YGK FullDrag : PE6 - Line Laboratory

YGK FullDrag : PE6 Braid

Overview

The FULLDRAG X8 is engineered for intense game fishing, offering unmatched strength and durability. With its AAA-rated braided line and advanced Hyper PE material, this line provides exceptional performance in various fishing environments. Whether you’re inshore or offshore, the FULLDRAG X8 ensures you have the strength and reliability needed to land your biggest catch.

https://xbraidygk.com.au/products/fulldrag-x8-gp-d

Summary

- Measured Ave Diameter: 0.505mm
- Out of Roundness: 0.112mm (22.17% variation in diameter)
- Measured Maximum Break: 80.2 lbs (80.2% of claimed 100 lbs)
- Measured Stretch @ Break: 3.1% Abrasion
- Maximum Break: 26.69 lbs (33.28% of max break)
- FG Knot Maximum Break: 58.88 lbs (73.42% of max break)

As expected, a nice line from YGK however the final results were a little lower than expected. Maximum strength was quite a bit under the rated strength, and diameter was 24% over the quoted diameter. Construction and feel was typical high YGK quality.

Testing Process

Key Line Statistics

Attribute	Value
Brand	YGK
Name	XBraid FullDrag PE6
Web Site	Visit Website
Rated Strength (lbs)	100
Date Tested	9 January 2025
Credit to	Yoon V
Strands	8
Cost $AUD	169.95
Spool Quanity (m)	300
Quoted Diameter (mm)	0.405
Measured Average Diameter (mm)	0.505
Diameter Quoted vs Measured (%)	124.69
Minimum Diameter (mm)	0.469
Maximum Diameter (mm)	0.581
Break Max Average (lbs)	80.2
Claimed vs Actual Breaking Strain (%)	80.2
Average Stretch @ Maximum Break	3.10%
Tensile Strength (PSI)	259670
Tensile Rank	106
Abrasion Break Max Average (lbs)	26.69
Abrasion Break vs Max Break Strain (%)	33.28
Abrasion % of Maximum Rank	71
Abrasion Tensile Strength PSI	86416
Abrasion Tensile Rank	94
FG Break Max Average (lbs)	58.88
FG Break vs Max Break Strain (%)	73.42
FG % of Maximum Rank	55
FG Tensile Strength PSI	190640
FG Tensile Rank	77

StrainSummary	Test 1	Test 2	Test 3	Average	Rated
0.02	0.92	0.67	0.32	80.20	100
0.03	1.29	1.32	0.68	80.20	100
0.06	1.84	1.75	0.97	80.20	100
0.08	2.23	2.39	1.26	80.20	100
0.10	2.64	2.60	1.41	80.20	100
0.12	2.85	3.28	1.55	80.20	100
0.13	3.27	3.97	2.53	80.20	100
0.15	3.70	4.45	3.11	80.20	100
0.16	4.13	4.69	3.91	80.20	100
0.18	4.57	5.16	4.56	80.20	100
0.19	4.78	5.64	5.00	80.20	100
0.21	5.23	6.13	5.44	80.20	100
0.23	5.69	6.37	5.90	80.20	100
0.25	5.92	6.85	6.36	80.20	100
0.26	6.61	7.58	6.83	80.20	100
0.28	7.09	7.82	7.07	80.20	100
0.29	7.82	8.30	7.54	80.20	100
0.31	8.78	8.76	8.03	80.20	100
0.32	9.23	9.23	8.49	80.20	100
0.34	9.45	9.69	8.95	80.20	100
0.36	9.67	9.91	9.41	80.20	100
0.37	10.33	10.35	10.08	80.20	100
0.38	10.77	10.80	10.92	80.20	100
0.40	10.99	11.24	11.32	80.20	100
0.42	11.60	11.67	11.54	80.20	100
0.44	11.80	11.89	12.38	80.20	100
0.45	12.41	12.51	12.82	80.20	100
0.47	12.62	12.71	13.26	80.20	100
0.48	13.06	13.12	13.72	80.20	100
0.50	13.48	13.54	14.18	80.20	100
0.51	13.89	13.95	14.41	80.20	100
0.55	14.11	14.81	14.87	80.20	100
0.57	14.55	15.48	15.30	80.20	100
0.58	15.02	15.94	15.76	80.20	100
0.60	15.45	16.37	16.20	80.20	100
0.61	16.36	16.82	16.67	80.20	100
0.63	17.27	17.05	16.90	80.20	100
0.64	17.94	17.51	18.04	80.20	100
0.66	18.40	17.97	18.71	80.20	100
0.68	18.82	18.47	19.15	80.20	100
0.70	19.27	18.91	19.58	80.20	100
0.71	19.48	19.35	19.79	80.20	100
0.73	19.92	19.56	20.22	80.20	100
0.74	20.35	19.98	20.64	80.20	100
0.76	20.75	20.43	21.07	80.20	100
0.77	21.16	20.86	21.48	80.20	100
0.79	21.58	21.27	21.70	80.20	100
0.80	22.01	21.48	22.14	80.20	100
0.82	22.23	22.10	22.55	80.20	100
0.84	22.65	22.31	22.98	80.20	100
0.86	23.09	22.96	23.44	80.20	100
0.87	23.55	23.18	23.88	80.20	100
0.90	23.96	24.07	24.33	80.20	100
0.92	24.19	24.73	24.54	80.20	100
0.93	24.64	25.17	25.18	80.20	100
0.95	25.47	25.65	25.40	80.20	100
0.97	25.94	26.09	26.33	80.20	100
0.98	26.16	26.55	27.26	80.20	100
1.00	27.35	26.99	27.48	80.20	100
1.02	27.82	27.21	27.92	80.20	100
1.03	28.48	27.90	28.41	80.20	100
1.05	28.91	28.13	28.63	80.20	100
1.06	29.34	28.57	29.06	80.20	100
1.08	29.76	28.98	29.48	80.20	100
1.09	29.96	29.44	29.90	80.20	100
1.11	30.39	29.68	30.33	80.20	100
1.12	30.81	30.16	30.78	80.20	100
1.14	31.01	30.59	31.01	80.20	100
1.16	31.72	31.02	31.68	80.20	100
1.18	32.18	31.44	32.14	80.20	100
1.19	32.63	31.86	32.36	80.20	100
1.21	33.32	32.28	32.83	80.20	100
1.22	34.22	32.50	33.29	80.20	100
1.24	34.90	32.96	33.74	80.20	100
1.25	35.59	33.39	34.17	80.20	100
1.29	35.83	34.09	34.83	80.20	100
1.32	36.06	35.01	35.76	80.20	100
1.34	36.76	35.91	36.44	80.20	100
1.35	37.00	36.14	36.90	80.20	100
1.37	37.24	36.81	37.59	80.20	100
1.38	37.93	37.26	38.07	80.20	100
1.40	38.40	37.49	38.29	80.20	100
1.42	38.83	37.49	38.73	80.20	100
1.44	39.26	38.37	39.13	80.20	100
1.45	39.47	38.83	39.37	80.20	100
1.47	39.89	39.05	39.65	80.20	100
1.48	40.30	39.26	39.83	80.20	100
1.50	40.74	39.91	40.20	80.20	100
1.51	41.18	40.36	40.63	80.20	100
1.53	41.63	40.78	41.07	80.20	100
1.54	41.88	41.20	41.29	80.20	100
1.56	42.32	41.42	41.73	80.20	100
1.58	42.75	42.08	42.21	80.20	100
1.60	43.22	42.30	43.13	80.20	100
1.61	43.68	42.73	43.61	80.20	100
1.64	43.90	43.66	43.86	80.20	100
1.66	44.33	44.57	44.34	80.20	100
1.68	45.01	44.81	44.81	80.20	100
1.69	45.23	45.05	45.27	80.20	100
1.70	46.13	45.75	45.49	80.20	100
1.72	46.84	46.21	46.16	80.20	100
1.74	47.28	46.66	46.57	80.20	100
1.76	47.49	47.09	47.01	80.20	100
1.77	48.18	47.31	47.25	80.20	100
1.79	48.62	47.73	47.65	80.20	100
1.80	49.06	48.36	48.11	80.20	100
1.82	49.48	48.58	48.53	80.20	100
1.83	49.89	48.79	49.34	80.20	100
1.85	50.09	49.22	49.99	80.20	100
1.86	50.50	49.89	50.89	80.20	100
1.88	50.92	50.11	51.81	80.20	100
1.90	51.34	50.75	52.04	80.20	100
1.92	51.78	50.75	52.51	80.20	100
1.93	52.22	51.40	52.97	80.20	100
1.95	52.43	51.82	53.44	80.20	100
1.96	52.64	52.29	53.91	80.20	100
1.98	53.28	52.52	54.15	80.20	100
1.99	53.49	52.96	54.61	80.20	100
2.03	54.40	53.87	55.07	80.20	100
2.05	55.32	54.54	55.52	80.20	100
2.06	56.23	54.97	55.95	80.20	100
2.08	56.88	55.39	56.38	80.20	100
2.09	57.31	55.83	56.60	80.20	100
2.11	57.74	56.29	57.04	80.20	100
2.13	58.12	56.53	57.81	80.20	100
2.14	58.53	56.77	58.67	80.20	100
2.16	58.94	57.44	58.88	80.20	100
2.17	59.33	57.92	59.51	80.20	100
2.19	59.52	58.36	59.94	80.20	100
2.21	59.72	58.78	60.16	80.20	100
2.22	60.36	58.98	60.62	80.20	100
2.24	60.78	59.40	61.06	80.20	100
2.26	61.23	59.81	61.50	80.20	100
2.27	61.67	60.22	61.92	80.20	100
2.30	61.88	61.01	62.14	80.20	100
2.32	62.31	61.22	62.58	80.20	100
2.35	62.75	62.14	63.06	80.20	100
2.38	63.66	62.81	63.51	80.20	100
2.40	64.30	63.91	63.93	80.20	100
2.42	64.72	64.35	64.16	80.20	100
2.43	65.14	64.58	64.60	80.20	100
2.45	65.55	65.19	65.02	80.20	100
2.47	65.76	65.19	65.46	80.20	100
2.48	66.37	65.83	66.34	80.20	100
2.50	66.56	66.24	66.97	80.20	100
2.51	66.97	66.67	67.39	80.20	100
2.53	67.17	66.87	67.81	80.20	100
2.55	67.78	67.30	68.23	80.20	100
2.56	68.00	67.74	68.64	80.20	100
2.58	68.19	68.17	68.85	80.20	100
2.60	68.57	68.60	69.26	80.20	100
2.61	69.16	69.05	69.68	80.20	100
2.63	69.93	69.25	70.14	80.20	100
2.64	70.77	69.67	70.58	80.20	100
2.68	71.36	70.50	70.98	80.20	100
2.71	71.74	71.33	71.19	80.20	100
2.73	72.12	71.98	71.60	80.20	100
2.74	72.51	72.41	72.01	80.20	100
2.76	72.70	72.85	72.42	80.20	100
2.77	73.09	73.29	72.82	80.20	100
2.79	73.49	73.74	73.45	80.20	100
2.80	73.88	73.96	74.32	80.20	100
2.82	74.30	74.38	74.75	80.20	100
2.84	74.70	74.81	75.18	80.20	100
2.85	75.08	75.22	75.37	80.20	100
2.87	75.25	75.63	75.98	80.20	100
2.89	75.58	75.85	76.17	80.20	100
2.90	75.97	76.26	76.60	80.20	100
2.92	76.40	76.64	77.02	80.20	100
2.93	76.82	77.06	77.21	80.20	100
2.95		77.48	77.85	80.20	100
2.97		77.68	78.26	80.20	100
2.99		78.29	78.67	80.20	100
3.00		78.69	78.89	80.20	100
3.03		79.26	79.09	80.20	100
3.05		80.05	79.71	80.20	100
3.06		80.45	80.09	80.20	100
3.08		80.85	80.89	80.20	100
3.09		81.04	81.51	80.20	100
3.11		81.45		80.20	100
3.13		81.87		80.20	100
3.14		82.28		80.20	100
