Shimano Kairiki 8+ : PE3 - Line Laboratory

Shimano Kairiki 8+ : PE3 Braid

Overview

Shimano Kairiki 8+: Dominate Your Fishing Experience with Outstanding Strength and Precision

Shimano Kairiki 8+: Experience the next evolution in fishing technology with Shimano’s Kairiki 8+. Featuring a renewed, silicon based, three-layer coating and utilising the new standard of Izanas material, it offers superior water repellency and durability. Meticulously designed tension ensures precise control, ideal for all conditions. Available in multicolour and “Mantis Green” options. Explore Kairiki 8+ and raise your fishing game today.

https://fish.shimano.com/en-AU/product/line/braid/a155f00000dn9qzqat.html

Summary

- Measured Ave Diameter: 0.343mm (149.13% of claimed diameter)
- Out of Roundness: 0.051mm (14.86% variation in diameter)
- Measured Maximum Break: 52.64 lbs (175.47% of claimed 30 lbs)
- Measured Stretch @ Break: 2.64%
- Abrasion Maximum Break: 17.44 lbs (33.13% of max break)
- FG Knot Maximum Break: 41.18 lbs (78.23% of max break)

The updated version of Shimanos’ Kairiki 8 appears to be a nice line. Apart from some unknown deposits we saw under the microscope, the construction looked excellent. Both the quoted diameter and maximum break values were understated according to our tests. This seems like a significant improvement compared to the other 2 original Kairiki lines we tested in 8 and 15lb, ranking 121st and 75th respectively.

Shimano specify 2 maximum break values on the box, one for “World Spec” which is 30lbs and another “EU Spec” which is 22.5kg or 49.5lbs. So if we do the maths against that maximum break value we get 106.34% of the claimed maximum break, which is much closer than the 30lb otherwise printed on the box.

Testing Process

Key Line Statistics

Attribute	Value
Brand	Shimano
Name	Kairiki 8+
Web Site	Visit Website
Rated Strength (lbs)	30
Date Tested	24 March 2025
Credit to	LL
Strands	8
Cost $AUD	39.99
Spool Quanity (m)	150
Quoted Diameter (mm)	0.23
Measured Average Diameter (mm)	0.343
Diameter Quoted vs Measured (%)	149.13
Minimum Diameter (mm)	0.325
Maximum Diameter (mm)	0.376
Break Max Average (lbs)	52.64
Claimed vs Actual Maximum Break (%)	175.47
Average Stretch @ Maximum Break	2.64%
Tensile Strength (PSI)	369344
Tensile Rank	42
Abrasion Break Max Average (lbs)	17.44
Abrasion Break vs Max Break (%)	33.14
Abrasion % of Maximum Rank	77
Abrasion Tensile Strength PSI	122366
Abrasion Tensile Rank	44
FG Break Max Average (lbs)	41.18
FG Break vs Max Break (%)	78.24
FG % of Maximum Rank	30
FG Tensile Strength PSI	288936
FG Tensile Rank	23

StrainSummary	Test 1	Test 2	Test 3	Average	Rated
0.01	1.12	0.92	1.30	52.64	30
0.03	1.36	1.85	1.77	52.64	30
0.05	1.60	2.09	2.24	52.64	30
0.08	2.85	2.58	2.71	52.64	30
0.10	3.34	3.09	2.95	52.64	30
0.11	3.57	3.56	3.42	52.64	30
0.13	3.80	4.03	3.88	52.64	30
0.14	4.50	4.25	4.11	52.64	30
0.16	4.72	4.67	4.78	52.64	30
0.17	5.36	5.08	5.24	52.64	30
0.19	5.79	5.48	5.67	52.64	30
0.20	6.17	5.68	6.31	52.64	30
0.22	6.38	6.07	7.15	52.64	30
0.24	6.76	6.82	7.54	52.64	30
0.25	7.15	7.54	7.74	52.64	30
0.27	7.53	8.27	8.14	52.64	30
0.29	7.93	9.03	8.54	52.64	30
0.30	8.34	9.58	8.94	52.64	30
0.32	8.53	10.31	9.36	52.64	30
0.33	8.92	10.47	9.57	52.64	30
0.36	9.68	11.05	9.96	52.64	30
0.37	9.88	11.22	10.38	52.64	30
0.40	10.47	11.58	10.77	52.64	30
0.42	10.84	11.93	11.15	52.64	30
0.43	11.42	12.28	11.54	52.64	30
0.45	11.79	12.62	11.73	52.64	30
0.46	12.16	12.79	12.31	52.64	30
0.48	12.33	13.12	12.88	52.64	30
0.50	12.71	13.46	13.22	52.64	30
0.51	13.07	13.77	13.88	52.64	30
0.53	13.40	14.07	14.22	52.64	30
0.55	13.57	14.23	14.38	52.64	30
0.56	13.95	14.53	14.70	52.64	30
0.58	14.42	14.85	15.04	52.64	30
0.59	14.59	15.15	15.21	52.64	30
0.61	14.90	15.45	15.68	52.64	30
0.63	15.23	15.77	16.01	52.64	30
0.64	15.56	16.59	16.16	52.64	30
0.66	15.87	16.94	16.50	52.64	30
0.69	16.37	17.27	16.83	52.64	30
0.71	17.06	17.77	17.00	52.64	30
0.72	17.41	17.93	17.53	52.64	30
0.74	17.77	18.46	17.86	52.64	30
0.76	17.94	18.80	18.03	52.64	30
0.78	18.27	18.97	18.37	52.64	30
0.79	18.62	19.47	18.72	52.64	30
0.81	18.99	19.64	19.09	52.64	30
0.82	19.34	20.11	19.45	52.64	30
0.84	19.70	20.27	19.81	52.64	30
0.85	19.88	20.59	20.33	52.64	30
0.87	20.23	20.74	20.85	52.64	30
0.89	20.57	21.19	21.36	52.64	30
0.91	20.91	21.50	21.85	52.64	30
0.92	21.24	21.65	22.16	52.64	30
0.94	21.55	22.26	22.50	52.64	30
0.95	21.71	22.89	22.80	52.64	30
0.97	22.32	23.55	23.12	52.64	30
0.99	22.63	23.89	23.29	52.64	30
1.02	22.95	24.38	23.61	52.64	30
1.04	23.59	24.69	23.94	52.64	30
1.05	23.93	25.03	24.29	52.64	30
1.07	24.09	25.20	24.62	52.64	30
1.08	24.43	25.55	24.97	52.64	30
1.10	24.79	25.91	25.13	52.64	30
1.12	25.12	26.24	25.45	52.64	30
1.13	25.30	26.57	25.77	52.64	30
1.15	25.61	26.89	26.10	52.64	30
1.16	25.93	27.04	26.42	52.64	30
1.18	26.28	27.52	26.59	52.64	30
1.20	26.62	27.66	27.11	52.64	30
1.21	26.96	27.81	27.29	52.64	30
1.23	27.13	28.27	27.94	52.64	30
1.25	27.44	28.56	28.61	52.64	30
1.28	28.11	28.73	29.07	52.64	30
1.30	28.60	29.07	29.37	52.64	30
1.31	29.03	29.70	29.67	52.64	30
1.33	29.18	30.33	29.97	52.64	30
1.34	29.49	30.49	30.12	52.64	30
1.36	29.80	30.82	30.44	52.64	30
1.38	30.14	31.14	30.74	52.64	30
1.40	30.45	31.44	31.05	52.64	30
1.41	30.77	31.77	31.19	52.64	30
1.43	30.93	31.94	31.51	52.64	30
1.44	31.25	32.42	31.79	52.64	30
1.46	31.55	32.58	32.28	52.64	30
1.48	31.90	32.89	32.44	52.64	30
1.51	32.38	33.05	32.78	52.64	30
1.53	33.02	33.50	33.12	52.64	30
1.54	33.34	33.82	33.45	52.64	30
1.56	33.68	34.13	33.78	52.64	30
1.57	34.00	34.29	33.94	52.64	30
1.60	34.16	34.56	34.57	52.64	30
1.61	34.63	35.16	35.21	52.64	30
1.63	34.80	35.72	35.35	52.64	30
1.64	35.13	36.19	35.66	52.64	30
1.66	35.43	36.65	35.81	52.64	30
1.67	35.72	37.12	36.25	52.64	30
1.69	36.02	37.27	36.56	52.64	30
1.71	36.17	37.42	36.71	52.64	30
1.72	36.46	37.89	37.18	52.64	30
1.74	36.74	38.22	37.49	52.64	30
1.76	37.04	38.53	37.80	52.64	30
1.77	37.34	38.84	37.95	52.64	30
1.79	37.65	39.13	38.27	52.64	30
1.80	37.81	39.29	38.57	52.64	30
1.82	38.15	39.73	38.88	52.64	30
1.83	38.46	39.89	39.05	52.64	30
1.86	39.08	40.03	39.22	52.64	30
1.88	39.72	40.48	39.68	52.64	30
1.90	39.86	40.76	40.00	52.64	30
1.92	40.19	40.92	40.62	52.64	30
1.93	40.51	41.07	41.09	52.64	30
1.95	40.82	41.50	41.36	52.64	30
1.96	40.95	41.65	41.66	52.64	30
1.98	41.26	41.81	41.95	52.64	30
2.00	41.57	42.27	42.10	52.64	30
2.01	41.87	42.58	42.56	52.64	30
2.03	42.17	43.15	42.86	52.64	30
2.05	42.48	43.45	43.02	52.64	30
2.06	42.79	43.60	43.30	52.64	30
2.08	43.07	44.09	43.59	52.64	30
2.09	43.22	44.24	43.89	52.64	30
2.11	43.53	44.55	44.17	52.64	30
2.12	43.84	44.71	44.49	52.64	30
2.16	44.30	45.16	44.66	52.64	30
2.19	44.93	45.43	44.98	52.64	30
2.21	45.55	45.75	45.31	52.64	30
2.22	45.71	46.07	45.78	52.64	30
2.24	46.03	46.22	46.38	52.64	30
2.25	46.50	46.51	46.98	52.64	30
2.27	46.65	46.80	47.30	52.64	30
2.28	46.96	47.07	47.46	52.64	30
2.30	47.28	47.22	47.61	52.64	30
2.32	47.58	47.80	48.05	52.64	30
2.34	47.74	48.08	48.34	52.64	30
2.35	48.02	48.37	48.66	52.64	30
2.37	48.33	48.66	48.80	52.64	30
2.38	48.61	48.96	48.96	52.64	30
2.40	48.91	49.25	49.40	52.64	30
2.42	49.20	49.39	49.69	52.64	30
2.43	49.51	49.68	50.00	52.64	30
2.45	49.65	49.96	50.30	52.64	30
2.48	50.25	50.25	50.61	52.64	30
2.51	50.86	50.54	50.75	52.64	30
2.53	51.31	50.69	51.05	52.64	30
2.55	51.59	50.98	51.34	52.64	30
2.56	51.87	51.28	51.64	52.64	30
2.58	52.17	51.57	51.94	52.64	30
2.60	52.47	51.87	52.26	52.64	30
2.61	52.61	52.02	52.56	52.64	30
2.63	52.90		52.71	52.64	30
2.64	53.20			52.64	30

Number	Measured	Average	Quoted
Number	Measured	Average	Quoted
1	0.330	0.343	0.230
2	0.372	0.343	0.230
3	0.325	0.343	0.230
4	0.342	0.343	0.230
5	0.326	0.343	0.230
6	0.376	0.343	0.230
7	0.331	0.343	0.230
8	0.341	0.343	0.230
