Sunline PE Jigger ULT : 25lb BRAID
The next generation of PE Jigger by Sunline. Designed specifically for deep sea jigging. The ULT has made some improvements to get you that deep sea predator.
It features LSP (low stretch processing) technology. Which gives it a maximum stretch of 3%. Perfect for deeper water where you need to feel everything that’s going on down below.
It also features SSP (Smooth Surface Processing). Which make the line more hydrophobic. Allowing less friction between the line and water. Put this with the LSP and it creates the perfect jigging braid for all your jigging needs.
Key Statistics
- Measured Diameter: .237mm (115% on stated .205mm)
- Measured Breaking Strain: 27.59lbs (110% of rated 25lbs)
- Abrasion Breaking Strain: 9.33lbs (33.8% of max break)
- FG Knot Breaking Strain: 15.33lbs (55.5% of max break)
Testing Process
Your consent is required to display this content from youtube - Privacy Settings
Key Line Statistics
| Attribute | Value |
|---|---|
| Brand | Sunline |
| Name | PE Jigger ULT x4 PE 1.5 |
| Web Site | Visit Website |
| Rated Strength (lbs) | 25 |
| Date Tested | 24 April 2023 |
| Credit to | @gulf_coast_slow_jigging |
| Strands | 4 |
| Cost $AUD | 209 |
| Spool Quanity (m) | 1200 |
| Quoted Diameter (mm) | 0.205 |
| Measured Average Diameter (mm) | 0.236 |
| Diameter Quoted vs Measured (%) | 115.12 |
| Minimum Diameter (mm) | 0.201 |
| Maximum Diameter (mm) | 0.259 |
| Break Max Average (lbs) | 27.59 |
| Claimed vs Actual Maximum Break (%) | 110.36 |
| Average Stretch @ Maximum Break | N/A |
| Tensile Strength (PSI) | 407780 |
| Tensile Rank | 23 |
| Abrasion Break Max Average (lbs) | 9.33 |
| Abrasion Break vs Max Break (%) | 33.83 |
| Abrasion % of Maximum Rank | 80 |
| Abrasion Tensile Strength PSI | 137897 |
| Abrasion Tensile Rank | 28 |
| FG Break Max Average (lbs) | 15.33 |
| FG Break vs Max Break (%) | 55.58 |
| FG % of Maximum Rank | 114 |
| FG Tensile Strength PSI | 226577 |
| FG Tensile Rank | 74 |
| Time | Test1 | Test2 | Test3 | Average | Rated |
|---|---|---|---|---|---|
| 0.0 | 0.00 | 0.00 | 0.00 | 27.59 | 25 |
| 0.1 | 1.49 | 0.72 | 0.74 | 27.59 | 25 |
| 0.2 | 2.35 | 1.40 | 1.12 | 27.59 | 25 |
| 0.3 | 2.57 | 1.71 | 1.15 | 27.59 | 25 |
| 0.4 | 2.93 | 2.26 | 1.54 | 27.59 | 25 |
| 0.5 | 3.28 | 2.48 | 1.92 | 27.59 | 25 |
| 0.6 | 3.99 | 3.06 | 2.67 | 27.59 | 25 |
| 0.7 | 4.35 | 3.42 | 3.02 | 27.59 | 25 |
| 0.8 | 4.92 | 4.12 | 3.62 | 27.59 | 25 |
| 0.9 | 5.14 | 4.47 | 3.85 | 27.59 | 25 |
| 1.0 | 5.70 | 4.82 | 4.09 | 27.59 | 25 |
| 1.1 | 6.03 | 5.06 | 4.44 | 27.59 | 25 |
| 1.2 | 6.37 | 5.29 | 4.80 | 27.59 | 25 |
| 1.3 | 6.69 | 5.87 | 5.48 | 27.59 | 25 |
| 1.4 | 7.00 | 6.22 | 5.80 | 27.59 | 25 |
| 1.5 | 7.54 | 6.89 | 6.35 | 27.59 | 25 |
| 1.6 | 7.75 | 7.22 | 6.57 | 27.59 | 25 |
| 1.7 | 8.29 | 7.78 | 6.79 | 27.59 | 25 |
| 1.8 | 8.61 | 8.02 | 7.10 | 27.59 | 25 |
| 1.9 | 9.25 | 8.25 | 7.40 | 27.59 | 25 |
| 2.0 | 9.57 | 8.56 | 8.01 | 27.59 | 25 |
| 2.1 | 9.89 | 8.86 | 8.31 | 27.59 | 25 |
| 2.2 | 10.08 | 9.49 | 8.80 | 27.59 | 25 |
| 2.3 | 10.26 | 9.81 | 8.99 | 27.59 | 25 |
| 2.4 | 10.73 | 10.32 | 9.49 | 27.59 | 25 |
| 2.5 | 11.02 | 10.52 | 9.79 | 27.59 | 25 |
| 2.6 | 11.58 | 10.71 | 10.10 | 27.59 | 25 |
| 2.7 | 11.85 | 10.98 | 10.38 | 27.59 | 25 |
| 2.8 | 12.13 | 11.26 | 10.65 | 27.59 | 25 |
| 2.9 | 12.30 | 11.83 | 11.10 | 27.59 | 25 |
| 3.0 | 12.48 | 12.12 | 11.28 | 27.59 | 25 |
| 3.1 | 12.91 | 12.62 | 11.72 | 27.59 | 25 |
| 3.2 | 13.18 | 12.81 | 11.99 | 27.59 | 25 |
| 3.3 | 13.72 | 13.28 | 12.26 | 27.59 | 25 |
| 3.4 | 13.99 | 13.54 | 12.48 | 27.59 | 25 |
| 3.5 | 14.27 | 13.81 | 12.71 | 27.59 | 25 |
| 3.6 | 14.45 | 14.07 | 13.10 | 27.59 | 25 |
| 3.7 | 14.64 | 14.34 | 13.27 | 27.59 | 25 |
| 3.8 | 15.03 | 14.74 | 13.70 | 27.59 | 25 |
| 3.9 | 15.25 | 14.87 | 13.97 | 27.59 | 25 |
| 4.0 | 15.71 | 15.23 | 14.47 | 27.59 | 25 |
| 4.1 | 15.97 | 15.46 | 14.70 | 27.59 | 25 |
| 4.2 | 16.35 | 15.68 | 14.94 | 27.59 | 25 |
| 4.3 | 16.48 | 15.93 | 15.10 | 27.59 | 25 |
| 4.4 | 16.61 | 16.18 | 15.25 | 27.59 | 25 |
| 4.5 | 16.85 | 16.61 | 15.64 | 27.59 | 25 |
| 4.6 | 17.08 | 16.78 | 15.86 | 27.59 | 25 |
| 4.7 | 17.56 | 17.24 | 16.27 | 27.59 | 25 |
| 4.8 | 17.81 | 17.53 | 16.46 | 27.59 | 25 |
| 4.9 | 18.24 | 17.81 | 16.64 | 27.59 | 25 |
| 5.0 | 18.44 | 18.05 | 16.79 | 27.59 | 25 |
| 5.1 | 18.63 | 18.29 | 16.94 | 27.59 | 25 |
| 5.2 | 18.79 | 18.66 | 17.35 | 27.59 | 25 |
| 5.3 | 18.95 | 18.79 | 17.61 | 27.59 | 25 |
| 5.4 | 19.32 | 19.11 | 18.10 | 27.59 | 25 |
| 5.5 | 19.54 | 19.31 | 18.33 | 27.59 | 25 |
| 5.6 | 19.86 | 19.75 | 18.70 | 27.59 | 25 |
| 5.7 | 19.96 | 20.01 | 18.85 | 27.59 | 25 |
| 5.8 | 20.28 | 20.26 | 18.99 | 27.59 | 25 |
| 5.9 | 20.48 | 20.40 | 19.20 | 27.59 | 25 |
| 6.0 | 20.69 | 20.55 | 19.40 | 27.59 | 25 |
| 6.1 | 20.92 | 20.96 | 19.78 | 27.59 | 25 |
| 6.2 | 21.15 | 21.22 | 19.96 | 27.59 | 25 |
| 6.3 | 21.51 | 21.69 | 20.23 | 27.59 | 25 |
| 6.4 | 21.65 | 21.90 | 20.34 | 27.59 | 25 |
| 6.5 | 21.92 | 22.20 | 20.44 | 27.59 | 25 |
| 6.6 | 22.07 | 22.30 | 20.72 | 27.59 | 25 |
| 6.7 | 22.21 | 22.40 | 21.01 | 27.59 | 25 |
| 6.8 | 22.40 | 22.56 | 21.47 | 27.59 | 25 |
| 6.9 | 22.60 | 22.73 | 21.64 | 27.59 | 25 |
| 7.0 | 22.89 | 23.09 | 22.00 | 27.59 | 25 |
| 7.1 | 22.98 | 23.29 | 22.17 | 27.59 | 25 |
| 7.2 | 23.27 | 23.66 | 22.35 | 27.59 | 25 |
| 7.3 | 23.46 | 23.83 | 22.51 | 27.59 | 25 |
| 7.4 | 23.87 | 24.00 | 22.68 | 27.59 | 25 |
| 7.5 | 24.08 | 24.22 | 23.00 | 27.59 | 25 |
| 7.6 | 24.30 | 24.44 | 23.16 | 27.59 | 25 |
| 7.7 | 24.46 | 24.87 | 23.39 | 27.59 | 25 |
| 7.8 | 24.63 | 25.08 | 23.45 | 27.59 | 25 |
| 7.9 | 24.92 | 25.38 | 23.74 | 27.59 | 25 |
| 8.0 | 25.04 | 25.47 | 23.96 | 27.59 | 25 |
| 8.1 | 25.36 | 25.56 | 24.18 | 27.59 | 25 |
| 8.2 | 25.54 | 25.73 | 24.29 | 27.59 | 25 |
| 8.3 | 25.73 | 25.91 | 24.40 | 27.59 | 25 |
| 8.4 | 25.82 | 26.26 | 24.59 | 27.59 | 25 |
| 8.5 | 25.92 | 26.45 | 24.67 | 27.59 | 25 |
| 8.6 | 26.19 | 26.79 | 24.86 | 27.59 | 25 |
| 8.7 | 26.38 | 26.95 | 24.97 | 27.59 | 25 |
| 8.8 | 26.80 | 27.29 | 25.18 | 27.59 | 25 |
| 8.9 | 27.03 | 27.47 | 25.27 | 27.59 | 25 |
| 9.0 | 27.41 | 27.65 | 25.37 | 27.59 | 25 |
| 9.1 | 27.55 | 25.44 | 27.59 | 25 | |
| 9.2 | 27.69 | 25.52 | 27.59 | 25 | |
| 9.3 | 27.69 | 25.79 | 27.59 | 25 | |
| 9.4 | 25.98 | 27.59 | 25 | ||
| 9.5 | 26.30 | 27.59 | 25 | ||
| 9.6 | 26.43 | 27.59 | 25 | ||
| 9.7 | 26.55 | 27.59 | 25 | ||
| 9.8 | 26.67 | 27.59 | 25 | ||
| 9.9 | 26.80 | 27.59 | 25 | ||
| 10.0 | 26.97 | 27.59 | 25 | ||
| 10.1 | 27.02 | 27.59 | 25 | ||
| 10.2 | 27.15 | 27.59 | 25 | ||
| 10.3 | 27.24 | 27.59 | 25 | ||
| 10.4 | 27.36 | 27.59 | 25 | ||
| 10.5 | 27.39 | 27.59 | 25 | ||
| 10.6 | 27.43 | 27.59 | 25 | ||
| 10.7 | 27.43 | 27.59 | 25 |
