Sunline Siglon AMZ x8 : PE1.2 Braid

Sunline Siglon AMZ x8 PE1.2 Braid

The Highest peak of SIGLON PE is born

● The special processing “PSP”(Perforance Sustainable Processing) is adopted, which significantly prolongs initial performance.
● PSP also ensures that the casting feel and controllability continue for a long time.
● For all day long fishing, durability on fraying and smoothness is improved.
● A wide range of sizes are lined up to accommodate from small fish species to powerful fish, including x4, x8 braided choices.
● Blood Orange is highly visible in all seasons and wather confitons.
● Multi-color pattern allows precise adjustment of how deep the line goes. Not to use white markings, it reduces impact on fish (also reflects countermeasures for pufferfish, etc).

https://fishing.sunline.co.jp/english/line/18161/

Key Statistics

- Measured Diameter: .230mm (123.2% of stated .187mm)
- Out of Roundness: .044mm (19.1% variation in diameter)
- Measured Breaking Strain: 18.83 lbs (117% of rated Ave 16lbs)
- Abrasion Breaking Strain: 7.96 lbs (42.27% of max break)
- FG Knot Breaking Strain: 16.67 lbs (88.53% of max break)

Overall a very nice braid. The outright Tensile Strength was well below average but both the Abrasion and FG Knot strength were excellent. During inspection under the microscope, it did appear to have some diameter variation along its length, however that may of been due to line twist.

Testing Process

Key Line Statistics

Attribute	Value
Brand	Sunline
Name	SIGLON PE AMZ x8 PE1.2
Web Site	Visit Website
Rated Strength (lbs)	16
Date Tested	25 June 2024
Credit to
Strands	8
Cost $AUD	89.95
Spool Quanity (m)	300
Quoted Diameter (mm)	0.187
Measured Average Diameter (mm)	0.23
Diameter Quoted vs Measured (%)	122.99
Minimum Diameter (mm)	0.216
Maximum Diameter (mm)	0.26
Break Max Average (lbs)	18.83
Claimed vs Actual Breaking Strain (%)	117.67
Average Stretch @ Maximum Break	N/A
Tensile Strength (PSI)	291328
Tensile Rank	86
Abrasion Break Max Average (lbs)	7.96
Abrasion Break vs Max Break Strain (%)	42.26
Abrasion % of Maximum Rank	11
Abrasion Tensile Strength PSI	123153
Abrasion Tensile Rank	40
FG Break Max Average (lbs)	16.67
FG Break vs Max Break Strain (%)	88.55
FG % of Maximum Rank	12
FG Tensile Strength PSI	257909
FG Tensile Rank	34

Time	Test1	Test2	Test3	Average	Rated
0.0	0.00	0.00	0.00	18.83	16
0.1	0.79	0.89	1.09	18.83	16
0.2	1.41	1.57	1.87	18.83	16
0.3	1.65	1.79	2.11	18.83	16
0.4	1.88	2.02	2.35	18.83	16
0.5	2.10	2.25	2.50	18.83	16
0.6	2.32	2.47	2.66	18.83	16
0.7	2.76	2.84	3.04	18.83	16
0.8	2.99	2.99	3.27	18.83	16
0.9	3.35	3.33	3.72	18.83	16
1.0	3.48	3.52	3.93	18.83	16
1.1	3.62	3.72	4.29	18.83	16
1.2	3.83	3.92	4.42	18.83	16
1.3	4.03	4.13	4.56	18.83	16
1.4	4.42	4.46	4.75	18.83	16
1.5	4.61	4.59	4.95	18.83	16
1.6	4.91	4.91	5.32	18.83	16
1.7	5.03	5.09	5.51	18.83	16
1.8	5.32	5.47	5.81	18.83	16
1.9	5.48	5.65	5.94	18.83	16
2.0	5.65	5.84	6.06	18.83	16
2.1	5.81	5.95	6.23	18.83	16
2.2	5.98	6.07	6.39	18.83	16
2.3	6.25	6.34	6.70	18.83	16
2.4	6.37	6.51	6.85	18.83	16
2.5	6.63	6.82	7.09	18.83	16
2.6	6.78	6.96	7.18	18.83	16
2.7	6.93	7.11	7.42	18.83	16
2.8	7.08	7.22	7.56	18.83	16
2.9	7.23	7.33	7.70	18.83	16
3.0	7.47	7.59	7.87	18.83	16
3.1	7.56	7.75	8.03	18.83	16
3.2	7.79	8.06	8.30	18.83	16
3.3	7.94	8.23	8.39	18.83	16
3.4	8.08	8.49	8.63	18.83	16
3.5	8.23	8.59	8.77	18.83	16
3.6	8.37	8.69	8.91	18.83	16
3.7	8.62	8.82	9.04	18.83	16
3.8	8.72	8.94	9.18	18.83	16
3.9	8.96	9.22	9.45	18.83	16
4.0	9.10	9.36	9.58	18.83	16
4.1	9.37	9.60	9.81	18.83	16
4.2	9.50	9.68	9.91	18.83	16
4.3	9.63	9.77	10.14	18.83	16
4.4	9.72	9.92	10.29	18.83	16
4.5	9.81	10.07	10.43	18.83	16
4.6	10.02	10.34	10.56	18.83	16
4.7	10.14	10.47	10.68	18.83	16
4.8	10.40	10.67	10.89	18.83	16
4.9	10.55	10.74	10.97	18.83	16
5.0	10.78	10.93	11.14	18.83	16
5.1	10.86	11.03	11.24	18.83	16
5.2	10.95	11.14	11.33	18.83	16
5.3	11.07	11.26	11.44	18.83	16
5.4	11.18	11.37	11.55	18.83	16
5.5	11.41	11.62	11.73	18.83	16
5.6	11.53	11.75	11.81	18.83	16
5.7	11.71	11.98	12.02	18.83	16
5.8	11.77	12.07	12.16	18.83	16
5.9	11.84	12.17	12.43	18.83	16
6.0	11.96	12.29	12.56	18.83	16
6.1	12.08	12.40	12.69	18.83	16
6.2	12.33	12.64	12.77	18.83	16
6.3	12.46	12.76	12.85	18.83	16
6.4	12.68	12.96	13.06	18.83	16
6.5	12.76	13.05	13.18	18.83	16
6.6	12.97	13.26	13.44	18.83	16
6.7	13.09	13.38	13.56	18.83	16
6.8	13.21	13.51	13.69	18.83	16
6.9	13.33	13.65	13.78	18.83	16
7.0	13.45	13.80	13.86	18.83	16
7.1	13.68	14.03	14.10	18.83	16
7.2	13.79	14.13	14.25	18.83	16
7.3	13.99	14.34	14.53	18.83	16
7.4	14.07	14.46	14.66	18.83	16
7.5	14.16	14.70	14.88	18.83	16
7.6	14.31	14.82	14.97	18.83	16
7.7	14.47	14.94	15.06	18.83	16
7.8	14.75	15.02	15.19	18.83	16
7.9	14.87	15.10	15.32	18.83	16
8.0	15.09	15.31	15.58	18.83	16
8.1	15.19	15.44	15.71	18.83	16
8.2	15.28	15.71	15.93	18.83	16
8.3	15.39	15.84	16.01	18.83	16
8.4	15.51	15.98	16.26	18.83	16
8.5	15.73	16.06	16.41	18.83	16
8.6	15.83	16.14	16.57	18.83	16
8.7	16.02	16.33	16.69	18.83	16
8.8	16.11	16.43	16.80	18.83	16
8.9	16.33	16.66	17.01	18.83	16
9.0	16.46	16.79	17.11	18.83	16
9.1	16.60	16.91	17.32	18.83	16
9.2	16.60	16.99	17.45	18.83	16
9.3		17.07	17.57	18.83	16
9.4		17.29	17.72	18.83	16
9.5		17.43	17.86	18.83	16
9.6		17.69	18.12	18.83	16
9.7		17.82	18.24	18.83	16
9.8		18.00	18.51	18.83	16
9.9		18.06	18.67	18.83	16
10.0		18.12	18.83	18.83	16
10.1		18.23	18.97	18.83	16
10.2		18.35	19.11	18.83	16
10.3		18.55	19.34	18.83	16
10.4		18.65	19.44	18.83	16
10.5		18.82	19.65	18.83	16
10.6		18.90	19.78	18.83	16
10.7		18.98	20.05	18.83	16
10.8		18.98	20.21	18.83	16
10.9			20.36	18.83	16
11.0			20.54	18.83	16
11.1			20.72	18.83	16
11.2			20.90	18.83	16
