Sufix 832 - 15lb Braid

Sufix® 832® Advanced Superline® is the strongest, most durable small diameter braid on the market. R8 Precision Braiding and fiber technology provides superior strength, roundness and line consistency. 832 Advanced Superline has 8 fibers (7 HMPE fibers plus 1 GORE® Performance Fiber) and 32 weaves (pics) per inch. GORE® Performance Fibers improve abrasion resistance, increase casting distance & accuracy and reduce line vibration. HMPE fibers provide high strength & sensitivity, hydrophobic water-repellent protection and small diameter.

https://www.rapala.com/sufix/braid/832-advanced-superline/832-advanced-superline/832+Advanced+Superline.html

Key Statistics

Measured Diameter: .258mm (+117% on claimed .22mm)
Measured Breaking Strain: 36.45lbs (+243% on claimed 15lbs)
Abrasion Breaking Strain: 711.93lbs (30% of measured max break)

Breaking strain indicate that this line is closer to 36lb than 15lb.

Tensile Strength (449816 psi) is the highest tested as of 11 September 22.

Abrasion resistance is average.

Testing Process

Key Line Statistics

Attribute	Value
Brand	Sufix
Name	832
Web Site	Visit Website
Rated Strength (lbs)	15
Date Tested	10 September 2022
Credit to	Line Laboratory
Strands	8
Cost $AUD	28.61
Spool Quanity (m)	135
Quoted Diameter (mm)	0.22
Measured Average Diameter (mm)	0.256
Diameter Quoted vs Measured (%)	116.36
Minimum Diameter (mm)	0.245
Maximum Diameter (mm)	0.278
Break Max Average (lbs)	36.52
Claimed vs Actual Breaking Strain (%)	243.47
Tensile Strength (PSI)	457155
Tensile Rank	5
Abrasion Break Max Average (lbs)	11.93
Abrasion Break vs Max Break Strain (%)	32.67
Abrasion % of Maximum Rank	59
Abrasion Tensile Strength PSI	149339
Abrasion Tensile Rank	9
FG Break Max Average (lbs)	25.26
FG Break vs Max Break Strain (%)	69.18
FG % of Maximum Rank	57
FG Tensile Strength PSI	316203
FG Tensile Rank	13

Time	Test1	Test2	Test3	Average	Rated
0,0	0,00	0,00	0,00	36,52	15
0,1	0,63	0,18	0,19	36,52	15
0,2	1,15	0,62	0,29	36,52	15
0,3	1,36	0,96	0,54	36,52	15
0,4	1,86	1,52	0,79	36,52	15
0,5	2,15	1,74	1,21	36,52	15
0,6	2,45	2,26	1,37	36,52	15
0,7	2,77	2,57	1,81	36,52	15
0,8	3,10	2,88	2,08	36,52	15
0,9	3,61	3,19	2,35	36,52	15
1,0	3,80	3,51	2,65	36,52	15
1,1	4,28	4,04	2,95	36,52	15
1,2	4,58	4,25	3,45	36,52	15
1,3	4,87	4,80	3,64	36,52	15
1,4	5,16	5,13	4,14	36,52	15
1,5	5,45	5,46	4,44	36,52	15
1,6	5,92	5,77	5,04	36,52	15
1,7	6,11	6,08	5,35	36,52	15
1,8	6,60	6,60	5,65	36,52	15
1,9	6,90	6,82	5,82	36,52	15
2,0	7,51	7,34	6,00	36,52	15
2,1	7,82	7,66	6,44	36,52	15
2,2	8,12	8,30	6,71	36,52	15
2,3	8,32	8,64	7,24	36,52	15
2,4	8,53	8,97	7,50	36,52	15
2,5	9,02	9,20	7,76	36,52	15
2,6	9,32	9,44	7,94	36,52	15
2,7	9,87	9,99	8,11	36,52	15
2,8	10,12	10,31	8,57	36,52	15
2,9	10,38	10,90	8,86	36,52	15
3,0	10,57	11,18	9,38	36,52	15
3,1	10,76	11,45	9,63	36,52	15
3,2	11,23	11,65	10,05	36,52	15
3,3	11,51	11,84	10,23	36,52	15
3,4	12,03	12,30	10,41	36,52	15
3,5	12,28	12,57	10,72	36,52	15
3,6	12,70	13,11	11,02	36,52	15
3,7	12,88	13,40	11,57	36,52	15
3,8	13,06	13,87	11,80	36,52	15
3,9	13,32	14,05	12,20	36,52	15
4,0	13,59	14,24	12,35	36,52	15
4,1	14,07	14,48	12,51	36,52	15
4,2	14,29	14,72	12,76	36,52	15
4,3	14,68	15,17	13,02	36,52	15
4,4	14,86	15,37	13,49	36,52	15
4,5	15,03	15,75	13,70	36,52	15
4,6	15,29	15,93	14,06	36,52	15
4,7	15,54	16,10	14,21	36,52	15
4,8	16,04	16,31	14,35	36,52	15
4,9	16,28	16,52	14,62	36,52	15
5,0	16,68	16,97	14,88	36,52	15
5,1	16,83	17,20	15,37	36,52	15
5,2	17,24	17,59	15,60	36,52	15
5,3	17,50	17,75	15,97	36,52	15
5,4	17,75	18,10	16,11	36,52	15
5,5	17,96	18,31	16,49	36,52	15
5,6	18,16	18,51	16,72	36,52	15
5,7	18,54	18,69	16,95	36,52	15
5,8	18,70	18,87	17,14	36,52	15
5,9	19,11	19,23	17,33	36,52	15
6,0	19,35	19,41	17,68	36,52	15
6,1	19,80	19,79	17,84	36,52	15
6,2	20,01	19,99	18,24	36,52	15
6,3	20,22	20,19	18,49	36,52	15
6,4	20,37	20,41	18,95	36,52	15
6,5	20,52	20,63	19,17	36,52	15
6,6	20,88	21,01	19,39	36,52	15
6,7	21,10	21,17	19,50	36,52	15
6,8	21,49	21,50	19,61	36,52	15
6,9	21,66	21,66	19,94	36,52	15
7,0	22,08	21,83	20,16	36,52	15
7,1	22,31	21,97	20,53	36,52	15
7,2	22,55	22,12	20,68	36,52	15
7,3	22,78	22,42	21,01	36,52	15
7,4	23,02	22,58	21,18	36,52	15
7,5	23,45	22,94	21,36	36,52	15
7,6	23,64	23,13	21,57	36,52	15
7,7	23,96	23,52	21,78	36,52	15
7,8	24,08	23,71	22,24	36,52	15
7,9	24,36	23,90	22,49	36,52	15
8,0	24,51	24,05	22,83	36,52	15
8,1	24,67	24,21	22,93	36,52	15
8,2	24,83	24,50	23,02	36,52	15
8,3	24,99	24,64	23,23	36,52	15
8,4	25,33	24,92	23,43	36,52	15
8,5	25,51	25,07	23,81	36,52	15
8,6	25,84	25,21	23,98	36,52	15
8,7	26,00	25,33	24,32	36,52	15
8,8	26,15	25,46	24,50	36,52	15
8,9	26,32	25,76	24,86	36,52	15
9,0	26,49	25,95	25,05	36,52	15
9,1	26,80	26,31	25,24	36,52	15
9,2	26,93	26,50	25,46	36,52	15
9,3	27,23	26,79	25,68	36,52	15
9,4	27,39	26,90	25,98	36,52	15
9,5	27,71	27,01	26,07	36,52	15
9,6	27,88	27,12	26,32	36,52	15
9,7	28,04	27,23	26,50	36,52	15
9,8	28,20	27,50	26,80	36,52	15
9,9	28,36	27,66	26,94	36,52	15
10,0	28,68	27,94	27,07	36,52	15
10,1	28,84	28,06	27,24	36,52	15
10,2	29,18	28,37	27,42	36,52	15
10,3	29,35	28,56	27,77	36,52	15
10,4	29,67	28,75	27,96	36,52	15
10,5	29,82	28,93	28,30	36,52	15
10,6	29,96	29,12	28,46	36,52	15
10,7	30,11	29,40	28,70	36,52	15
10,8	30,25	29,49	28,79	36,52	15
10,9	30,53	29,70	28,87	36,52	15
11,0	30,65	29,82	29,03	36,52	15
11,1	30,95	29,93	29,19	36,52	15
11,2	31,11	30,12	29,47	36,52	15
11,3	31,28	30,30	29,59	36,52	15
11,4	31,44	30,60	29,88	36,52	15
11,5	31,59	30,71	30,06	36,52	15
11,6	31,94	31,01	30,40	36,52	15
11,7	32,12	31,21	30,56	36,52	15
11,8	32,47	31,58	30,73	36,52	15
11,9	32,63	31,77	30,88	36,52	15
12,0	32,88	31,95	31,03	36,52	15
12,1	32,96	32,06	31,26	36,52	15
12,2	33,05	32,17	31,35	36,52	15
12,3	33,19	32,40	31,63	36,52	15
12,4	33,33	32,51	31,82	36,52	15
12,5	33,63	32,81	32,02	36,52	15
12,6	33,80	32,99	32,15	36,52	15
12,7	34,08	33,27	32,27	36,52	15
12,8	34,21	33,38	32,56	36,52	15
12,9	34,33	33,48	32,73	36,52	15
13,0	34,48	33,69	33,08	36,52	15
13,1	34,64	33,91	33,26	36,52	15
13,2	34,93	34,32	33,60	36,52	15
13,3	35,06	34,53	33,74	36,52	15
13,4	35,28	34,83	33,89	36,52	15
13,5	35,36	34,92	34,01	36,52	15
13,6	35,57	35,02	34,13	36,52	15
13,7	35,71	35,13	34,42	36,52	15
13,8	35,84	35,24	34,60	36,52	15
13,9	35,97	35,53	34,89	36,52	15
14,0	36,10	35,70	35,02	36,52	15
14,1	36,23	35,99	35,14	36,52	15
14,2		36,10	35,31	36,52	15
14,3		36,41	35,49	36,52	15
14,4		36,61	35,74	36,52	15
14,5		36,81	35,83	36,52	15
14,6		37,01	35,91	36,52	15
14,7		37,22		36,52	15
14,8		37,42		36,52	15
