Sufix 131 G-Core x13 : 10lb
12 carrier HMPE braided line plus a single GORE® Performance Fiber in the center for optimal roundness and reduced internal abrasion. Built with 13 fibers (12 HMPE fibers + 1 GORE® Performance Fiber in core) to guarantee consistently strong construction with no weak points for reliable braided line during casting, strikes and fighting action. Construction increases the number of fibers at the knot resulting in better knot tying and stronger holding power. A single strand of GORE® Performance Fiber surrounded by 12 precision braided HMPE fibers results in a “super-round” line that is smoother and quieter than other lines.
Key Statistics
- Measured Diameter: .243mm (+121.5% on stated .200mm)
- Measured Breaking Strain: 26.44lbs (+264.4% on claimed 10lbs)
- Abrasion Breaking Strain: 7.64lbs (28.9% of measured max break)
Breaking strain indicates that this line is significantly underrated and is closer to 26lb than 10lb.
Tensile Strength (367812psi) is BELOW average (rank 11 of 19)
Abrasion resistance as a percentage of maximum breaking strain is BELOW average @ 28.9% (average 31.8%).
Overall this line was a little disappointing when looking at the test results, especially compared to the Sufix 832 which tested significantly better in every test. Sufix 832 is also cheaper so there appears to be little reason to pick the 131 over 832.
Testing Process
Key Line Statistics
Attribute | Value |
---|---|
Brand | Sufix |
Name | 131 G-Core x13 |
Web Site | Visit Website |
Rated Strength (lbs) | 10 |
Date Tested | 22 October 2022 |
Credit to | Line Laboratory |
Strands | 13 |
Cost $AUD | 48.77 |
Spool Quanity (m) | 135 |
Quoted Diameter (mm) | 0.2 |
Measured Average Diameter (mm) | 0.243 |
Diameter Quoted vs Measured (%) | 121.5 |
Minimum Diameter (mm) | 0.234 |
Maximum Diameter (mm) | 0.25 |
Break Max Average (lbs) | 26.44 |
Claimed vs Actual Breaking Strain (%) | 264.37 |
Tensile Strength (PSI) | 366304 |
Tensile Rank | 36 |
Abrasion Break Max Average (lbs) | 7.64 |
Abrasion Break vs Max Break Strain (%) | 28.9 |
Abrasion % of Maximum Rank | 85 |
Abrasion Tensile Strength PSI | 105846 |
Abrasion Tensile Rank | 56 |
FG Break Max Average (lbs) | 0 |
FG Break vs Max Break Strain (%) | 0 |
FG % of Maximum Rank | 91 |
FG Tensile Strength PSI | 0 |
FG Tensile Rank | 97 |
Time | Test1 | Test2 | Test3 | Average | Rated |
---|---|---|---|---|---|
0,0 | 0,00 | 0,00 | 0,00 | 26,44 | 10 |
0,1 | 0,31 | 0,43 | 0,30 | 26,44 | 10 |
0,2 | 0,60 | 0,94 | 0,72 | 26,44 | 10 |
0,3 | 0,75 | 1,23 | 0,98 | 26,44 | 10 |
0,4 | 1,12 | 1,53 | 1,25 | 26,44 | 10 |
0,5 | 1,35 | 1,79 | 1,43 | 26,44 | 10 |
0,6 | 1,58 | 2,06 | 1,61 | 26,44 | 10 |
0,7 | 1,82 | 2,50 | 2,03 | 26,44 | 10 |
0,8 | 2,07 | 2,68 | 2,27 | 26,44 | 10 |
0,9 | 2,45 | 3,09 | 2,75 | 26,44 | 10 |
1,0 | 2,59 | 3,33 | 2,98 | 26,44 | 10 |
1,1 | 2,96 | 3,56 | 3,22 | 26,44 | 10 |
1,2 | 3,20 | 3,79 | 3,38 | 26,44 | 10 |
1,3 | 3,43 | 4,01 | 3,53 | 26,44 | 10 |
1,4 | 3,64 | 4,39 | 3,92 | 26,44 | 10 |
1,5 | 3,86 | 4,55 | 4,15 | 26,44 | 10 |
1,6 | 4,22 | 4,93 | 4,60 | 26,44 | 10 |
1,7 | 4,38 | 5,15 | 4,82 | 26,44 | 10 |
1,8 | 4,74 | 5,62 | 5,20 | 26,44 | 10 |
1,9 | 4,94 | 5,87 | 5,37 | 26,44 | 10 |
2,0 | 5,36 | 6,11 | 5,53 | 26,44 | 10 |
2,1 | 5,58 | 6,26 | 5,75 | 26,44 | 10 |
2,2 | 5,79 | 6,42 | 5,97 | 26,44 | 10 |
2,3 | 5,92 | 6,80 | 6,42 | 26,44 | 10 |
2,4 | 6,06 | 7,04 | 6,66 | 26,44 | 10 |
2,5 | 6,40 | 7,51 | 7,05 | 26,44 | 10 |
2,6 | 6,61 | 7,74 | 7,22 | 26,44 | 10 |
2,7 | 7,04 | 8,13 | 7,58 | 26,44 | 10 |
2,8 | 7,26 | 8,27 | 7,79 | 26,44 | 10 |
2,9 | 7,48 | 8,42 | 7,99 | 26,44 | 10 |
3,0 | 7,62 | 8,64 | 8,26 | 26,44 | 10 |
3,1 | 7,77 | 8,86 | 8,52 | 26,44 | 10 |
3,2 | 8,10 | 9,30 | 8,95 | 26,44 | 10 |
3,3 | 8,30 | 9,51 | 9,12 | 26,44 | 10 |
3,4 | 8,72 | 9,85 | 9,52 | 26,44 | 10 |
3,5 | 8,95 | 9,98 | 9,75 | 26,44 | 10 |
3,6 | 9,18 | 10,31 | 9,99 | 26,44 | 10 |
3,7 | 9,32 | 10,53 | 10,24 | 26,44 | 10 |
3,8 | 9,47 | 10,74 | 10,49 | 26,44 | 10 |
3,9 | 9,82 | 10,96 | 10,91 | 26,44 | 10 |
4,0 | 10,03 | 11,19 | 11,07 | 26,44 | 10 |
4,1 | 10,45 | 11,55 | 11,43 | 26,44 | 10 |
4,2 | 10,66 | 11,70 | 11,61 | 26,44 | 10 |
4,3 | 11,01 | 12,03 | 12,04 | 26,44 | 10 |
4,4 | 11,16 | 12,21 | 12,28 | 26,44 | 10 |
4,5 | 11,30 | 12,40 | 12,52 | 26,44 | 10 |
4,6 | 11,49 | 12,61 | 12,67 | 26,44 | 10 |
4,7 | 11,69 | 12,83 | 12,82 | 26,44 | 10 |
4,8 | 12,10 | 13,19 | 13,17 | 26,44 | 10 |
4,9 | 12,33 | 13,33 | 13,36 | 26,44 | 10 |
5,0 | 12,67 | 13,72 | 13,77 | 26,44 | 10 |
5,1 | 12,80 | 13,95 | 13,98 | 26,44 | 10 |
5,2 | 12,92 | 14,19 | 14,19 | 26,44 | 10 |
5,3 | 13,13 | 14,42 | 14,29 | 26,44 | 10 |
5,4 | 13,33 | 14,64 | 14,38 | 26,44 | 10 |
5,5 | 13,72 | 15,03 | 14,68 | 26,44 | 10 |
5,6 | 13,91 | 15,20 | 14,89 | 26,44 | 10 |
5,7 | 14,21 | 15,54 | 15,27 | 26,44 | 10 |
5,8 | 14,32 | 15,71 | 15,46 | 26,44 | 10 |
5,9 | 14,62 | 16,13 | 15,76 | 26,44 | 10 |
6,0 | 14,81 | 16,36 | 15,88 | 26,44 | 10 |
6,1 | 14,99 | 16,60 | 16,00 | 26,44 | 10 |
6,2 | 15,16 | 16,75 | 16,20 | 26,44 | 10 |
6,3 | 15,33 | 16,91 | 16,40 | 26,44 | 10 |
6,4 | 15,60 | 17,27 | 16,83 | 26,44 | 10 |
6,5 | 15,71 | 17,49 | 17,07 | 26,44 | 10 |
6,6 | 16,02 | 17,91 | 17,37 | 26,44 | 10 |
6,7 | 16,22 | 18,13 | 17,43 | 26,44 | 10 |
6,8 | 16,53 | 18,34 | 17,50 | 26,44 | 10 |
6,9 | 16,64 | 18,46 | 17,65 | 26,44 | 10 |
7,0 | 16,96 | 18,58 | 17,81 | 26,44 | 10 |
7,1 | 17,17 | 18,91 | 18,14 | 26,44 | 10 |
7,2 | 17,60 | 19,11 | 18,31 | 26,44 | 10 |
7,3 | 17,82 | 19,51 | 18,62 | 26,44 | 10 |
7,4 | 18,03 | 19,71 | 18,76 | 26,44 | 10 |
7,5 | 18,20 | 20,04 | 19,10 | 26,44 | 10 |
7,6 | 18,36 | 20,19 | 19,31 | 26,44 | 10 |
7,7 | 18,73 | 20,33 | 19,52 | 26,44 | 10 |
7,8 | 18,93 | 20,53 | 19,66 | 26,44 | 10 |
7,9 | 19,33 | 20,73 | 19,81 | 26,44 | 10 |
8,0 | 19,54 | 21,13 | 20,09 | 26,44 | 10 |
8,1 | 19,74 | 21,34 | 20,22 | 26,44 | 10 |
8,2 | 19,89 | 21,57 | 20,56 | 26,44 | 10 |
8,3 | 20,04 | 21,59 | 20,77 | 26,44 | 10 |
8,4 | 20,41 | 21,68 | 20,97 | 26,44 | 10 |
8,5 | 20,62 | 21,75 | 21,17 | 26,44 | 10 |
8,6 | 21,04 | 21,81 | 21,36 | 26,44 | 10 |
8,7 | 21,25 | 22,03 | 21,70 | 26,44 | 10 |
8,8 | 21,45 | 22,24 | 21,85 | 26,44 | 10 |
8,9 | 21,60 | 22,46 | 22,20 | 26,44 | 10 |
9,0 | 21,75 | 22,48 | 22,41 | 26,44 | 10 |
9,1 | 22,02 | 22,51 | 22,74 | 26,44 | 10 |
9,2 | 22,13 | 22,62 | 22,85 | 26,44 | 10 |
9,3 | 22,37 | 22,71 | 22,97 | 26,44 | 10 |
9,4 | 22,49 | 22,97 | 23,09 | 26,44 | 10 |
9,5 | 22,83 | 23,13 | 23,22 | 26,44 | 10 |
9,6 | 23,04 | 23,50 | 23,54 | 26,44 | 10 |
9,7 | 23,26 | 23,71 | 23,73 | 26,44 | 10 |
9,8 | 23,38 | 23,91 | 24,13 | 26,44 | 10 |
9,9 | 23,49 | 24,05 | 24,34 | 26,44 | 10 |
10,0 | 23,69 | 24,18 | 24,54 | 26,44 | 10 |
10,1 | 23,76 | 24,50 | 24,68 | 26,44 | 10 |
10,2 | 23,84 | 24,68 | 24,83 | 26,44 | 10 |
10,3 | 23,96 | 24,98 | 25,18 | 26,44 | 10 |
10,4 | 24,08 | 25,10 | 25,39 | 26,44 | 10 |
10,5 | 24,39 | 25,22 | 25,72 | 26,44 | 10 |
10,6 | 24,57 | 25,37 | 25,83 | 26,44 | 10 |
10,7 | 24,93 | 25,51 | 26,07 | 26,44 | 10 |
10,8 | 25,11 | 25,80 | 26,20 | 26,44 | 10 |
10,9 | 25,42 | 25,94 | 26,32 | 26,44 | 10 |
11,0 | 25,57 | 26,08 | 26,53 | 26,44 | 10 |
11,1 | 25,71 | 26,73 | 26,44 | 10 | |
11,2 | 25,90 | 26,94 | 26,44 | 10 | |
11,3 | 26,10 | 26,44 | 10 | ||
11,4 | 26,29 | 26,44 | 10 |
