||
| 7.0 | 15.60 | 14.22 | 16 |
Diameter Variation
