Seaguar INSHORE 25lb Fluorocarbon

Seaguar INSHORE 25lb

Fishing skinny water. Running the flats. Working the jetty. Casting from shore. Now you’ve got a Seaguar leader built to handle the toughest inshore challenge. Made from 100% custom Seaguar resins, Inshore offers incredible abrasion resistance with maximum impact and knot strength. It’s faster-sinking and significantly less visible underwater than mono. You get famous Seaguar performance in an economical fluoro – perfect for everyone.

https://seaguar.com/saltwater/new-lines/inshore

Key Statistics

Measured Diameter: .486mm (+103.4% on claimed .470mm)
Measured Breaking Strain: 34.93lbs (139.7% on claimed 25lbs)
Abrasion Breaking Strain: 15.77lbs (45.15% of measured maximum)
Breaking strain indicate that this is closer to a 36lb line, not 25lb.
Abrasion resistance is below average compared to other monofilaments (45% vs 57% Average)

Summary

Diameter Measurments were extremely consistant with only 0.001mm between all 6 measurments.

Line construction looks very smooth with minimal pitting. Second highest tensile strength of all Monofilaments.

Overall a great line with its only downfall being less than average abrasion resistance (45% vs average of 57%).

Testing Process

Key Line Statistics

Attribute	Value
Brand	Seaguar
Name	InShore Fluorocarbon
Web Site	Visit Website
Rated Strength (lbs)	25
Date Tested	27 September 2022
Credit to	Line Laboratory
Strands	1
Cost $AUD	24.95
Spool Quanity (m)	50
Quoted Diameter (mm)	0.47
Measured Average Diameter (mm)	0.486
Diameter Quoted vs Measured (%)	103.4
Minimum Diameter (mm)	0.486
Maximum Diameter (mm)	0.487
Break Max Average (lbs)	34.93
Claimed vs Actual Breaking Strain (%)	139.71
Tensile Strength (PSI)	121313
Tensile Rank	3
Abrasion Break Max Average (lbs)	15.77
Abrasion Break vs Max Break Strain (%)	45.14
Abrasion Tensile Strength PSI	54770
Abrasion Tensile Rank	4
FG Break Max Average (lbs)	0
FG Break vs Max Break Strain (%)	0
FG Tensile Strength PSI	0
FG Tensile Rank	1

Time	Test1	Test2	Test3	Rated
0,00	0,00	0,00	0,00	25
0,10	0,10	0,37	0,10	25
0,20	0,25	0,69	0,30	25
0,30	0,34	0,83	0,45	25
0,40	0,44	1,17	0,60	25
0,50	0,62	1,38	0,73	25
0,60	0,79	1,59	0,86	25
0,70	1,20	1,78	1,21	25
0,80	1,43	1,96	1,44	25
0,90	1,79	2,25	1,83	25
1,00	1,93	2,36	2,00	25
1,10	2,23	2,60	2,28	25
1,20	2,39	2,74	2,38	25
1,30	2,56	3,00	2,49	25
1,40	2,70	3,13	2,63	25
1,50	2,85	3,25	2,78	25
1,60	3,08	3,32	3,05	25
1,70	3,17	3,40	3,19	25
1,80	3,39	3,58	3,40	25
1,90	3,52	3,68	3,48	25
2,00	3,65	3,89	3,56	25
2,10	3,77	3,99	3,68	25
2,20	3,90	4,09	3,80	25
2,30	4,14	4,16	4,03	25
2,40	4,25	4,22	4,13	25
2,50	4,45	4,39	4,30	25
2,60	4,52	4,49	4,37	25
2,70	4,71	4,69	4,52	25
2,80	4,82	4,79	4,61	25
2,90	4,93	4,96	4,70	25
3,00	5,04	5,02	4,80	25
3,10	5,15	5,09	4,89	25
3,20	5,33	5,18	5,06	25
3,30	5,39	5,26	5,12	25
3,40	5,57	5,44	5,29	25
3,50	5,68	5,53	5,39	25
3,60	5,79	5,71	5,49	25
3,70	5,90	5,81	5,58	25
3,80	6,01	5,90	5,68	25
3,90	6,20	5,96	5,84	25
4,00	6,27	6,01	5,91	25
4,10	6,45	6,17	6,09	25
4,20	6,55	6,26	6,21	25
4,30	6,75	6,45	6,43	25
4,40	6,86	6,53	6,55	25
4,50	6,96	6,68	6,66	25
4,60	7,03	6,75	6,74	25
4,70	7,11	6,81	6,81	25
4,80	7,29	6,92	7,00	25
4,90	7,41	7,02	7,10	25
5,00	7,64	7,23	7,31	25
5,10	7,77	7,34	7,41	25
5,20	7,97	7,50	7,51	25
5,30	8,05	7,56	7,59	25
5,40	8,13	7,73	7,68	25
5,50	8,24	7,83	7,88	25
5,60	8,36	7,94	7,99	25
5,70	8,58	8,04	8,25	25
5,80	8,70	8,14	8,39	25
5,90	8,88	8,31	8,53	25
6,00	8,96	8,38	8,61	25
6,10	9,03	8,56	8,69	25
6,20	9,15	8,66	8,89	25
6,30	9,26	8,77	9,02	25
6,40	9,50	8,87	9,24	25
6,50	9,62	8,98	9,35	25
6,60	9,82	9,15	9,53	25
6,70	9,89	9,21	9,62	25
6,80	10,09	9,38	9,70	25
6,90	10,21	9,49	9,82	25
7,00	10,33	9,69	9,95	25
7,10	10,43	9,79	10,21	25
7,20	10,54	9,89	10,35	25
7,30	10,71	9,96	10,57	25
7,40	10,79	10,02	10,65	25
7,50	10,98	10,20	10,73	25
7,60	11,09	10,30	10,85	25
7,70	11,21	10,51	10,97	25
7,80	11,32	10,62	11,19	25
7,90	11,44	10,72	11,29	25
8,00	11,64	10,79	11,47	25
8,10	11,72	10,85	11,56	25
8,20	11,92	11,03	11,76	25
8,30	12,03	11,13	11,89	25
8,40	12,14	11,35	12,01	25
8,50	12,24	11,45	12,14	25
8,60	12,35	11,62	12,28	25
8,70	12,52	11,68	12,49	25
8,80	12,58	11,74	12,57	25
8,90	12,77	11,85	12,76	25
9,00	12,89	11,95	12,88	25
9,10	13,12	12,16	12,99	25
9,20	13,23	12,27	13,08	25
9,30	13,34	12,44	13,18	25
9,40	13,41	12,50	13,39	25
9,50	13,49	12,57	13,52	25
9,60	13,68	12,67	13,72	25
9,70	13,79	12,78	13,81	25
9,80	14,00	12,97	14,02	25
9,90	14,10	13,05	14,16	25
10,00	14,26	13,20	14,29	25
10,10	14,33	13,27	14,39	25
10,20	14,40	13,44	14,50	25
10,30	14,51	13,54	14,67	25
10,40	14,63	13,65	14,74	25
10,50	14,85	13,75	14,91	25
10,60	14,95	13,86	15,00	25
10,70	15,13	14,03	15,10	25
10,80	15,19	14,09	15,22	25
10,90	15,26	14,25	15,34	25
11,00	15,37	14,35	15,53	25
11,10	15,49	14,44	15,61	25
11,20	15,69	14,53	15,81	25
11,30	15,78	14,63	15,93	25
11,40	15,98	14,78	16,16	25
11,50	16,08	14,85	16,26	25
11,60	16,19	15,01	16,36	25
11,70	16,27	15,11	16,42	25
11,80	16,36	15,31	16,48	25
11,90	16,54	15,40	16,62	25
12,00	16,65	15,50	16,69	25
12,10	16,86	15,57	16,88	25
12,20	16,97	15,64	17,00	25
12,30	17,15	15,81	17,11	25
12,40	17,22	15,92	17,20	25
12,50	17,29	16,11	17,28	25
12,60	17,39	16,20	17,48	25
12,70	17,49	16,29	17,60	25
12,80	17,69	16,33	17,80	25
12,90	17,79	16,36	17,90	25
13,00	17,98	16,53	17,99	25
13,10	18,08	16,65	18,05	25
13,20	18,17	16,89	18,11	25
13,30	18,27	17,01	18,26	25
13,40	18,37	17,12	18,35	25
13,50	18,57	17,21	18,56	25
13,60	18,68	17,30	18,69	25
13,70	18,85	17,45	18,89	25
13,80	18,91	17,50	18,97	25
13,90	19,06	17,67	19,05	25
14,00	19,15	17,77	19,16	25
14,10	19,23	17,97	19,26	25
14,20	19,33	18,05	19,46	25
14,30	19,43	18,14	19,56	25
14,40	19,63	18,29	19,72	25
14,50	19,73	18,43	19,79	25
14,60	19,92	18,68	19,86	25
14,70	20,00	18,77	19,95	25
14,80	20,09	18,92	20,03	25
14,90	20,18	18,96	20,23	25
15,00	20,28	19,01	20,34	25
15,10	20,43	19,09	20,53	25
15,20	20,49	19,16	20,61	25
15,30	20,64	19,33	20,78	25
15,40	20,74	19,41	20,86	25
15,50	20,91	19,52	20,95	25
15,60	20,98	19,55	21,04	25
15,70	21,06	19,57	21,13	25
15,80	21,16	19,62	21,28	25
15,90	21,27	19,68	21,34	25
16,00	21,48	19,87	21,49	25
16,10	21,58	20,02	21,57	25
16,20	21,77	20,23	21,79	25
16,30	21,86	20,29	21,91	25
16,40	21,94	20,36	22,04	25
16,50	22,00	20,42	22,11	25
16,60	22,06	20,48	22,18	25
16,70	22,21	20,62	22,32	25
16,80	22,30	20,70	22,39	25
16,90	22,47	20,86	22,52	25
17,00	22,54	20,93	22,58	25
17,10	22,70	21,08	22,70	25
17,20	22,78	21,15	22,75	25
17,30	22,86	21,22	22,81	25
17,40	22,94	21,22	22,93	25
17,50	23,02	21,23	23,06	25
17,60	23,21	21,38	23,30	25
17,70	23,32	21,54	23,41	25
17,80	23,51	21,73	23,62	25
17,90	23,58	21,78	23,72	25
18,00	23,66	21,82	23,81	25
18,10	23,77	21,93	23,88	25
18,20	23,87	22,03	23,95	25
18,30	24,05	22,20	24,07	25
18,40	24,13	22,27	24,12	25
18,50	24,25	22,40	24,21	25
18,60	24,29	22,48	24,25	25
18,70	24,34	22,61	24,29	25
18,80	24,45	22,66	24,39	25
18,90	24,55	22,72	24,50	25
19,00	24,74	22,77	24,72	25
19,10	24,83	22,82	24,85	25
19,20	24,98	22,94	25,07	25
19,30	25,05	23,02	25,17	25
19,40	25,19	23,21	25,33	25
19,50	25,26	23,32	25,38	25
19,60	25,33	23,44	25,44	25
19,70	25,35	23,60	25,48	25
19,80	25,37	23,75	25,52	25
19,90	25,47	23,98	25,60	25
20,00	25,55	24,04	25,65	25
20,10	25,78	24,15	25,78	25
20,20	25,92	24,18	25,87	25
20,30	26,07	24,22	25,96	25
20,40	26,19	24,29	26,10	25
20,50	26,30	24,36	26,23	25
20,60	26,54	24,50	26,54	25
20,70	26,65	24,56	26,70	25
20,80	26,82	24,70	26,93	25
20,90	26,88	24,77	26,98	25
21,00	26,99	24,84	27,08	25
21,10	27,05	24,94	27,13	25
21,20	27,11	25,04	27,17	25
21,30	27,14	25,27	27,25	25
21,40	27,17	25,40	27,34	25
21,50	27,26	25,62	27,50	25
21,60	27,31	25,72	27,59	25
21,70	27,43	25,81	27,77	25
21,80	27,49	25,88	27,87	25
21,90	27,55	25,94	27,97	25
22,00	27,65	26,01	28,01	25
22,10	27,75	26,01	28,06	25
22,20	27,90	26,04	28,10	25
22,30	27,95	26,06	28,10	25
22,40	28,06	26,09	28,16	25
22,50	28,11	26,20	28,22	25
22,60	28,25	26,30	28,28	25
22,70	28,34	26,56	28,34	25
22,80	28,42	26,71	28,39	25
22,90	28,52	26,91	28,63	25
23,00	28,62	26,97	28,81	25
23,10	28,82	27,09	29,22	25
23,20	28,92	27,16	29,44	25
23,30	29,12	27,23	29,67	25
23,40	29,23	27,28	29,72	25
23,50	29,33	27,32	29,78	25
23,60	29,38	27,39	29,87	25
23,70	29,44	27,42	29,90	25
23,80	29,56	27,44	30,01	25
23,90	29,64	27,44	30,07	25
24,00	29,81	27,44	30,21	25
24,10	29,92	27,62	30,28	25
24,20	30,02	27,79	30,35	25
24,30	30,03	28,00	30,46	25
24,40	30,03	28,03	30,57	25
24,50	30,05	28,11	30,77	25
24,60	30,07	28,15	30,86	25
24,70	30,20	28,29	30,98	25
24,80	30,30	28,38	31,00	25
24,90	30,46	28,47	31,07	25
25,00	30,50	28,57	31,12	25
25,10	30,55	28,68	31,37	25
25,20	30,61	28,85	31,57	25
25,30	30,68	28,92	31,78	25
25,40	30,83	29,02	31,96	25
25,50	30,93	29,06	32,15	25
25,60	31,04	29,14	32,39	25
25,70	31,07	29,20	32,44	25
25,80	31,15	29,25	32,56	25
25,90	31,21	29,27	32,62	25
26,00	31,27	29,30	32,73	25
26,10	31,38	29,33	32,79	25
26,20	31,49	29,33	33,00	25
26,30	31,66	29,40	33,15	25
26,40	31,72	29,46	33,43	25
26,50	31,84	29,52	33,56	25
26,60	31,89	29,63	33,68	25
26,70	31,95	29,74	33,69	25
26,80	32,04	30,02	33,70	25
26,90	32,14	30,18	33,82	25
27,00	32,30	30,42	33,94	25
27,10	32,37	30,48	34,32	25
27,20	32,49	30,55	34,59	25
27,30	32,53	30,59	34,89	25
27,40	32,58	30,62	34,92	25
27,50	32,69	30,72	35,00	25
27,60	32,79	30,79	35,06	25
27,70	32,91	30,87	35,11	25
27,80	32,92	30,90	35,15	25
27,90	32,95	30,92	35,18	25
28,00	32,98	30,93	35,24	25
28,10	33,06	30,93	35,25	25
28,20	33,11	31,03	35,27	25
28,30	33,17	31,14	35,27	25
28,40	33,23	31,35	35,27	25
28,50	33,28	31,47	35,48	25
28,60	33,37	31,63	35,68	25
28,70	33,40	31,69	35,92	25
28,80	33,55	31,80	35,94	25
28,90	33,66	31,86	35,99	25
29,00	33,83	31,92	36,01	25
29,10	33,87	31,95	36,04	25
29,20	33,92	31,99	36,04	25
29,30	33,98	32,09	36,05	25
29,40	34,03	32,16	36,05	25
29,50	34,15	32,27	36,06	25
29,60	34,21	32,32	36,06	25
29,70	34,33	32,36		25
29,80	34,40	32,42		25
29,90	34,46	32,49		25
30,00	34,46	32,61		25
30,10		32,66		25
30,20		32,79		25
30,30		32,86		25
30,40		32,93		25
30,50		32,95		25
30,60		32,96		25
30,70		33,05		25
30,80		33,11		25
30,90		33,22		25
31,00		33,26		25
31,10		33,36		25
31,20		33,43		25
31,30		33,49		25
31,40		33,54		25
31,50		33,59		25
31,60		33,72		25
31,70		33,80		25
31,80		33,92		25
31,90		33,95		25
32,00		34,02		25
32,10		34,06		25
32,20		34,09		25
32,30		34,09		25
32,40		34,09		25
32,50		34,14		25
32,60		34,19		25
32,70		34,25		25
32,80		34,25		25
32,90		34,26		25
33,00		34,26		25
